qEmergency Calls

A call can be made to the emergency
phone number (911) using the voice input
command.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Emergency”

3. Prompt:

“Dialing “911”, is this

correct?

”

4. Say: [Beep]

“Yes”

5. Prompt:

“Dialing”

qRefusing an Incoming Call

For incoming call refusal, refer to

“Receiving an incoming call” (page 6-79).

qMute

The microphone can be muted during a
call.

1. Press the talk button with a short press.

2. Say: [Beep]

“Mute”

3. Prompt:

“Microphone muted”

Canceling mute

1. Press the talk button with a short press.

2. Say: [Beep]

“Mute off”

3. Prompt:

“Microphone unmuted”

qTransferring a Call

Transferring a call from Hands-Free to
a device (Mobile phone)

Communication between the hands-free
unit and a device (Mobile phone) is
canceled, and the line can be switched to a
standard call using a device (Mobile
phone).

1. Press the talk button with a short press.

2. Say: [Beep]

“Transfer call”

3. Prompt:

“Transferred call to phone”

Transferring a call from a device
(Mobile phone) to Hands-Free

Communication between devices (Mobile
phone) can be switched to Bluetooth

Hands-Free.

1. Press the talk button with a short press.

2. Say: [Beep]

“Transfer call”

3. Prompt:

“Transferred call to Hands

Free system

”

qMulti-Call Functions

Call waiting

A call can be interrupted to receive an
incoming call from a third party.

Call interrupt

A call can be switched to a new incoming
call.

Method 1

1. Press the pick-up button.

2. Prompt:

“Swapping calls.”

Method 2

1. Press the talk button with a short press.

2. Say: [Beep]

“Swap calls”

6-82

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page280
Monday, May 23 2016 7:36 PM

Black plate (281,1)

3. Prompt:

“Swapping calls”

NOTE

To refuse an incoming call, press the hang-
up button.

After receiving a new incoming call, the
previous call is placed on hold.

Switching calls

Switching back to the previous call can
also be done.

Method 1

1. Press the pick-up button.

2. Prompt:

“Swapping calls.”

Method 2

1. Press the talk button with a short press.

2. Say: [Beep]

“Swap calls”

3. Prompt:

“Swapping calls”

Three-way call function

1. Press the talk button with a short press.

2. Say: [Beep]

“Join calls”

3. Prompt:

“Joining calls”

Making a call using a telephone
number

1. Press the talk button with a short press.

2. Say: [Beep]

“Dial”

3. Prompt:

“Number, please”

4. Say: [Beep]

“XXXXXXXXXXX

(Telephone number)

”

5. Prompt:

“XXXXXXXXXXX.

(Telephone number) After the beep,
continue to add numbers, or say Go-
Back to re-enter the last entered
numbers, or press the Pick-Up button
to execute dialing.

”

6. (Dialing)

Press the pick-up button or say

“Dial”,

then go to Step 7.
(Adding/inputting telephone
number)
Say,

“XXXX” (desired telephone

number), then go to Step 5.
(Telephone number correction)
Say,

“Go Back”. The prompt replies,

“Go Back. The last entered numbers
have been removed.

”. Then go back to

Step 3.

7. Prompt:

“Dialing”

Making calls using the phonebook

1. Press the talk button with a short press.

2. Say: [Beep]

“Call”

3. Prompt:

“Name please.”

4. Say: [Beep]

“XXXXX... (Ex. “John's

phone

”)” (Say a voice tag registered in

the phonebook.)

5. Prompt:

“Calling XXXXX... (Ex.

“John's phone”) XXXX (Ex. “at
home

”). Is this correct?” (Voice tag and

phone number location registered in
phonebook).

6. Say: [Beep]

“Yes”

7. Prompt:

“Dialing”

Redialing function

1. Press the talk button with a short press.

2. Say: [Beep]

“Redial”

3. Prompt:

“Dialing”

Ending the current call

Press the hang-up button during the call.

Interior Comfort

Bluetooth® Hands-Free

6-83

Mazda5_8FN4-EA-16G_Edition1 Page281
Monday, May 23 2016 7:36 PM

Black plate (282,1)

qPhonebook Settings

Editing phonebook

The data registered to the Bluetooth

Hands-Free phonebook can be edited.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Phonebook”

3. Prompt:

“Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.

