Hyundai i10 (2016 year). Manual

What to do in an emergency

When towing your vehicle in an emer-

gency without wheel dollies:

1. Set the ignition switch in the ACC posi-

tion.

2. Place the transaxle shift lever in N

(Neutral).

3. Release the parking brake.

CAUTION

Failure to place the transaxle shift

lever in N (Neutral) may cause inter-

nal damage to the transaxle.

OBA063011

OBA063012

Removable towing hook (front)

3. Install the towing hook by turning it

(if equipped)

clockwise into the hole until it is fully

secured.

1. Open the tailgate, and remove the tow-

4. Remove the towing hook and install

ing hook from the tool bag.

the cover after use.

2. Remove the hole cover pressing the

lower part of the cover on the front

bumper.

6 16

What to do in an emergency

■ Front (if equipped)

Use extreme caution when towing the

vehicle. A driver must be in the vehicle to

CAUTION

steer it and operate the brakes.

• Attach a towing strap to the tow-

Towing in this manner may be done only

ing hook.

on hard-surfaced roads for a short dis-

• Using a portion of the vehicle

tance and at low speeds. Also, the

other than the tow hooks for tow-

wheels, axles, power train, steering and

ing may damage the body of your

brakes must all be in good condition.

vehicle.

•

Do not use the towing hooks to pull a

• Use only a cable or chain specifi-

vehicle out of mud, sand or other con-

cally intended for use in towing

OBA063012

ditions from which the vehicle cannot

vehicles. Securely fasten the

■ Rear

be driven out under its own power.

cable or chain to the towing hook

•

Avoid towing a vehicle heavier than the

provided.

vehicle doing the towing.

•

The drivers of both vehicles should

•

Before emergency towing, check that

communicate with each other frequent-

the hook is not broken or damaged.

ly.

•

Fasten the towing cable or chain

securely to the hook.

•

Do not jerk the hook. Apply it steadily

with even force.

OBA063013

•

To avoid damaging the hook, do not

Emergency towing

pull from the side or at a vertical angle.

If towing is necessary, we recommend

Always pull straight ahead.

you to have it done by an authorized

HYUNDAI dealer or a commercial tow

truck service.

If towing service is not available in an

emergency, your vehicle may be tem-

porarily towed using a cable or chain

secured to the emergency towing hook

under the front (or rear) of the vehicle.

6 17

What to do in an emergency

Emergency towing precautions

WARNING

•

Turn the ignition switch to ACC so the

Use extreme caution when towing

steering wheel isn’t locked.

the vehicle.

•

Place the transaxle shift lever in N

•

Avoid sudden starts or erratic

(Neutral).

driving maneuvers which would

•

Release the parking brake.

place excessive stress on the

•

Press the brake pedal with more force

emergency towing hook and tow-

than normal since you will have

ing cable or chain. The hook and

reduced brake performance.

towing cable or chain may break

•

More steering effort will be required

and cause serious injury or dam-

because the power steering system

age.

will be disabled.

OPA067014

•

If the disabled vehicle is unable

•

If you are driving down a long hill, the

to be moved, do not forcibly con-

•

Use a towing strap less than 5 m (16

brakes may overheat and brake per-

tinue the towing. Contact an

feet) long. Attach a white or red cloth

formance will be reduced. Stop often

authorized HYUNDAI dealer or a

(about 30 cm (12 inches) wide) in the

and let the brakes cool off.

commercial tow truck service for

middle of the strap for easy visibility.

assistance.

•

Drive carefully so that the towing strap

•

Tow the vehicle as straight ahead

is not loosened during towing.

as possible.

•

Keep away from the vehicle dur-

ing towing.

6 18

What to do in an emergency

CAUTION - Automatic

transaxle

•

If the vehicle is being towed with

all four wheels on the ground, it

can be towed only from the front.

Be sure that the transaxle is in

neutral. Do not tow at speeds

greater than

40 km/h (25 mph)

and for more than

25 km (15

miles). Be sure the steering wheel

is unlocked by placing the igni-

tion switch in the ACC position. A

driver must be in the towed vehi-

cle to operate the steering wheel

and brakes.

•

Before towing, check the level of

the automatic transaxle fluid. If it

is below the "HOT" range on the

dipstick, add fluid. If you cannot

add fluid, a towing dolly must be

used.

