Safety system of your vehicle
Air bag non-inflation conditions
OPD036055
OPD036056
Front air bags are not designed to
Front air bags may not inflate in side
OPD036054
inflate in rear collisions, because
impact collisions, because occupants
In certain low-speed collisions the air
occupants are moved backward by
move in the direction of the collision,
bags may not deploy. The air bags
the force of the impact. In this case,
and thus in side impacts, front air bag
are designed not to deploy in such
inflated air bags would not provide
deployment would not provide addi-
cases because they may not provide
any additional benefit.
tional occupant protection.
benefits beyond the protection of the
However, side and curtain air bags
seat belts.
may inflate depending on the severity,
vehicle speed and angles of impact.
2-60
2
OTL035069
OPD036057
OTL035068
In an angled collision, the force of
Just before impact, drivers often
Front air bags may not inflate in
impact may direct the occupants in a
brake heavily. Such heavy braking
rollover accidents because front air
direction where the air bags would
lowers the front portion of the vehicle
bag deployment would not provide
not be able to provide any additional
causing it to “ride” under a vehicle
additional occupant protection.
benefit, and thus the sensors may
with a higher ground clearance. Air
not deploy any air bags.
bags may not inflate in this "under-
i
Information
ride" situation because deceleration
forces that are detected by sensors
• Vehicles equipped with rollover sensor
may be significantly reduced by such
The side and curtain air bags may
“underride” collisions.
inflate in a rollover situation, when it is
detected by the rollover sensor.
• Vehicles not equipped with rollover
sensor
The side and/or curtain air bags may
inflate when the vehicle is rolled over
by a side impact collision, if the vehicle
is equipped with side and/or curtain
air bags.
2-61
Safety system of your vehicle
SRS care
(Continued)
The SRS is virtually maintenance-
•
Do not place objects over or
free and there are no parts you can
near the air bag modules on the
safely service by yourself. If the SRS
steering wheel, instrument
air bag warning light does not illumi-
panel, and the front passenger's
nate when the ignition switch is in the
panel above the glove box.
ON position, or continuously remains
•
Clean the air bag pad covers
on, we recommend that the system
with a soft cloth moistened
be immediately inspected by an
with plain water. Solvents or
authorized HYUNDAI dealer.
cleaners could adversely affect
We recommend any work on the SRS
OPD036058
the air bag covers and proper
system, such as removing, installing,
deployment of the system.
Air bags may not inflate if the vehicle
repairing, or any work on the steering
•
We recommend that inflated
collides with objects such as utility
wheel, the front passenger's panel,
air bags be replaced by an
poles or trees, where the point of
front seats and roof rails be performed
authorized HYUNDAI dealer.
impact is concentrated and the colli-
by an authorized HYUNDAI dealer.
sion energy is absorbed by the vehi-
Improper handling of the SRS system
•
If components of the air bag
cle structure.
may result in serious personal injury.
system must be discarded, or if
the vehicle must be scrapped,
certain safety precautions must
WARNING
be observed. Consult an author-
ized HYUNDAI dealer for the
To reduce the risk of serious
necessary information. Failure
injury or death take the follow-
to follow these precautions
ing precautions:
could increase the risk of per-
• Do not attempt to modify or
sonal injury.
disconnect the SRS compo-
nents or wiring, including the
addition of any kind of badges
to the pad covers or modifica-
tions to the body structure.
(Continued)
2-62
Additional safety precautions
Adding equipment to or modify-
Air bag warning labels
ing your air bag equipped vehicle
Passengers should not move out of
or change seats while the vehicle is
If you modify your vehicle by changing
moving. A passenger who is not
your vehicle's frame, bumper system,
2
wearing a seat belt during a crash or
front end or side sheet metal or ride
emergency stop can be thrown
height, this may affect the operation of
against the inside of the vehicle,
your vehicle's air bag system.
against other occupants, or be ejected
from the vehicle.
Do not use any accessories on seat
belts. Devices claiming to improve
occupant comfort or reposition the
seat belt can reduce the protection
OAD035053
provided by the seat belt and increase
Air bag warning labels are attached
the chance of serious injury in a crash
to alert the passengers of potential
Do not modify the front seats.
risks of the air bag system.
Modification of the front seats could
Be sure to read all of the information
interfere with the operation of the sup-
about the air bags that are installed on
plemental restraint system sensing
your vehicle in this Owner’s Manual.
components or side air bags.
Do not place items under the front
seats. Placing items under the front
seats could interfere with the opera-
tion of the supplemental restraint sys-
tem sensing components and wiring
harnesses.