”

4. Say: [Beep]

“Edit”

5. Prompt:

“Please say the name of the

entry you would like to edit or say,

“List names”.”

6. Say: [Beep]

“XXXXX... (Ex. “Mary's

phone

”)” (Say the voice tag for the

registered name to be edited in the
phonebook.)

7. Prompt:

“Home, Work, Mobile, or

Other?

”

8. Say: [Beep]

“Home” (Say the

registered location to be edited:

“Home”, “Work”, “Mobile”, or

“Other”).

9. Prompt:

“XXXXX... (Ex. “Mary's

phone

”) (Registered voice tag) XXXX

(Ex.

“Home”) (Registered location). Is

this correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“The current number is

XXXXXXXXXXX (Ex.

“555-1234”)

(Currently registered number). New
number, please.

”

NOTE

If there was no previous phone number
registered to a location (Ex.

“Work”), the

prompt will only read out

“Number, please”.

12. Say: [Beep]

“XXXXXXXXXXX

(Ex.

“555-5678”)” (Say the new

phone number to be registered.)

13. Prompt:

“XXXXXXXX (Telephone

number) After the beep, continue to
add numbers, or say Go-Back to re-
enter the last entered numbers, or
press the Pick-Up button to save the
number.

”

14. (Number Change)

Press the pick-up button, then go to
Step 15.
(Adding/inputting telephone
number)
Say,

“XXXX” (desired telephone

number), then go to Step 13.
(Telephone number correction)
Say,

“Go Back”. The prompt replies,

“Go Back. The last entered numbers
have been removed. Number, please.

”

. Then go back to Step 12.

15. Prompt:

“Number changed.”

Phonebook data deletion

Erasing individual phonebook data

Individual data registered to the
Bluetooth

Hands-Free phonebook can be

cleared.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

6-84

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page282
Monday, May 23 2016 7:36 PM

Black plate (283,1)

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Phonebook”

3. Prompt:

“Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.

”

4. Say: [Beep]

“Delete”

5. Prompt:

“Please say the name of the

entry you would like to delete or say,

“List names”.”

6. Say: [Beep]

“XXXXX... (Ex. “John's

phone

”)” (Say the registered voice tag

to be deleted from the phonebook.)

7. Prompt:

“Deleting XXXXX... (Ex.

“John's phone”) (Registered voice tag)
Home (Registered location). Is this
correct?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“XXXXX... (Ex. “John's

phone

”) (Registered voice tag) Home

(Registered location) deleted.

”

Complete deletion of the phonebook
data

All data registered to the Bluetooth

Hands-Free phonebook can be erased.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Phonebook”

3. Prompt:

“Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.

”

4. Say: [Beep]

“Erase all”

5. Prompt:

“Are you sure you want to

erase everything from your Hands Free
system phonebook?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“You are about to delete

everything from your Hands Free
system phonebook. Do you want to
continue?

”

8. Say: [Beep]

“Yes”

9. Prompt:

“Please wait, erasing the

Hands Free system phonebook.

”

10. Prompt:

“Hands-Free system

phonebook erased.

”

Read-out of names registered to the
Bluetooth

Hands-Free phonebook

Bluetooth

Hands-Free can read out the

list of names registered to its phonebook.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Phonebook”

3. Prompt:

“Select one of the following:

New entry, edit, list names, delete,
erase all or import contact.

”

4. Say: [Beep]

“List names”

5. Prompt:

“XXXXX..., XXXXX...,

XXXXX... (Ex.

“John's phone”, Mary's

phone, Bill's phone)

” (Voice guidance

reads out the voice tags registered to
the phonebook.)

Press the talk button with a short press
during the read-out at the desired name,
and then say one of the following voice
commands to execute it.

“Continue”: Continues the list read-
out.

Interior Comfort

Bluetooth® Hands-Free

6-85

Mazda5_8FN4-EA-16G_Edition1 Page283
Monday, May 23 2016 7:36 PM

Black plate (284,1)

“Call”: Calls the registered phonebook
data when the talk button is short-
pressed.

“Edit”: Edits the registered phonebook
data when the talk button is short-
pressed.

“Delete”: Deletes the registered
phonebook data when the talk button is
short-pressed.

