Automatic-Dimming Night Vision

The auto-dimming function can be

Safety™ (NVS®) Mirror

controlled by pressing the ON/OFF

(if equipped)

button:

The NVS® Mirror automatically

reduces glare by monitoring light lev-

1. Pressing the button turns the auto-

els in the front and the rear of the

dimming function OFF which is

vehicle. Any object that obstructs

indicated by the green Status

either light sensor will degrade the

3

Indicator LED turning off.

automatic dimming control feature.

2. Pressing the button again turns

the auto-dimming function ON

For more information regarding

which is indicated by the green

OAD045046N

NVS® mirrors and other applica-

Status Indicator LED turning on.

tions, please refer to the Gentex

(1) Channel 1 button

The mirror defaults to the ON posi-

website:

(2) Channel 2 button

tion each time the vehicle is started.

www.gentex.com

(3) Status indicator LED

(4) Channel 3 button

Z-Nav™ Compass Display

(5) Rear light sensor

The NVS™ Mirror in your vehicle is

(6) Dimming ON/OFF button

also equipped with a Z-Nav™

Compass that shows the vehicle

(7) Compass control button

Compass heading in the Display

(8) Compass display

Window using the 8 basic cardinal

headings (N, NE, E, SE, etc.).

3-27

Convenient features of your vehicle

Compass function

The Compass can be turned ON and

OFF and will remember the last state

when the vehicle is cycled. To turn

the display feature ON/OFF:

1. Press and release the button to

turn the display feature OFF.

2. Press and release the

button

again to turn the display back ON.

Additional options can be set with

press and hold sequences of the but-

ton and are detailed below.

There is a difference between mag-

netic north and true north. To com-

pensate for this difference you will

need to adjust the Zone setting

based on where you live.

B520C05NF

3-28

To adjust the Zone setting:

There are some conditions that can

If you need to recalibrate the com-

cause changes to the vehicle mag-

pass:

1. Determine the desired Zone

nets, such as installing a ski rack or

Number based upon your current

1. Press and hold the

button for

a CB antenna. Body repair work on

location on the Zone Map.

more than 6 seconds. When the

the vehicle can also cause changes

compass memory is cleared a "C"

2. Press and hold the

button for

to the vehicle’s magnetic field. In

will appear in the display.

more than 3 but less than 6 sec-

these situations, the compass will

onds, the current Zone Number

2. Drive the vehicle in 2 complete cir-

need to be re-calibrated to quickly

will appear on the display.

cles at less than 5 mph (8 km/h).

3

correct these changes.

3. Pressing and holding the button

again will cause the numbers to

increment (Note: they will repeat

…13, 14, 15, 1, 2, …). Releasing

the button when the desired Zone

Number appears on the display

will set the new Zone.

4. Within about 5 seconds the com-

pass will start displaying a com-

pass heading again.

3-29

Convenient features of your vehicle

Integrated HomeLink® Wireless

Programming HomeLink®

WARNING

Control System

Please note the following:

The HomeLink® Wireless Control

Before programming HomeLink®

•

When programming a garage door

System can replace up to three hand-

to a garage door opener or gate

opener, it is advised to park the

held radio-frequency (RF) transmit-

operator, make sure people and

vehicle outside of the garage.

ters with a single built-in device. This

objects are out of the way of the

•

It is recommended that a new bat-

innovative feature will learn the radio

device to prevent potential harm

tery be placed in the hand-held

frequency codes of most current

or damage. Do not use the

transmitter of the device being pro-

transmitters to operate devices such

HomeLink® with any garage door

grammed to HomeLink® for quicker

as gate operators, garage door open-

opener that lacks the safety stop

training and accurate transmission

ers, entry door locks, security sys-

and reverse features required by

of the radio-frequency signal.

tems, even home lighting. Both stan-

U.S. federal safety standards (this

dard and rolling code-equipped trans-

•

Some vehicles may require the

includes any garage door opener

mitters can be programmed by fol-

POWER button to be placed in the

model manufactured before April

lowing the outlined procedures.

ACC (or "Accessories") position for

1, 1982). A garage door that can-

programming and/or operation of

Additional HomeLink® information

not detect an object - signaling

HomeLink®.

can be found at: www.homelink.com

the door to stop and reverse -

•

In the event that there are still pro-

or by calling 1-800-355-3515.

does not meet current U.S. feder-

gramming difficulties or questions

Retain the original transmitter of the

al safety standards. Using a

after following the programming

RF device you are programming for

garage door opener without

steps listed below, contact

use in other vehicles as well as for

these features increases the risk

HomeLink®homelwww.homelink.com

future HomeLink® programming. It is

of serious injury or death.

or by calling 1-800-355-3515.

also suggested that upon the sale of

the vehicle, the programmed

HomeLink® buttons be erased for

security purposes.

