-> No INSTALL a new supercharger air intake elbow. Test the system for normal operation. G532443t3 : CHECK THE OPERATION OF THE AIR INTAKE ELBOW 1. Remove the air cleaner outlet pipe, Air Cleaner Outlet Pipe (19.10.31) 2. Remove the supercharger outlet pipe, Supercharger Outlet Pipe (18.50.16) 3. Apply a vacuum to the actuator diaphragm. 4. Observe the butterfly operation. Does the butterfly operate? -> Yes Check for another cause of the malfunction.
-> No INSTALL a new supercharger air intake elbow. Test the system for normal operation.
|
