Do not modify the front seats.
Air Bag Warning Labels
• If components of the air bag
Modification of the front seats could
system must be discarded, or if
interfere with the operation of the
the vehicle must be scrapped,
supplemental restraint system sens-
certain safety precautions
ing components or side air bags.
2
must be observed. Consult an
authorized HYUNDAI dealer for
Do not place items under the front
the necessary information.
seats. Placing items under the front
Failure to follow these precau-
seats could interfere with the opera-
tions could increase the risk of
tion of the supplemental restraint
personal injury.
system sensing components and
wiring harnesses.
Do not cause impact to the doors.
Additional Safety Precautions
Impact to the doors when the Engine
OAE036060
Start/Stop button is in the ON posi-
Passengers should not move out
Air bag warning labels, required by
of or change seats while the vehi-
tion may cause the air bags to inflate.
the U.S. National Highway Traffic
cle is moving. A passenger who is
Modifications to accommodate
Safety Administration (NHTSA), are
not wearing a seat belt during a
disabilities. If you require modifica-
attached to alert the driver and pas-
crash or emergency stop can be
tion to your vehicle to accommodate
sengers of potential risks of the air
thrown against the inside of the vehi-
a disability, contact the HYUNDAI
bag system. Be sure to read all of the
cle, against other occupants, or be
Customer Connect Center at 800-
information about the air bags that
ejected from the vehicle.
633-5151.
are installed on your vehicle in this
Do not use any accessories on
Owners Manual.
seat belts. Devices claiming to
Adding equipment to or modify-
improve occupant comfort or reposi-
ing your air bag equipped vehicle
tion the seat belt can reduce the pro-
If you modify your vehicle by chang-
tection provided by the seat belt and
ing your vehicle's frame, bumper sys-
increase the chance of serious injury
tem, front end or side sheet metal or
in a crash.
ride height, this may affect the opera-
tion of your vehicle's air bag system.
2-63
Convenient features of your vehicle
Accessing Your Vehicle
3-3
Resetting the sunroof
3-31
Remote Key
3-3
Sunroof Open Warning
3-32
Smart Key
3-6
Exterior Features
3-33
Immobilizer System
3-11
Hood
3-33
Door Locks
3-13
Liftgate
3-34
Operating Door Locks from Outside the Vehicle
3-13
Fuel Filler Door
3-36
Operating Door Locks from Inside the Vehicle
3-14
Instrument Cluster
3-39
3
Automatic Door Lock and Unlock Features
3-17
Instrument Cluster Control
3-40
Child-Protector Rear Door Locks
3-17
Gauges and Meters
3-41
Theft-Alarm System
3-18
Transmission Shift Indicator
3-44
Steering Wheel
3-19
Warning and Indicator Lights
3-45
Electric Power Steering (EPS)
3-19
LCD Display Messages
3-56
Tilt Steering / Telescope Steering
3-20
LCD Display
3-62
Horn
3-20
LCD Display Control
3-62
Mirrors
3-21
LCD Display Modes
3-63
Inside Rearview Mirror
3-21
Trip Computer
3-73
Side View Mirrors
3-22
Head Up Display (HUD)
3-77
Windows
3-25
Lighting
3-80
Power Windows
3-26
Exterior Lights
3-80
Wide sunroof
3-29
Interior Lights
3-87
Sunroof Opening and Closing
3-30
Welcome System
3-89
Sliding the Sunroof
3-30
Wipers and Washers
3-91
Tilting the Sunroof
3-30
Windshield Wipers
3-91
Sunshade
3-31
Windshield Washers
3-93
Rear Window Wiper and Washer
3-94
Driver Assist System
3-95
Interior Features
3-121
Rear view monitor
3-95
Cup Holder
3-121
Manual Climate Control System
3-96
Sunvisor
3-122
Heating and Air Conditioning
3-97
Power Outlet
3-122
System Operation
3-100
USB charger
3-123
System Maintenance
3-102
Wireless Cellular Phone Charging System
3-124
Clock
3-126
3
Automatic Climate Control System
3-104
Clothes Hanger
3-127
Automatic Temperature Control Mode
3-105
Floor Mat Anchor(s)
3-127
Manual Temperature Control Mode
3-106
Cargo Area Cover
3-128
System Operation
3-109
System Maintenance
3-111
Windshield Defrosting and Defogging
3-113
Auto Defogging System (Additional Feature with
Automatic Temperature Control System)
3-115
Rear Window Defroster
3-117
Climate Control Additional Features
3-118
Automatic Ventilation
3-118
Sunroof Inside Air Recirculation
3-118
Storage Compartment
3-119
Center Console Storage
3-119
Glove Box
3-119
Sunglass Holder
3-120
ACCESSING YOUR VEHICLE
Remote Key (if equipped)
Locking Your Vehicle
WARNING
To lock your vehicle:
1. Make sure all doors, the engine
Do not leave the keys in your
hood and the liftgate are closed.