3-30

Reprogramming a single

Erasing HomeLink® buttons

i

Information

HomeLink® button

Individual buttons cannot be erased.

This device complies with Part 15 of

To program a new device to a previ-

However, to erase all three pro-

the FCC Rules.

ously trained HomeLink® button, fol-

grammed buttons:

low these steps:

Operation is subject to the following

1. Press and hold the two outer

three conditions:

1. Press and hold the desired

HomeLink® buttons until the indi-

HomeLink® button. Do NOT

cator light begins to flash-after 20

1. This device may not cause harmful

release until step 4 has been com-

seconds.

interference, and

3

pleted.

2. This device must accept any interfer-

2. Release both buttons. Do not hold

2. When the indicator light begins to

for longer than 30 seconds.

ence received, including interference

flash slowly

(after

20 seconds),

that may cause undesired operation.

The Integrated HomeLink® Wireless

position the handheld transmitter 1

3. The transceiver has been tested and

Control System is now in the training

to

3 inches away from the

complies with FCC and Industry

(learn) mode and can be pro-

HomeLink® surface.

Canada rules. Changes or modifica-

grammed at any time following the

3. Press and hold the handheld

appropriate steps in the Programming

tions not expressly approved by the

transmitter button. The HomeLink®

chapters above.

party responsible for compliance

indicator light will flash, first slowly

could void the user’s authority to

and then rapidly.

operate the device.

NVS® is a registered trademark and

4. When the indicator light begins to

Z-Nav™ is a trademark of the Gentex

flash rapidly, release both buttons.

Corporation, Zeeland, Michigan.

5. Press and hold the just-trained

HomeLink® is a registered trademark

HomeLink® button and observe

owned by Johnson Controls,

the red Status Indicator LED. If the

Incorporated, Milwaukee, Wisconsin.

indicator light stays on constantly,

FCC ID: NZLZTVHL3

programming is complete and

IC: 4112A-ZTVHL3

your new device should activate.

3-33

Convenient features of your vehicle

Side View Mirrors

Use your interior side view mirror or

Blind spot mirror

direct observation to determine the

actual distance of following vehicles

when changing lanes.

WARNING

Do not adjust or fold the side

view mirrors while driving. This

may cause loss of vehicle con-

trol resulting in an accident.

OLF044477N

OAE046013

NOTICE

Be sure to adjust mirror angles

• Do not scrape ice off the mirror

before driving.

face; this may damage the sur-

Your vehicle is equipped with both

face of the glass.

left-hand and right-hand side view

• If the mirror is jammed with ice,

mirrors. The mirrors can be adjusted

do not adjust the mirror by

remotely with the remote switch. The

force. Use an approved spray

mirror heads can be folded to pre-

de-icer (not radiator antifreeze)

vent damage during an automatic

spray, or a sponge or soft cloth

OLF044478N

car wash or when passing through a

with very warm water, or move

narrow street.

The Blind Spot Mirror (BSM) is a

the vehicle to a warm place and

The right side view mirror is convex.

allow the ice to melt.

supplemental mirror that reduces the

driver’s blind spot by showing the

Objects seen in the mirror are closer

than they appear.

rear side area of the vehicle. The

blind spot mirror is equipped on the

left-hand side view mirror.

3-34

Side view mirror control

NOTICE

WARNING

•

The mirrors stop moving when

• Always check the road condi-

they reach the maximum adjust-

tion while driving for unex-

ing angles, but the motor contin-

pected situations even though

ues to operate while the switch

the vehicle is equipped with a

is pressed. Do not press the

blind spot mirror.

switch longer than necessary,

3

the motor may be damaged.

• The blind spot mirror is a

device made for convenience.

•

Do not attempt to adjust the side

Do not solely rely on the mir-

view mirrors by hand or the

ror but always pay attention to

motor may be damaged.

traffic around you.

OAE046014

Adjusting the side mirrors:

NOTICE

1. Press either the L (driver's side) or

Do not clean the mirror with harsh

R (passenger's side) button (1) to

abrasives, fuel or other petroleum

select the side view mirror you

based cleaning products.

would like to adjust.