“Previous”: Returns to the previous
phonebook data in read-out when the
talk button is short-pressed.

6. Prompt:

“End of list, would you like

to start from the beginning?

”

7. Say: [Beep]

“No”

8. The procedure returns to Step 3.

qDTMF (Dual Tone Multi-

Frequency Signal) Transmission

This function is used when transmitting
DTMF via the user's voice. The receiver
of a DTMF transmission is generally a
home telephone answering machine or a
company's automated guidance call center
(When you send tone signals back
according to the voice guidance
recording).

1. Press the talk button with a short press.

2. Say: [Beep]

“XXXX... send” (Say

DTMF code)

3. Prompt:

“Sending XXXX... (DTMF

code)

”

Hands-Free Setting

qDevice

Device registration

For the registration of a Bluetooth

equipped device to Bluetooth

Hands-

Free.
Refer to Bluetooth® Hands-Free
Preparation on page 6-75.

Registered device read-out

Bluetooth

Hands-Free can read-out the

devices registered to its system.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Pairing options”

5. Prompt:

“Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.

”

6. Say: [Beep]

“List”

7. Prompt:

“XXXXX..., XXXXX...,

XXXXX... (Ex. Device A, device B,
device C)

” (The voice guidance reads

out the device tags registered to the
hands-free system.)

6-86

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page284
Monday, May 23 2016 7:36 PM

Black plate (285,1)

Press the talk button with a short press
during the read-out at the desired device,
and then say one of the following voice
commands to execute it.

“Select phone”: Selects device (Mobile
phone) when the talk button is short-
pressed.

“Select music player”: Selects device
(Music player) when the talk button is
short-pressed.

“Edit”: Edits device when the talk
button is short-pressed.

“Continue”: Continues the list read-
out.

“Delete”: Deletes the registered device
when the talk button is short-pressed.

“Previous”: Returns to the previous
device in read-out when the talk button
is short-pressed.

8. Prompt:

“End of list, would you like

to start from the beginning?

”

9. Say: [Beep]

“No”

10. Prompt:

“Returning to main menu.”

Device selection

If several devices have been programmed,
the Bluetooth

unit links the device last

connected. If you would like to link a
different programmed device, it is
necessary to change the link. The order of
device priority after the link has been
changed is maintained even when the
ignition is switched off.

Hands-free phone

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Select phone”

5. Prompt:

“Please say the name of the

device you would like to select.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C). Which
device please?

”

6. Say: [Beep]

“XXXXX... (Ex. Device

”

7. Prompt:

“XXXXX... (Ex. Device B).

Is this correct?

”

8. Say: [Beep]

“Yes” or “No”

9. If

“Yes”, go to Step 10. If “No”, the

procedure returns to Step 5.

10. Prompt:

“XXXXX... (Ex. Device B)

selected.

”

Music player

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Select music player”

5. Prompt:

“Please say the name of the

device you would like to select.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C). Which
device please?

”

Interior Comfort

Bluetooth® Hands-Free

6-87

Mazda5_8FN4-EA-16G_Edition1 Page285
Monday, May 23 2016 7:36 PM

Black plate (286,1)

6. Say: [Beep]

“XXXXX... (Ex. Device

”

7. Prompt:

“XXXXX... (Ex. Device B).

Is this correct?

”

8. Say: [Beep]

“Yes” or “No”

9. If

“Yes”, go to Step 10. If “No”, the

procedure returns to Step 5.

10. Prompt:

“XXXXX... (Ex. Device B)

selected.

”

NOTE

Device (Music player) selection can also be
done by operating the panel button (page
6-63).

Registered device (Mobile phone)
deletion

Registered devices (Mobile phone) can be
deleted individually or collectively.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Pairing options”

5. Prompt:

“Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.

”

NOTE

A registered device (Mobile phone) can be
deleted using the registration list.

6. Say: [Beep]

“Delete”

7. Prompt:

“Please say the name of the

device you would like to delete.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C), or all.
Which device please?

”

8. Say: [Beep]

“XXXXX... (Ex. device

”

NOTE

Say

“All” to delete all devices (Mobile phone).

9. Prompt:

“Deleting XXXXX... (Ex.

device B...) (Registered device tag). Is
this correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“Deleted”

Registered device editing

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Pairing options”

5. Prompt:

“Select one of the following:

Pair, Edit, Delete, List, or Set Pairing
Code.