Do not cause impact to the doors.
Impact to the doors when the ignition
switch is in the ON position may cause
the air bags to inflate.
2-63
Convenient features of your vehicle
Accessing your vehicle
3-3
Panorama sunroof
3-32
Remote key
3-3
Sunshade
3-33
Smart key
3-6
Sliding the sunroof
3-33
Immobilizer system
3-10
Tilting the sunroof
3-34
DOOR LOCKS
3-11
Closing the sunroof
3-34
Operating door locks from outside the vehicle
3-11
Resetting the sunroof
3-35
Operating door locks from inside the vehicle
3-12
Sunroof open warning
3-36
Auto door lock/unlock features
3-14
Exterior features
3-37
3
Child-protector rear door locks
3-15
Hood
3-37
Theft-alarm system
3-16
Tailgate
3-38
Driver position memory system
3-17
Fuel filler door
3-40
Storing memory positions
3-17
Instrument cluster
3-43
Recalling memory positions
3-17
Instrument cluster control
3-44
Easy access function
3-18
Gauges and meters
3-45
Transmission shift indicator
3-48
Steering wheel
3-19
Manual transmission shift indicator
3-48
Electric power steering (EPS)
3-19
Warning and indicator lights
3-51
Tilt steering / Telescope steering
3-20
LCD display messages
3-65
Heated steering wheel
3-21
Horn
3-21
LCD Display
3-71
Mirrors
3-22
LCD display control
3-71
LCD modes
3-72
Inside rearview mirror
3-22
Outside rearview mirror
3-23
Trip computer
3-79
Reverse parking aid function
3-26
Trip modes
3-79
Windows
3-27
Light
3-83
Power windows
3-27
Exterior lights
3-83
Manual windows
3-31
Static bending light
3-92
Welcome system
3-92
Interior lights
3-93
Climate control additional features
3-137
Wipers and washers
3-97
Cluster ionizer
3-137
Windshield wipers
3-98
Automatic ventilation
3-137
Windshield washers
3-99
To cancel or set the automatic ventilation
3-137
Rear window wiper and washer switch
3-100
Sunroof inside air recirculation
3-137
Driver assist system
3-101
Storage compartment
3-138
3
Rear view camera
3-101
Center console storage
3-138
Rear parking assist system
3-102
Glove box
3-138
Parking assist system
3-106
Sunglass holder
3-139
Defroster
3-109
Multi box
3-139
Rear window defroster
3-109
Interior features
3-140
Manual climate control system
3-111
Ashtray
3-140
Heating and air conditioning
3-112
Cup holder
3-140
System operation
3-116
Sliding armrest
3-141
System maintenance
3-118
Sunvisor
3-142
Power outlet
3-142
Automatic climate control system
3-121
Cigarette lighter
3-144
Automatic heating and air conditioning
3-122
Wireless cellular phone charging system
3-144
Manual heating and air conditioning
3-123
Clock
3-146
System operation
3-128
Clothes hanger
3-146
System maintenance
3-131
Floor mat anchor(s)
3-147
Windshield defrosting and defogging
3-133
Luggage net (holder)
3-147
Manual climate control system
3-133
Cargo area cover
3-148
Automatic climate control system
3-134
Exterior features
3-149
Defogging logic
3-135
Mounting bracket for roof carrier
3-149
Auto defogging system
(only for automatic climate control system)
3-136
ACCESSING YOUR VEHICLE
Remote key
Locking
Unlocking
To lock :
To unlock:
1. Close all doors, engine hood and
1. Press the Door Unlock button (2)
tailgate.
on the remote key.
2. Press the Door Lock button (1) on
2. The doors will unlock. The hazard
the remote key.
warning lights will blink two times.
Also, the outside rearview mirror
3. The doors will lock. The hazard
3
will unfold, if the outside rearview
warning lights will blink. Also, the
mirror folding switch is in the
outside rearview mirror will fold, if
AUTO position (if equipped).
the outside rearview mirror folding
switch is in the AUTO position (if
equipped).
i
Information
OPDE046001
4. Make sure the doors are locked by
After unlocking the doors, the doors
Your HYUNDAI uses a remote key,
checking the position of the door
will lock automatically after 30 sec-
which you can use to lock or unlock
lock button inside the vehicle.
onds unless a door is opened.
a door (and tailgate) and even start
the engine.
WARNING
1. Door Lock
Do not leave the keys in your
2. Door Unlock
vehicle with unsupervised chil-
3. Tailgate Unlock
dren. Unattended children
could place the key in the igni-
tion switch and may operate
power windows or other con-
trols, or even make the vehicle
move, which could result in
serious injury or death.