vehicle with unsupervised chil-
2. Press the Door Lock button (1) on
dren. Unattended children
the remote key to lock all doors.
could place the key in the igni-
tion switch and may operate
3. The hazard warning lights will
3
power windows or other con-
blink and the chime will sound
trols, or even make the vehicle
once.
move, which could result in
4. Make sure the doors are locked by
serious injury or death.
checking the position of the door
lock button inside the vehicle.
OPD046001
Your HYUNDAI uses a remote key,
which you can use to lock or unlock
the driver and passenger doors or
the rear liftgate.
1. Door Lock
2. Door Unlock
3. Liftgate Unlock
4. Panic
3-3
Convenient features of your vehicle
Unlocking your vehicle
Now all doors will unlock when the
Panic button (if equipped)
Door Unlock button is pressed one
To unlock your vehicle :
Press and hold the Panic button (4)
time. To change the setting back,
1. Press the Door Unlock button (2)
for more than one second. The horn
repeat this procedure.
sounds and hazard warning lights
on the remote key.
flash for about 30 seconds.
2. The driver's door will unlock. The
i
Information
To cancel the panic mode, press any
hazard warning lights will blink two
button on the remote key.
times.
After unlocking the doors, the doors
will automatically relock after 30 sec-
Two press unlock setting:
onds unless a door is opened.
If you press the Door Unlock but-
Start-up
ton on the remote key again with-
For information, refer to the "Key
in four seconds, then all the doors
Liftgate unlocking
Ignition Switch" section in chapter 5.
will unlock.
To unlock the liftgate :
Two press unlock setting can be
NOTICE
1. Press and hold the Liftgate Unlock
changed according to owner's pref-
button (3) on the remote key for
To prevent damaging the remote
erence in the cluster User Settings
more than one second.
key:
mode or with the remote key.
2. The hazard warning lights will
• Keep the remote key away from
• User settings mode method:
blink two times and the liftgate will
water or any liquid and fire.
Select or deselect the 'Two Press
be unlocked.
Internal circuits may malfunc-
Unlock' feature in the User
Once the liftgate is opened and then
tion if the inside of the remote
Settings mode on the cluster LCD
closed, the liftgate will lock automati-
key gets damp (from liquids or
display (User Settings ➞ Door ➞
cally.
moisture) or if it is heated. This
Two Press Unlock).
can exclude the remote key from
• Remote key method:
being covered under warranty.
i
Information
Press and hold both Door Lock (1)
• Avoid dropping or throwing the
The word "HOLD" is written on the
and Door Unlock (2) buttons at the
remote key.
button to inform you that you must
same time until the hazard warn-
press and hold the button for more
• Protect the remote key from
ing lights blink.
extreme temperatures.
than one second.
3-4
Mechanical key
Remote key precautions
When possible, avoid placing the
remote key and your mobile phone in
The remote key will not work if any of
the same location such as a pants or
the following occur:
jacket pocket in order to avoid inter-
• The key is in the ignition switch.
ference between the two devices.
• You exceed the operating distance
limit (about 90 feet [30 m]).
i
Information
• The remote key battery is weak.