”

6. Say: [Beep]

“Edit”

7. Prompt:

“Please say the name of the

device you would like to edit.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C). Which
device please?

”

6-88

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page286
Monday, May 23 2016 7:36 PM

Black plate (287,1)

8. Say: [Beep]

“XXXXX... (Ex. device

”

9. Prompt:

“New name please?”

10. Say: [Beep]

“XXXXX... (Ex. device

” (Speak a “device tag”, an

arbitrary name for the device.)

11. Prompt:

“XXXXX... (Ex. device C)

(Device tag), is this correct?

”

12. Say: [Beep]

“Yes”

13. Prompt:

“New name saved.”

qSecurity Setting

If a passcode is set, the system cannot be
activated unless the passcode is input.

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

Passcode setting

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Passcode”

5. Prompt:

“Passcode is disabled. Would

you like to enable it?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“Please say a 4-digit

passcode. Remember this passcode. It
will be required to use this system.

”

8. Say: [Beep]

“XXXX” (Say a desired 4-

digit passcode,

“PCode”.)

9. Prompt:

“Passcode XXXX (Passcode,

PCode). Is this correct?

”

10. Say: [Beep]

“Yes”

11. Prompt:

“Passcode is enabled.”

Using Bluetooth

Hands-Free with a

passcode

1. Press the pick-up button or talk button

with a short press.

2. Prompt:

“Hands-Free system is

locked. State the passcode to
continue.

”

3. Say: [Beep]

“XXXX” (Say the set

passcode

“PCode”.)

4. If the correct passcode is input, voice

guidance

“XXXXXX... (Ex. “Mary's

device

”) (Device tag) is connected” is

announced.
If the passcode is incorrect, voice
guidance

“XXXX (4-digit passcode,

Pcode) incorrect passcode, please try
again

” is announced.

Canceling the passcode

NOTE

Do this function only when parked. It is too
distracting to attempt while driving and you
may make too many errors to be effective.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Passcode”

5. Prompt:

“Passcode is enabled. Would

you like to disable it?

”

Interior Comfort

Bluetooth® Hands-Free

6-89

Mazda5_8FN4-EA-16G_Edition1 Page287
Monday, May 23 2016 7:36 PM

Black plate (288,1)

6. Say: [Beep]

“Yes”

7. Prompt:

“Passcode is disabled.”

Confirmation Prompts

The confirmation prompt confirms the
command content to the user before
advancing to the operation requested by
the user. When this function is turned on,
the system reads out the voice input
command previously received and
confirms whether the command is correct
before advancing to the command
execution.
When the confirmation prompt function is
turned on:
(Ex.

“Calling John's device. Is this

correct?

”)

When the confirmation prompt function is
turned off:
(Ex.

“Calling John's device.”)

NOTE

If the confirmation prompt function is turned
off when making an emergency call, the system
reads out and confirms the command before
executing it.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Setup”

3. Prompt:

“Select one of the following:

Pairing options, confirmation prompts,
language, passcode, select phone or
select music player.

”

4. Say: [Beep]

“Confirmation prompts”

5. Prompt:

“Confirmation prompts are

on/off. Would you like to turn
confirmation prompts off/on?

”

6. Say: [Beep]

“Yes”

7. Prompt:

“Confirmation prompts are

off/on.

”

qVoice Recognition Learning

Function (Speaker Enrollment)

The voice recognition learning function
enables voice recognition appropriate to
the characteristics of the user's voice.
If the recognition of the voice input
commands to the system is not adequate,
this function can largely improve the
system's voice recognition of the user. If
your voice can be recognized sufficiently
without using this function, you may not
realize the added benefit of the function.
To register your voice, the voice input
command list must be read out. Read out
the list when the vehicle is parked.
Perform the registration in as quiet a place
as possible (page 6-73).
The registration must be performed
completely. The required time is a few
minutes. The user needs to be seated in
the driver's seat with the voice input
command list for voice recognition
learning open to the page indicated in the
following.

When voice recognition learning is
done for the first time

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Voice training”

3. Prompt:

“This operation must be

performed in a quiet environment while
the vehicle is stopped. See the owner's
manual for the list of required training
phrases. Press and release the talk
button when you are ready to begin.
Press the hangup button to cancel at
any time.