3-3
Convenient features of your vehicle
Tailgate unlocking
Start-up
Mechanical key
To unlock:
For detailed information refer to “Key
1. Press the Tailgate Unlock button
Ignition Switch” in chapter 5.
(3) on the remote key for more
than one second.
NOTICE
2. The hazard warning lights will
To prevent damaging the remote
blink two times.
key:
• Keep the remote key away from
i
Information
water or any liquid and fire. If the
inside of the remote key gets
The word "HOLD" is written on the
damp (due to drinks or mois-
button to inform you that you must
ture), or is heated, internal cir-
press and hold the button for more
OPDE046003
cuit may malfunction, excluding
than one second.
the car from the warranty.
If the remote key does not operate
normally, you can lock or unlock the
• Avoid dropping or throwing the
door by using the mechanical key.
remote key.
To unfold the key, press the release
• Protect the remote key from
button then the key will unfold auto-
extreme temperatures.
matically.
To fold the key, fold the key manually
while pressing the release button.
NOTICE
Do not fold the key without press-
ing the release button. This may
damage the key.
3-4
Remote key precautions
This is especially important when the
Battery replacement
phone is active such as making and
The remote key will not work if any of
If the remote key is not working prop-
receiving calls, text messaging,
the following occur:
erly, try replacing the battery with a
and/or sending/receiving emails.
new one.
• The key is in the ignition switch.
Avoid placing the remote key and your
• You exceed the operating distance
mobile phone in the same pants or
limit (about 30 m [90 feet]).
jacket pocket and always try to main-
• The remote key battery is weak.
tain an adequate distance between
3
the two devices.
• Other vehicles or objects may be
blocking the signal.
• The weather is extremely cold.
i
Information
• The remote key is close to a radio
Changes or modifications not express-
transmitter such as a radio station
ly approved by the party responsible
or an airport which can interfere
for compliance could void the user’s
with normal operation of the remote
authority to operate the equipment. If
key.
the keyless entry system is inoperative
OPD046002
due to changes or modifications not
When the remote key does not work
expressly approved by the party
Battery Type: CR2032
correctly, open and close the door
responsible for compliance, it will not
To replace the battery:
with the mechanical key. If you have a
be covered by your manufacturer’s
problem with the remote key, it is rec-
1. Insert a slim tool into the slot and
vehicle warranty.
ommended that you contact an
gently pry open the cover.
authorized HYUNDAI dealer.
2. Using a screw driver, remove the
NOTICE
If the remote key is in close proximity
battery cover.
to your mobile phone, the signal could
Keep the remote key away from
3. Remove the old battery and insert
be blocked by your mobile phones
electromagnetic materials that
a new battery. Make sure the bat-
normal operational signals.
blocks electromagnetic waves to
tery position is correct.
the key surface.
4. Reinstall the battery cover and key
cover in the reverse order of
removal.
3-5
Convenient features of your vehicle
If you suspect your remote key might
Smart key
Locking
have sustained some damage, or
you feel your remote key is not work-
ing correctly, it is recommended that
you contact an authorized HYUNDAI
dealer.
i
Information
An inappropriately disposed
battery can be harmful to the
environment and human
health. Dispose the battery
according to your local law(s)
OPDE046044
OPD046005
and regulation.
Your HYUNDAI uses a Smart Key,
To lock :
which you can use to lock or unlock
1. Close all doors, engine hood and
a door (and tailgate) and even start
tailgate.
the engine.
2. Either press the door handle but-
1. Door Lock
ton or press the Door Lock button
2. Door Unlock
(1) on the smart key.
3. Tailgate Unlock
3. The hazard warning lights will
blink. Also, the outside rearview
mirror will fold, if the outside
rearview mirror folding switch is in
the AUTO position (if equipped).
4. Make sure the doors are locked by
checking the position of the door
lock button inside the vehicle.
3-6
Unlocking
i
Information
i
Information
The door handle button will only
• The door handle button will only
operate when the smart key is within
operate when the smart key is with-
0.7~1 m (28~40 in.) from the outside
in 0.7~1 m (28~40 in.) from the out-
door handle.
side door handle. Other people can
also open the doors without the
smart key in possession.
Even though you press the outside
3
• After unlocking the doors, the doors
door handle button, the doors will not
will lock automatically after 30 sec-
lock and the chime will sound for
onds unless a door is opened.
three seconds if any of the following
occur:
• The Smart Key is in the vehicle.
