Secondary Bulkhead Center Panel Removal All vehicles
1 . Remove the cowl vent screen. For additional information, refer to Cowl Vent Screen (76.10.01)
2 .
Carry out the air conditioning (A/C) system recovery procedure. For additional information, refer to Air Conditioning (A/C) System Recovery, Evacuation and Charging (82.30.30)
Right-hand drive vehicles
3 . Drain the cooling system. For additional information, refer to Cooling System Draining, Filling and Bleeding
4 . Remove the air deflector. For additional information, refer to Air Deflector (76.11.41)
5 . Detach the transmission harness electrical connectors from the retaining bracket.
6 . Disconnect the transmission harness electrical connectors. |