3
This device complies with Part 15 of
• Other vehicles or objects may be
the FCC rules.
blocking the signal.
Operation is subject to the following
• The weather is extremely cold.
three conditions:
• The remote key is close to a radio
1. This device may not cause harmful
OPD046003
transmitter such as a radio station or
interference.
an airport which can interfere with
If the remote key does not operate
2. This device must accept any inter-
normal operation of the remote key.
normally, you can lock or unlock the
ference received, including interfer-
driver's door by using the mechanical
If the remote key does not work cor-
ence that may cause undesired
key.
rectly, open and close the door with
operation.
the mechanical key. If you have a
To unfold the mechanical key, press
3. Changes or modifications not
problem with the remote key contact
the release button on the remote.
expressly approved by the party
an authorized HYUNDAI dealer.
To return the key to its stored posi-
responsible for compliance could
If the remote key is in close proximi-
tion, press the release button and
void the user's authority to operate
ty to your mobile phone, the signal
fold the key back into the remote.
the device.
could be blocked by your mobile
phone's normal operational signals.
This is specifically relevant when the
phone is active such as making and
receiving calls, text messaging,
and/or sending/receiving emails.
3-5
Convenient features of your vehicle
NOTICE
2. Using a screw driver, remove the
Smart Key (if equipped)
battery cover.
Keep the remote key away from
3. Remove the old battery and insert
electromagnetic materials that
the new battery. Make sure the
block electromagnetic waves to
battery position is correct.
the key surface.
4. Reinstall the battery cover and key
cover in the reverse order of
Battery replacement
removal.
If you suspect your remote key might
have sustained some damage, or
you feel your remote key is not work-
ing correctly contact an authorized
HYUNDAI dealer.
OPD046044
Your HYUNDAI uses a Smart Key,
i
Information
which you can use to lock or unlock
An inappropriately disposed
the driver and passenger doors or
battery can be harmful to the
the rear liftgate.
environment and human health.
1. Door Lock
Dispose of the battery according
OPD046002
2. Door Unlock
to your local law(s) or regula-
3. Liftgate Unlock
If the remote key is not working prop-
tions.
erly, try replacing the battery with a
4. Panic
new one.
Battery Type: CR2032
To replace the battery:
1. Insert a slim tool into the slot and
gently pry open the cover.
3-6
Locking your vehicle
Unlocking your vehicle
i
Information
The door handle button will only
operate when the smart key is within
28~40 inches (0.7~1 m) from the out-
side door handle.
Note that you cannot lock your vehi-
3
cle using the door handle button if
any of the following occur:
• The Smart Key is in the vehicle.
• The Engine Start/Stop button is in
ACC or ON position.
OJS048001
OJS048001
• Any of the doors are open except
To lock your vehicle using the door
To unlock your vehicle:
for the liftgate.
handle button or the Smart Key:
1. Make sure you have the smart key
1. Close all doors, hood and liftgate.
in your possession.
WARNING
2. Either press the door handle but-
2. Press either the button on the
ton or press the Door Lock button
door handle or the Door Unock
Do not leave the Smart Key in
(1) on the smart key.
button (2) on the smart key. The
your vehicle with unsupervised
driver's door will unlock and the
3. The hazard warning lights will
children. Unattended children
hazard warning lights will blink two
blink and the chime will sound
could press the Engine Start/
times.
once.
Stop button and may operate
4. When the doors are locked, the
power windows or other con-
indicator light on the central door
trols, or even make the vehicle
lock/unlock switch will be illuminat-
move, which could result in
ed.
serious injury or death.
3-7
Convenient features of your vehicle
3. Two Press Unlock Feature
The Two Press Unlock Feature can
Opening the liftgate
also be enabled or disabled by
The priority for unlocking the driver
To unlock and open the liftgate:
pressing the door lock and unlock
door only, or unlocking all the doors
1. Make sure you have the smart key
buttons simultaneously on the Key
with one press may be adjusted in
in your possession.
FOB:
the User Settings menu in the LCD
2. Press either the liftgate handle
cluster display.