”

4. Press the talk button with a short press.

6-90

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page288
Monday, May 23 2016 7:36 PM

Black plate (289,1)

5. The voice guidance reads out the voice

input command number (refer to the
voice input command list for voice
recognition learning). (Ex.

“Please read

phrase 1

”)

6. Say: [Beep]

“0123456789” (Say the

voice input command for voice
recognition learning (1 to 8) according
to the voice guidance.)

7. Prompt:

“Speaker enrollment is

complete.

”

NOTE

If an error occurred in the voice recognition
learning, re-learning can be done by pressing
the talk button with a short press.

Voice recognition re-learning

If voice recognition learning has already
been done.

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Voice training”

3. Prompt:

“Enrollment is enabled/

disabled. Would you like to disable/
enable or retrain?

”

4. Say: [Beep]

“Retrain”

5. Prompt:

“This operation must be

”

6. Press the talk button with a short press.

7. The voice guidance reads out the voice

input command number (refer to the
voice input command list for voice
recognition learning). (Ex.

“Please read

phrase 1

”)

8. Say: [Beep]

“0123456789” (Say the

voice input command for voice
recognition learning (1 to 8) according
to the voice guidance.)

9. Prompt:

“Speaker enrollment is

complete.

”

NOTE

If an error occurred in the voice recognition
learning, re-learning can be done by pressing
the talk button with a short press.

Voice input command list for voice
recognition learning

When reading out, the following points
must be observed:

Read out the numbers one at a time
correctly and naturally.

(For example,

“1234” must be read out

“one, two, three, four”, not “twelve, thirty
four

”.)

Do not read out parentheses.

“ (” and

hyphens

“-” are used for separating

numbers in a phone number.

Ex.

“ (888) 555-1212” must be spoken “Eight, eight,
eight, five, five, five, one, two, one, two.

”

Phrase

Command

0123456789

(888) 555-1212

Call

Dial

Setup

Cancel

Continue

Help

Interior Comfort

Bluetooth® Hands-Free

6-91

Mazda5_8FN4-EA-16G_Edition1 Page289
Monday, May 23 2016 7:36 PM

Black plate (290,1)

NOTE

The applicable phrase appears in the
display.

After user voice registration is completed,
voice guidance

“Speaker enrollment is

complete

” is announced.

Voice recognition learning on/off

1. Press the pick-up button or talk button

with a short press.

2. Say: [Beep]

“Voice training”

3. Prompt:

“Enrollment is enabled/

disabled. Would you like to disable/
enable or retrain?

”

4. Say: [Beep]

“Disable” or “Enable”

5. When

“Disable” is spoken, the voice

recognition learning is turned off.
When

“Enable” is spoken, the voice

recognition learning is turned on.

6. Prompt:

“Speaker Enrollment is

disabled/enabled.

”

When Bluetooth® Hands-
Free Cannot be Used

Bluetooth

Hands-Free cannot be used

under the following conditions:

The device is outside of the
communication area.

The device has a malfunction.

The device is not connected to the
hands-free unit equipped on the
vehicle.

The device's battery is weak.

The device is turned off.

The device is placed where radio
reception is difficult.

The ignition is switched off.

6-92

Interior Comfort

Bluetooth® Hands-Free

Mazda5_8FN4-EA-16G_Edition1 Page290
Monday, May 23 2016 7:36 PM

Black plate (291,1)

Safety Certification

FCC ID: NT8MBLUECO9 IC:3043A-
MBLUECO9
This device complies with Part 15 of the
FCC Rules and with RSS-210 of Industry
Canada. Operation is subject to the
following two conditions:
(1) This device may not cause harmful

interference, and

(2) This device must accept any

interference received, including
interference that may cause undesired
operation.

WARNING

Changes or modifications not
expressively approved by the party
responsible for compliance could void
the user's authority to operate the
equipment.

The term

“IC: ” before the radio

certification number only signifies that
Industry Canada technical specifications
were met.
The antenna used for this transmitter must
not be co-located or operating in
conjunction with any other antenna or
transmitter. End-users and installers must
be provided with installation instructions
and transmitter operating conditions for
satisfying RF exposure compliance.