2. Use the mirror adjustment control

switch to position the selected mir-

ror up, down, left or right.

3. After adjustment, put the button

into neutral

(center) position to

prevent inadvertent adjustment.

3-35

Convenient features of your vehicle

Folding the side view mirrors

NOTICE

The electric type outside rearview

mirror operates even though the

POWER button is in the OFF posi-

tion. However, to prevent unnec-

essary battery discharge, do not

adjust the mirrors longer than

necessary while the vehicle is not

in the ready (

) mode.

NOTICE

OAE046016

Electric type (if equipped)

Do not fold the electric type side

OAE046015

view mirror by hand. It could

Left : The mirror will unfold.

Manual type (if equipped)

cause motor failure.

Right : The mirror will fold.

To fold the side view mirrors, grasp

the housing of the mirror and then

Center (AUTO) : The mirror will fold

or unfold automatically as follows:

fold it toward the rear of the vehicle.

- The mirror will fold or unfold when

the door is locked or unlocked by

the smart key.

- The mirror will fold or unfold when

the door is locked or unlocked by

the button on the outside door han-

dle.

3-36

Reverse Parking Aid Function

The side view mirrors will automati-

(if equipped)

cally revert to their original positions if

any of the following occur:

• The POWER button is placed to

either the OFF position or the ACC

position.

• The vehicle is shifted to any posi-

tion except R (Reverse).

3

• The remote control side view mir-

ror switch is not selected.

OAEE046512N

When you shift the vehicle to R

(Reverse) position, the side view mir-

ror(s) will rotate downwards to aid

with driving in reverse. The position

of the side view mirror switch

(1)

determines whether or not the mir-

rors will move:

Left/Right : When either the L (Left) or

R (Right) switch is select-

ed, both side view mirrors

will move.

Neutral : When neither switch is select-

ed, the side view mirrors will

not move.

3-37

Convenient features of your vehicle

WINDOWS

(1) Driver’s door power window

switch

(2) Front passenger’s door power

window switch

(3) Rear door (left) power window

switch

(4) Rear door (right) power window

switch

(5) Window opening and closing

(6) Automatic power window

(7) Power window lock switch

OAEE046508N

3-38

Power Windows

Window opening and closing

i

Information

The POWER button must be in the

•

In cold and wet climates, power win-

ON position to be able to raise or

dows may not work properly due to

lower the windows. Each door has a

freezing conditions.

Power Window switch to control that

•

While driving with the rear win-

door’s window. The driver has a

dows down or with the sunroof (if

Power Window Lock switch which

equipped) opened

(or partially

can block the operation of passenger

3

opened), your vehicle may demon-

windows. The power windows will

strate a wind buffeting or pulsation

operate for approximately

30 sec-

noise. This noise is normal and can

onds after the POWER button is

be reduced or eliminated by taking

placed in the ACC or OFF position.

the following actions. If the noise

However, if the front doors are

occurs with one or both of the rear

OAE046020

opened, the Power Windows cannot

windows down, partially lower both

be operated even within the 30 sec-

To open:

front windows approximately 1 inch

ond period.

Press the window switch down to the

(2.5 cm). If you experience the noise

first detent position (5). Release the

with the sunroof open, slightly close

switch when you want the window to

WARNING

the sunroof.

stop.

To avoid serious injury or death,

do not extend your head, arms

To close:

or body outside the windows

Pull the window switch up to the first

while driving.

detent position (5). Release the win-

dow switch when you want the win-

dow to stop.

3-39

Convenient features of your vehicle

Auto up/down window

To reset the power windows

Automatic reverse (if equipped)

(if equipped)

If the power windows do not operate

Pressing or pulling up the power win-

normally, the automatic power win-

dow switch momentarily to the sec-

dow system must be reset as follows:

ond detent position

(6) completely

1. Place the POWER button to the

lowers or lifts the window even when

ON position.

the switch is released. To stop the

2. Close the window and continue

window at the desired position while

pulling up on the power window

the window is in operation, pull up or

switch for at least one second.

press down and release the switch.

If the power windows do not operate

properly after resetting, have the

system checked by an authorized

HYUNDAI dealer.

OLF044032

If a window senses any obstacle while

it is closing automatically, it will stop

WARNING

and lower approximately 12 inches (30

cm) to allow the object to be cleared.