Press and hold both the DOOR
release button on the vehicle or
LOCK button and the DOOR
The Two Press Unlock feature, when
press and hold the Liftgate Unlock
UNLOCK button simultaneously until
enabled, will require the user to
button on the smart key for more
the hazard warning lights blink.
press the door unlock button once for
than one second. The hazard
driver door only and twice for unlock-
This will enable or disable the Two
warning lights will blink two times
ing all the doors.
Press Unlock feature. Repeat this
and the liftgate latch will unlock.
procedure to enable/disable the
mode again.
Select or Deselect the Two Press
NOTICE
Unlock Feature in the User Settings
The liftgate must be operated
menu in the LCD cluster display. The
i
Information
manually to open the liftgate.
option can be found under the follow-
• The door handle buttons will only
Once the liftgate latch is
ing menu:
operate when the smart key is with-
unlocked, pull upward on the lift-
in 28-40 inches (0.7~1m) from the
gate handle to fully open the lift-
USER SETTINGS ➞ DOOR ➞ TWO
outside door handle
gate.
PRESS UNLOCK
• Either the driver or front passenger
door can be opened with the door
3. Once the liftgate is opened and
handle button when the smart key is
then closed, the liftgate will lock
within this range
automatically.
• If you press the front passenger out-
side door handle with the smart key
in your possession, all the doors will
unlock
3-8
Panic button
Mechanical key
i
Information
Press and hold the Panic button (4)
If the Smart Key does not operate
• The liftgate handle button will only
for more than one second. The horn
normally, you can lock or unlock the
operate when the smart key is with-
sounds and hazard warning lights
driver's door by using the mechanical
in 28 inches (0.7 m) from the liftgate
blink for about 30 seconds. To cancel
key.
handle.
the panic mode, press any button on
• The Liftgate Unlock button (3) will
the Smart Key.
only unlock the liftgate. It will not
3
release the latch and open the lift-
Start-up
gate automatically. If the Liftgate
You can start the vehicle without
Unlock button is used, someone
inserting the key.
must still press the liftgate handle
For information, refer to the
button to open the liftgate.
"Engine Start/Stop Button" sec-
tion in chapter 5.
NOTICE
OPD046045
To prevent damaging the smart key:
• Keep the smart key in a cool, dry
To remove the mechanical key from
place to avoid damage or mal-
the smart key FOB, slide the release
function. Exposure to moisture
lever in the direction of the arrow (1)
or high temperature may cause
and then pull the mechanical key (2)
the internal circuit of the smart
outward.
key to malfunction which may
To unlock the vehicle using the
not be covered under warranty.
mechanical key. insert the mechani-
• Avoid dropping or throwing the
cal key into the key hole in the driver
smart key.
door.
• Protect the smart key from
To reinstall the mechanical key into
extreme temperatures.
the FOB, insert the key in the top of
the key FOB and push inward until a
click sound is heard.
3-9
Convenient features of your vehicle
Loss of a smart key
If the smart key is in close proximity
i
Information
to your mobile phone, the signal
A maximum of two Smart Keys can
could be blocked by your mobile
This device complies with Part 15 of
be registered to a single vehicle. If
phone's normal operational signals.
the FCC rules.
you happen to lose your smart key,
This is specifically relevant when the
Operation is subject to the following
you should immediately take the
phone is active such as making and
three conditions:
vehicle and remaining keys to your
receiving calls, text messaging,
authorized HYUNDAI dealer or tow
1. This device may not cause harmful
and/or sending/receiving emails.
the vehicle, if necessary.
interference.
When possible, avoid keeping the
2. This device must accept any inter-
remote key and your mobile phone in
ference received, including interfer-
Smart key precautions
the same location such as a pants or
ence that may cause undesired
The smart key may not work if any of
jacket pocket in order to avoid inter-
operation.
the following occur:
ference between the two devices.
3.
