Cooling System Flushing
1. Remove the air cleaner. <<303-12A>>
2. Remove the air cleaner. <<303-12B>>
3. Remove the thermostat.
Thermostat - 4.2L, Vehicles With: Supercharger (26.45.07)
4. Detach the lower coolant hose from the radiator and position to one side.
5. Detach the upper coolant hose from the radiator.
NOTE:
To remove rust, sludge and other foreign material from the cooling system, use Premium
Cooling System flush, meeting Jaguar specification EGR-M14P7-A, which is safe for use
with aluminium cooling systems. This cleaning restores cooling system efficiency and
helps prevent overheating.
NOTE:
In severe cases where cleaning solvents will not properly clean the cooling system, it will
be necessary to use the pressure flushing method using Cooling System Flusher, 164-
R3670 to restore efficient operation.
NOTE:
A pulsating or reversed direction of flushing water will loosen sediment more quickly
than a steady flow in the normal coolant flow direction.