The automatic reverse feature

doesn't activate while resetting

If the window detects the resistance

the power window system.

while the power window switch is

Make sure body parts or other

pulled up continuously, the window

objects are safely out of the way

will stop upward movement then

before closing the windows to

lower approximately 1 inch (2.5 cm).

avoid injuries or vehicle dam-

If the power window switch is pulled

age.

up continuously again within 5 sec-

onds after the window is lowered by

the automatic window reverse fea-

ture, the automatic window reverse

will not operate.

3-40

Power window lock switch

i

Information

WARNING

The automatic reverse feature is only

active when the "Auto Up" feature is

Do not allow children to play

used by fully pulling up the switch to

with the power windows. Keep

the second detent.

the driver's door power window

lock switch in the LOCK posi-

WARNING

tion. Serious injury or death can

3

result from unintentional win-

Make sure body parts or other

dow operation by a child.

objects are safely out of the way

before closing the windows to

NOTICE

avoid injuries or vehicle damage.

OAE046021

•

To prevent possible damage to

Objects less than 0.16 inch (4 mm)

the power window system, do

in diameter caught between the

The driver can disable the power

not open or close two windows

window glass and the upper win-

window switches on the rear passen-

or more at the same time. This

dow channel may not be detected

ger's doors by pressing the power

will also ensure the longevity of

by the automatic reverse window

window lock switch.

the fuse.

and the window will not stop and

When the power window lock switch

reverse direction.

•

Never try to operate the main

is pressed:

switch on the driver's door and

• The driver's master control can

the individual door window

NOTICE

operate all the power windows.

switch in opposite directions at

• The front passenger's control can

the same time. If this is done, the

Do not install any accessories on

operate the front passenger's power

window will stop and cannot be

the windows. The automatic

window.

opened or closed.

reverse feature may not operate.

• The rear passenger's control can-

not operate the rear passenger's

power window.

3-41

Convenient features of your vehicle

SUNROOF (IF EQUIPPED)

i

Information

(Continued)

• In cold and wet climates, the sun-

• Do not leave the vehicle on

roof may not work properly due to

and the key in your vehicle

freezing conditions.

with unsupervised children.

Unattended children could

• After the vehicle is washed or in a

operate the sunroof, which

rainstorm, be sure to wipe off any

could result in serious injury.

water that is on the sunroof before

operating it.

• Do not sit on the top of the

vehicle. It may cause injuries

or vehicle damage.

WARNING

OAD045022

If your vehicle is equipped with a

•

Never adjust the sunroof or

NOTICE

sunroof, you can slide or tilt your

sunshade while driving. This

• Do not continue to move the

sunroof with the sunroof control

could result in loss of control

sunroof control lever after the

switch located on the overhead con-

and an accident that may

sunroof is fully opened, closed,

sole.

cause death, serious injury, or

or tilted. Damage to the motor or

The sunroof can be opened, closed,

property damage.

system components could

or tilted when the POWER button is

•

Make sure heads, other body

occur.

in the ON position.

parts or objects are out of the

• Make sure the sunroof is closed

The sunroof can be operated for

way before using the sunroof.

fully when leaving your vehicle.

approximately 30 seconds after the

•

Do not extend your head,

If the sunroof is open, rain or

POWER button is in the ACC or OFF

arms or body outside the sun-

snow may leak through the sun-

position.

roof while driving, to avoid

roof and wet the interior as well

However, if the front door is opened,

serious injury.

as cause theft.

the sunroof cannot be operated even

(Continued)

within 30 seconds.

3-42

Sunroof opening and closing

Sliding the sunroof

Automatic reverse (if equipped)

Pressing the sunroof control lever

backward or forward momentarily to

the second detent position complete-

ly opens or closes the sunroof even

when the switch is released. To stop

the sunroof at the desired position

while the sunroof is in operation,

3

press the sunroof control lever back-

ward or forward and release the

switch.

OAD045023

i

Information

OLFC044035CN

To open:

To minimize wind noise while driving,

If the sunroof senses any obstacle

it is recommended that you drive with

while it is closing automatically, it will

Press the sunroof control lever back-

the sunroof slightly closed (stop the

reverse direction then stop to allow

ward to the first detent position.

sunroof about 3 inch (7 cm) before the

the object to be cleared.

Release the switch when you want

maximum slide open position).

the sunroof to stop.

The auto reverse function does not

work if a small obstacle is between

To close:

the sliding glass and the sunroof

Press the sunroof control lever forward

sash.

to the first detent position. Release the

You should always check that all pas-

switch when you want the sunroof to

sengers and objects are away from

stop.

the sunroof before closing it.

3-43

Content   ..  5  6  7  8   ..