Changes or modifications not
• The smart key is close to a radio
expressly approved by the party
NOTICE
transmitter such as a radio station
responsible for compliance could
or an airport which can interfere
Keep the smart key away from
void the user's authority to operate
with normal operation of the trans-
electromagnetic materials that
the device.
mitter.
blocks electromagnetic waves to
• The smart key is near a mobile two
the key surface.
way radio system or a cellular
phone.
NOTICE
• Another vehicle's smart key is being
Always have the smart key with
operated close to your vehicle.
you when leaving the vehicle. If
If the smart key does not work cor-
the smart key is left near the vehi-
rectly, open and close the door with
cle, the vehicle battery may be dis-
the mechanical key. If you have a
charged.
problem with the smart key, contact
an authorized HYUNDAI dealer.
3-10
Battery replacement
If you suspect your smart key might
Immobilizer System
have sustained some damage, or
(if equipped)
you feel your smart key is not work-
The immobilizer system protects
ing correctly, contact an authorized
your vehicle from theft. If an improp-
HYUNDAI dealer.
erly coded key (or other device) is
used, the engine's fuel system is dis-
i
Information
abled.
3
When the ignition switch is placed in
An inappropriately disposed
the ON position, the immobilizer sys-
battery can be harmful to the
tem indicator should come on briefly,
environment and human
then go off. If the indicator starts to
health. Dispose of the battery
blink, the system does not recognize
according to your local law(s)
OPD046046
the coding of the key.
or regulations.
Turn the ignition switch to the
If the Smart Key is not working prop-
erly, try replacing the battery with a
LOCK/OFF position, then turn the
ignition switch to the ON position
new one.
again.
Battery Type: CR2032
In some circumstances, the vehicle
To replace the battery:
may not recognize your smart key if
1. Remove the mechanical key.
another smart key device is nearby
2. Use a slim tool to pry open the
or a metal object such as a key chain
rear cover of the smart key.
is causing interference with the
smart key.
3. Remove the old battery and insert
the new battery. Make sure the
If this occurs, your vehicle may not
battery position is correct.
start. Remove any metal objects or
additional keys near the smart key
4. Reinstall the rear cover of the
before attempting to start the vehicle
smart key.
again.
3-11
Convenient features of your vehicle
If the system repeatedly does not
NOTICE
i
Information
recognize the coding of the key, it is
recommended that you contact your
The transponder in your key is an
This device complies with Part 15 of
HYUNDAI dealer.
important part of the immobilizer
the FCC rules.
system. It is designed to give
Do not attempt to alter this system or
Operation is subject to the following
years of trouble-free service, how-
add other devices to it. Electrical
three conditions:
ever you should avoid exposure to
problems could result that may make
1. This device may not cause harmful
moisture, static electricity and
your vehicle inoperable.
interference.
rough handling. Immobilizer sys-
tem malfunction could occur.
2. This device must accept any inter-
ference received, including interfer-
WARNING
ence that may cause undesired
operation.
In order to prevent theft of your
vehicle, do not leave spare keys
3. Changes or modifications not
anywhere in your vehicle. Your
expressly approved by the party
immobilizer password is a cus-
responsible for compliance could
tomer unique password and
void the user's authority to operate
should be kept confidential.
the device.
3-12
DOOR LOCKS
Operating Door Locks from
If you unlock the driver's door with a
Remote key
Outside the Vehicle
mechanical key, you can open and
close the driver’s door only.
Mechanical key
Once the doors are unlocked, they
■ Smart key
may be opened by pulling the door
handle. When closing the door, push
the door by hand. Make sure that
doors are closed securely.
3
OPD047001N
To lock the doors, press the Door
OJS048002
Lock button (1) on the remote key.
■ Remote key
Press the Door Unlock button (2) on
the remote key, the driver's door will
unlock. If you press the Door Unlock
button on the remote key again with-
in four seconds, then all the doors
will unlock.
Once the doors are unlocked, they
may be opened by pulling the door
handle.
When closing the door, push the
door by hand. Make sure that doors
OJS048002L
are closed securely.
If you lock the driver's door with a
mechanical key, all vehicle doors will
lock.