Tailgate unlocking
OPD046005
• The Engine Start/Stop button is in
To unlock:
To unlock:
ACC or ON position.
1. Carry the smart key.
1. Carry the Smart Key.
• Any door except the tailgate is
2. Either press the tailgate handle
2. Either press the door handle but-
open.
button or press the Tailgate Unlock
ton or press the Door Unlock but-
button
(3) on the smart key for
ton (2) on the smart key.
WARNING
more than one second.
3. The doors will unlock. The hazard
3. The hazard warning lights will
Do not leave the Smart Key in
warning lights will blink two times.
blink two times.
your vehicle with unsupervised
Also, the outside rearview mirror
Once the tailgate is opened and then
children. Unattended children
will unfold, if the outside rearview
closed, the tailgate will lock automat-
could press the Engine Start/
mirror folding switch is in the AUTO
ically.
Stop button and may operate
position. (if equipped)
power windows or other con-
trols, or even make the vehicle
i
Information
move, which could result in
After unlocking the tailgate, the tail-
serious injury or death.
gate will lock automatically after 30
seconds unless the tailgate is opened.
3-7
Convenient features of your vehicle
Start-up
Mechanical key
Loss of a smart key
You can start the engine without
If the Smart Key does not operate
A maximum of two smart keys can
inserting the key. For detailed infor-
normally, you can lock or unlock the
be registered to a single vehicle. If
mation refer to the Engine
door by using the mechanical key.
you happen to lose your smart key, it
Start/Stop button in chapter 5.
is recommended that you should
immediately take the vehicle and
NOTICE
remaining key to your authorized
HYUNDAI dealer or tow the vehicle,
To prevent damaging the smart
if necessary.
key:
• Keep the smart key away from
water or any liquid and fire. If the
inside of the smart key gets
damp (due to drinks or moisture),
or is heated, internal circuit may
malfunction, excluding the car
OPD046045
from the warranty.
• Avoid dropping or throwing the
Move the release lever in the direc-
smart key.
tion of the arrow (1) and then remove
the mechanical key (2). Insert the
• Protect the smart key from
mechanical key into the key hole on
extreme temperatures.
the door.
To reinstall the mechanical key, put
the key into the hole and push it until
a click sound is heard.
3-8
Smart key precautions
Avoid placing the smart key and your
Battery replacement
mobile phone in the same pants or
The smart key will not work if any of
jacket pocket and always try to main-
the following occur:
tain an adequate distance between
• The smart key is close to a radio
the two devices.
transmitter such as a radio station
or an airport which can interfere
with normal operation of the trans-
i
Information
mitter.
3
Changes or modifications not express-
• The smart key is near a mobile two
ly approved by the party responsible
way radio system or a cellular
for compliance could void the user’s
phone.
authority to operate the equipment. If
the keyless entry system is inoperative
• Another vehicle’s smart key is
due to changes or modifications not
OPDE046046
being operated close to your vehi-
expressly approved by the party
cle.
If the Smart Key is not working prop-
responsible for compliance, it will not
When the smart key does not work
erly, try replacing the battery with a
be covered by your manufacturer’s
correctly, open and close the door
new one.
vehicle warranty.
with the mechanical key. If you have
Battery Type: CR2032
a problem with the smart key, it is
NOTICE
To replace the battery:
recommended that you contact an
authorized HYUNDAI dealer.
1. Pry open the rear cover of the
Keep the smart key away from
smart key.
If the smart key is in close proximity
electromagnetic materials that
2. Remove the old battery and insert
to your mobile phone, the signal
blocks electromagnetic waves to
could be blocked by your mobile
the key surface.
the new battery. Make sure the
battery position is correct.
phones normal operational signals.
This is especially important when the
3. Reinstall the rear cover of the
phone is active such as making and
smart key.
receiving calls, text messaging,
and/or sending/receiving emails.
3-9
Convenient features of your vehicle
If you suspect your smart key might
Immobilizer system
Do not attempt to alter this system or
have sustained some damage, or
(if equipped)
add other devices to it. Electrical
you feel your smart key is not work-
problems could result that may make
The immobilizer system protects your
ing correctly, it is recommended that
your vehicle inoperable.
vehicle from theft. If an improperly
you contact an authorized HYUNDAI
coded key (or other device) is used,
dealer.
the engine’s fuel system is disabled.
WARNING
When the ignition switch is placed in
i
Information
In order to prevent theft of your
the ON position, the immobilizer sys-
vehicle, do not leave spare keys
An inappropriately disposed
tem indicator should come on briefly,
anywhere in your vehicle. Your
battery can be harmful to the
then go off. If the indicator starts to
immobilizer password is a cus-
environment and human health.
blink, the system does not recognize
tomer unique password and
Dispose the battery according to
the coding of the key.
should be kept confidential.
your local law(s) and regulation.