Mazda Bluetooth® Hands-
Free Customer Service

For toll-free Bluetooth

Hands-Free

customer service call 800-430-0153 or go
to www.mazdahandsfree.ca for assistance.

Interior Comfort

Bluetooth® Hands-Free

6-93

Mazda5_8FN4-EA-16G_Edition1 Page291
Monday, May 23 2016 7:36 PM

Black plate (292,1)

Sunvisors

When you need a sunvisor, lower it for
use in front or swing it to the side.

Sunvisor

qVanity Mirrors

To use the vanity mirror, lower the
sunvisor.

Interior Lights

NOTE

Do not leave the lights on for long periods
while the engine is turned off. Otherwise, the
battery power could be depleted.

qIlluminated Entry System

When the illuminated entry system
operates, the overhead light (switch is in
the DOOR position) turns on for:

About 30 seconds after the driver's
door is unlocked and the ignition is
switched off (with the ignition key
removed).

About 15 seconds after all doors are
closed.

About 15 seconds after the ignition is
switched off (with the ignition key
removed) with all doors closed.

The light also turns off when:

The ignition is switched ON and all
doors are closed.

The driver's door is locked.

NOTE

Battery saver
If any door is left opened, the light turns off
after about 30 minutes to save the battery.
The light turns on again when the ignition
is switched ON, or when any door is
opened after all doors have been closed.

The operation of the illuminated entry
system can be changed.
Refer to Personalization Features on page
10-8.

6-94

Interior Comfort

Mazda5_8FN4-EA-16G_Edition1 Page292
Monday, May 23 2016 7:36 PM

Black plate (293,1)

qOverhead Lights

Front

Switch Position

Front Overhead Lights

Light off

Light is on when any door is
open

Light is on or off when the
illuminated entry system is
on

Rear

Switch Position

Rear Overhead Lights

Light off

Light is on when any door is
open

Light is on or off when the
illuminated entry system is
on

Light on

qMap Lights

The map lights are switched on or off by
pressing the switches.

Switches

qLuggage Compartment Light

Switch

Position

Luggage Compartment Light

Light off

Light on when the liftgate is open

Interior Comfort

6-95

Mazda5_8FN4-EA-16G_Edition1 Page293
Monday, May 23 2016 7:36 PM

Black plate (294,1)

Information Display

Steering switch

Audio display

Climate control display

Trip computer
display

Clock/Ambient
temperature display

qInformation Display Functions

The information display has the following functions:

Clock

Ambient Temperature Display

Climate Control Display

Audio Display

Trip Computer

Bluetooth

Hands-Free Display

Refer to Bluetooth® Hands-Free on page 6-71.

6-96

Interior Comfort

Some models.

Mazda5_8FN4-EA-16G_Edition1 Page294
Monday, May 23 2016 7:36 PM

Black plate (295,1)

qClock

When the ignition is switched to ACC or
ON, the time is displayed.

Time setting

1. Switch the ignition to ACC or ON.

2. Adjust the time using the time setting

buttons ( ,

The hours advance while the time
setting button ( ) is pressed.
The minutes advance while the time
setting button (

) is pressed.

Time resetting

1. Switch the ignition to ACC or ON.

2. Press the :00 button.

3. When the button is pressed, the time

will be reset as follows:

(Example)
12:01

―12:29→12:00

12:30

―12:59→1:00

NOTE

When the button is pressed, the seconds will
start at

“00”.

qAmbient Temperature Display

When the ignition is switched ON, the
ambient temperature is displayed.

NOTE

Under the following conditions, the ambient
temperature display may differ from the
actual ambient temperature depending on
the surroundings and vehicle conditions:

Significantly cold or hot temperatures.

Sudden changes in ambient temperature.

The vehicle is parked.

The vehicle is driven at low speeds.

Press the AUTO switch(page 6-5) for 3
seconds or more to switch the display from
Fahrenheit to Centigrade or vice versa.

qClimate Control Display

The climate control system status is
displayed. To operate the climate control
system, refer to

“Climate Control System”

(page 6-2).

qAudio Display

The audio system status is displayed. To
operate the audio system, refer to

“Audio System” (page 6-11).

Interior Comfort

6-97

Mazda5_8FN4-EA-16G_Edition1 Page295
Monday, May 23 2016 7:36 PM

Mazda 5 (2017 year). Manual - part 18