3-13
Convenient features of your vehicle
Smart key
If you press the button on the front
Operating Door Locks from
passenger's outside door, all doors
Inside the Vehicle
will unlock.
With the door lock button
Once the doors are unlocked, they
may be opened by pulling the door
handle.
When closing the door, push the
door by hand. Make sure that doors
Lock / Unlock
are closed securely.
i
Information
•
In cold and wet climates, door lock
OJS048001
and door mechanisms may not work
properly due to freezing conditions.
Door
Door
OJS048004N
•
If the door is locked/unlocked multi-
Lock
Unlock
ple times in rapid succession with
•
To unlock a door, push the door
either the vehicle key or door lock
lock button (1) to the "Unlock" posi-
switch, the system may stop operat-
tion. The red mark (2) on the door
ing temporarily in order to protect
lock button will be visible.
the circuit and prevent damage to
•
To lock a door, push the door lock
system components.
button (1) to the "Lock" position. If
•
Two press unlock setting can be
the door is locked properly, the red
changed in the User Settings mode
mark (2) on the door lock button
on the cluster.
will not be visible.
OPD046004
•
To open a door, pull the door han-
Press the button on the driver's out-
dle (3) outward.
side door handle while carrying the
Smart Key with you or press the
Door Unlock button on the Smart
Key, the driver's door will unlock.
3-14
•
If the inner door handle of either
With the central door lock
i
Information
the driver door or passenger door
switch
is pulled when the door lock button
If a power door lock ever fails to func-
is in the lock position, the button is
tion while you are in the vehicle try
unlocked and the door will open.
one or more of the following tech-
niques to exit:
•
For Key Start Vehicles
(Remote
Key)
•
Operate the door unlock feature
repeatedly
(both electronic and
The front doors cannot be locked if
3
manual) while simultaneously
the remote key is in the ignition
pulling on the door handle.
switch and either of the front doors
are open.
•
Operate the other door locks and
handles, front and rear.
•
For Push Button Start Vehicles
(Smart Key)
•
Lower a front window and use the
mechanical key to unlock the door
The doors cannot be locked if the
OJS048005N
from outside.
smart key fob is inside the vehicle
The driver side door armrest is
and any of the doors are open.
equipped with a central door lock
switch. The lock button is indicated
by a (
) symbol. The unlock button
is indicated by a (
) symbol.
When the lock button (1) is pressed,
all the vehicle doors will lock.
When the unlock button
(2) is
pressed, all the vehicle doors will
unlock.
3-15
Convenient features of your vehicle
• For Key Start Vehicles
WARNING
WARNING
(Remote key)
If the key is in the ignition switch
Do not leave children or animals
Always secure your vehicle.
and any door is opened, the doors
unattended in your vehicle. An
Leaving your vehicle unlocked
will not lock even though the lock
enclosed vehicle can become
increases the potential risk to
button (2) is pressed.
extremely hot, causing death or
you or others from someone
• For Push Button Start Vehicles
serious injury to unattended
hiding in your vehicle.
(Smart Key)
children or animals who cannot
To secure your vehicle, while
If the smart key is in the vehicle
escape the vehicle. Children
depressing the brake, move the
and any door is open, the doors
might operate features of the
shift lever to the P (Park) posi-
will not lock even though the lock
vehicle that could injure them,
tion, engage the parking brake,
button (2) is pressed.
or they could encounter other
and place the ignition switch in
harm, possibly from someone
the LOCK/OFF position, close
gaining entry to the vehicle.
WARNING
all windows, lock all doors, and
always take the key with you.
• The doors should always be
fully closed and locked while
the vehicle is in motion. If the
CAUTION
doors are unlocked, the risk of
being thrown from the vehicle
Opening a door when something
in a crash is increased.
is approaching may cause dam-
• Do not pull the inner door
age or injury. Be careful when
handle of the driver's or pas-
opening doors and watch for
senger's door while the vehi-
vehicles, motorcycles, bicycles
cle is moving.
or pedestrians approaching the
vehicle in the path of the door.
3-16
