physical damage to the harness. If no fault is found in the circuit, suspect the following component(s): - Fuel injector 3 (INJ4)
-> No REPAIR the short circuit. For additional information, refer to the wiring diagrams. Clear any DTCs, test the system for normal operation. PINPOINT TEST G552275p11 : FUEL G552275t67 : CHECK THE COMPONENT RESISTANCE 1.
Circuit
Pin Fuel injector, cylinder 4 - ground 01
Fuel injector, cylinder 4 - control 02
2.
Circuit
Pin Fuel injector, cylinder 4 - ground L2
Fuel injector, cylinder 4 - control L1
3. Key off. 4. Disconnect the fuel injector 4 (INJ1) connector, C45. 5. Measure the resistance between: |
