Press the button on the end of the stalk
for wash and wipe. Rotate the collar to
adjust the time delay for intermittent
wipe, or to select AUTO for automatic
operation of the wipers.

Enabling automatic operation

The wiper stalk must be in position 1 and
AUTO selected on the collar to enable
automatic operation of the wipers.

Warning indicators

Side lamps on (Green).

Headlamp main beam on
(Blue).

Rear fog lamps on (Amber).

Automatic Speed Limiter (ASL)
active (Green).

Direction indicator (Green).

Seat belt reminder (Red).

Forward alert active (Amber).

Park brake On/Low brake fluid
(Red) USA only.

Anti-Lock Braking System
(ABS) (Amber) USA only.

Electric parking brake On/Low
brake fluid (Red) Canada and
Mexico only.

Anti-lock Braking System fault
(ABS) (Amber) Canada and
Mexico only.

Engine malfunction (Amber).

Dynamic Stability Control
(DSC) OFF. TracDSC ON
(Amber).

DSC system fault.

Adaptive Cruise Control active
(Amber).

Air bag system fault (Amber).

Adaptive front lighting system
fault (Amber).

Low tire pressure warning
(Yellow).

Automatic exterior lamps

If AUTO (autolamps) has been selected,
and the windshield wipers are operated
continuously for more than twenty
seconds, then the exterior lamps will be
switched on automatically.

E92029

Quick start

Electric Parking Brake (EPB)

• The EPB will automatically release

when the gear selector is moved from
P (Park) with the footbrake applied.

• The EPB can be manually released

when the engine is running and the
footbrake is applied. Press the EPB
switch down to release, and pull it up
to apply.

• If manually applied whilst in D or R,

the EPB will automatically release
when the accelerator is applied.

Transmission

Gearshift interlock

The ignition must be on, and the
footbrake applied, before the gear
selector can be moved from P (Park) to R
(Reverse). The selector can be moved
into P with the ignition off.

Sports mode

When the gear selector is moved from D
(Drive) to S (Sport) automatic changing of
the gears is maintained. However, the
gear shift points are modified to make full
use of the engine’s power.

Note: With the selector lever in S, and DS
displayed in the message centre, the
transmission will enter 6th gear less often
at higher cruising speeds.

Fuel consumption will be adversely
affected.

Manual operation

Manual changing of the gears via the
steering wheel paddles is possible when
the gear selector is in either D (Drive) or S
(Sport).

E92030

E92031