Place the ignition switch to the
LOCK/OFF position, then place the
ignition switch to the ON position
NOTICE
again.
The transponder in your key is an
The system may not recognize your
important part of the immobilizer
key’s coding if another immobilizer
system. It is designed to give
key or other metal object (i.e., key
years of trouble-free service, how-
chain) is near the key. The engine
ever you should avoid exposure to
may not start because the metal may
moisture, static electricity and
interrupt the transponder signal from
rough handling. Immobilizer sys-
transmitting normally.
tem malfunction could occur.
If the system repeatedly does not
recognize the coding of the key, it is
recommended that you contact your
HYUNDAI dealer.
3-10
DOOR LOCKS
Operating door locks from
Remote key
Smart key
outside the vehicle
Mechanical key
■ Remote key
■ Smart key
Lock / Unlock
Unlock
Unlock
3
Lock
Lock
OPD046005
OPDE046413
To lock the doors, press the Door
Lock button (1) on the remote key.
OPD046006
To unlock the doors, press the Door
Turn the key toward the rear of the
Unlock button (2) on the remote key.
vehicle to unlock and toward the front
Once the doors are unlocked, they
of the vehicle to lock.
may be opened by pulling the door
If you lock/unlock the driver's door
handle.
with a key, all vehicle doors will
When closing the door, push the
lock/unlock automatically.
OPDE046004
door by hand. Make sure that doors
Once the doors are unlocked, they
are closed securely.
To lock the doors, press the button on
may be opened by pulling the door
the outside door handle while carry-
handle.
ing the smart key with you or press
When closing the door, push the
the door lock button on the smart key.
door by hand. Make sure that doors
are closed securely.
3-11
Convenient features of your vehicle
To unlock the doors, press the button
Operating door locks from
on the outside door handle while car-
inside the vehicle
rying the smart key with you or press
With the door handle
the door unlock button on the smart
key.
Once the doors are unlocked, they
may be opened by pulling the door
handle.
When closing the door, push the
door by hand. Make sure that doors
are closed securely.
OPDE046414
In case of an emergency
i
Information
If the power door lock does not oper-
•
In cold and wet climates, door lock
ate electrically, the only way to lock
and door mechanisms may not work
the door(s) is with the mechanical
OPDE046007
properly due to freezing conditions.
key from the outside key hole.
Front door
•
If the door is locked/unlocked multi-
Doors without the outside key hole,
ple times in rapid succession with
If the inner door handle is pulled
you can lock the door as follows:
either the vehicle key or door lock
when the door is locked, the door will
switch, the system may stop operat-
1. Open the door.
unlock and open.
ing temporarily in order to protect
2. Insert the key into the emergency
the circuit and prevent damage to
door lock hole and turn the key
Rear door
system components.
horizontally to lock.
If the inner door handle is pulled
3. Close the door securely.
once when the door is locked, the
door will unlock.
i
Information
If the inner door handle is pulled
Once the tailgate is closed when the
once more, the door will open.
power door lock switch does not oper-
ate electrically, you will not be able to
open the tailgate.
3-12
With the central door
i
Information
WARNING
lock/unlock switch
If a power door lock ever fails to func-
tion while you are in the vehicle try
Do not leave children or animals
one or more of the following tech-
unattended in your vehicle. An
niques to exit:
enclosed vehicle can become
extremely hot, causing death or
Operate the door unlock feature
serious injury to unattended
repeatedly (both electronic and manu-
3
children or animals who cannot
al) while simultaneously pulling on the
escape the vehicle. Children
door handle.
might operate features of the
Operate the other door locks and han-
vehicle that could injure them,
dles, front and rear.
or they could encounter other
Lower a front window and use the
harm, possibly from someone
mechanical key to unlock the door
gaining entry to the vehicle.
OPD046008
from outside.
•
With a door unlocked
- If you press the central door lock
WARNING
switch, all vehicle doors will lock
and the indicator light on the switch
The doors should always be
will illuminate.
fully closed and locked while
- If any door is opened when the
the vehicle is in motion. If the
switch is pressed, all doors will not
doors are unlocked, the risk of
lock.
being thrown from the vehicle in
a crash is increased.
•
With all doors locked
- If you press the central door unlock
switch, all vehicle doors will unlock.
- If any door is unlocked, the indica-
tor of the central door lock switch
will go off.
3-13