6 19

Maintenance

ENGINE COMPARTMENT

7-3

PARKING BRAKE

7-29

MAINTENANCE SERVICES

7-4

• Checking the parking brake

7-29

• Owner’s responsibility

7-4

AIR CLEANER

7-30

• Owner maintenance precautions

7-4

• Filter replacement

7-30

OWNER MAINTENANCE

7-6

CLIMATE CONTROL AIR FILTER

7-32

• Owner maintenance schedule

7-6

• Filter inspection

7-32

SCHEDULED MAINTENANCE SERVICE

7-8

• Filter replacement

7-32

• Normal maintenance schedule

7-9

WIPER BLADES

7-34

• Maintenance under severe usage conditions

7-13

• Blade inspection

7-34

EXPLANATION OF SCHEDULED

• Blade replacement

7-34

MAINTENANCE ITEMS

7-19

BATTERY

7-38

ENGINE OIL

7-19

• For best battery service

7-38

• Checking the engine oil level

7-19

• Battery capacity label

7-39

• Changing the engine oil and filter

7-23

• Battery recharging

7-39

• Reset items

7-40

ENGINE COOLANT

7-23

• Checking the engine coolant level

7-23

TIRES AND WHEELS

7-41

• Changing the engine coolant

7-25

• Tire care

7-41

• Recommended cold tire inflation pressures

7-41

BRAKE/CLUTCH FLUID

7-26

• Checking tire inflation pressure

7-43

• Checking the brake/clutch fluid level

7-26

• Tire rotation

7-44

AUTOMATIC TRANSAXLE FLUID

7-27

• Wheel alignment and tire balance

7-45

• Checking the automatic transaxle fluid level

7-27

• Tire replacement

7-45

• Changing the automatic transaxle fluid

7-28

• Wheel replacement

7-46

WASHER FLUID

7-29

• Tire traction

7-46

• Checking the washer fluid level

7-29

• Tire maintenance

7-47

• Tire sidewall labeling

7-47

• Low aspect ratio tire

7-51

FUSES

7-52

• Instrument panel fuse replacement

7-53

• Engine compartment panel fuse replacement

7-55

• Main fuse (multi fuse)

7-56

• Fuse/relay panel description

7-57

LIGHT BULBS

7-69

• Headlight, position light, turn signal light, and

front fog light bulb replacement

7-70

• Side repeater light bulb replacement

7-72

• Rear combination light bulb replacement

7-72

• Rear fog light bulb replacement

7-74

• High mounted stop light

7-74

• License plate light bulb replacement

7-74

• Interior light bulb replacement

7-75

APPEARANCE CARE

7-76

• Exterior care

7-76

• Interior care

7-81

EMISSION CONTROL SYSTEM

7-82

• Crankcase emission control system

7-82

• Evaporative emission control system

7-82

• Exhaust emission control system

7-83

Maintenance

ENGINE COMPARTMENT

■ Left-hand drive

1. Engine coolant reservoir

2. Engine oil filler cap

3. Brake/clutch fluid reservoir

4. Air cleaner

5. Fuse box

6. Positive battery terminal

■ Right-hand drive

7. Negative battery terminal

8. Windshield washer fluid reservoir

9. Radiator cap

10. Engine oil dipstick

11. Automatic transaxle dipstick*

* : if equipped

❈ The actual engine room in the vehicle may differ from the illustration.

OBA013006/OBA013006R

7 3

Maintenance

MAINTENANCE SERVICES

You should exercise the utmost care to

Owner’s responsibility

Owner maintenance precautions

prevent damage to your vehicle and

✽ NOTICE

Improper or incomplete service may

injury to yourself whenever performing

Maintenance Service and Record

result in problems. This chapter gives

any maintenance or inspection proce-

Retention are the owner's responsibility.

instructions only for the maintenance

dures.

items that are easy to perform.

Inadequate, incomplete or insufficient

We recommend in general that you have

servicing may result in operational prob-

your vehicle serviced by an authorized

✽ NOTICE

lems with your vehicle that could lead to

HYUNDAI dealer.

Improper owner maintenance during

vehicle damage, an accident, or person-

al injury.

You should retain documents that show

the warranty period may affect warran-

proper maintenance has been performed

ty coverage. For details, read the sepa-

on your vehicle in accordance with the

rate Service Passport provided with the

scheduled maintenance service charts

vehicle. If you're unsure about any serv-

shown on the following pages. You need

icing or maintenance procedure, we rec-

this information to establish your compli-

ommend that the system be serviced by

ance with the servicing and maintenance

an authorized HYUNDAI dealer.

requirements of your vehicle warranties.

Detailed warranty information is provided

in your Service Passport.

Repairs and adjustments required as a

result of improper maintenance or a lack

of required maintenance are not covered

when your vehicle is covered by warran-

ty.

7 4

Maintenance

WARNING - Maintenance

work

•

Performing maintenance work on

a vehicle can be dangerous. You

can be seriously injured while

performing some maintenance

procedures. If you lack sufficient

knowledge and experience or the

proper tools and equipment to do

the work, we recommend that the

system be serviced by an author-

ized HYUNDAI dealer.

•

Working under the hood with the

engine running is dangerous. It

becomes even more dangerous

when you wear jewelry or loose

clothing. These can become

entangled in moving parts and

result in injury. Therefore, if you

must run the engine while work-

ing under the hood, make certain

that you remove all jewelry (espe-

cially rings, bracelets, watches,

and necklaces) and all neckties,

scarves, and similar loose cloth-

ing before getting near the

engine or cooling fans.

7 5

Maintenance

OWNER MAINTENANCE

The following lists are vehicle checks and

Owner maintenance schedule

While operating your vehicle:

inspections that should be performed at

•

Note any changes in the sound of the

When you stop for fuel:

the frequencies indicated to help ensure

exhaust or any smell of exhaust fumes

•

Check the engine oil level.

safe, dependable operation of your vehi-

in the vehicle.

•

Check the coolant level in the coolant

cle.

•

Check for vibrations in the steering

reservoir.

Any adverse conditions should be

wheel. Notice any increased steering

•

Check the windshield washer fluid

brought to the attention of your dealer as

effort or looseness in the steering

level.

soon as possible.

wheel, or change in its straight-ahead

•

Look for low or under-inflated tires.

These Owner Maintenance Checks are

position.

generally not covered by warranties and

•

Notice if your vehicle constantly turns

you may be charged for labor, parts and

slightly or “pulls” to one side when trav-

WARNING

lubricants used.

eling on smooth, level road.

Be careful when checking your

•

When stopping, listen and check for

engine coolant level when the

unusual sounds, pulling to one side,

engine is hot. Scalding hot coolant

increased brake pedal travel or “hard-

and steam may blow out under

to-push” brake pedal.

pressure. This could cause burns

or other serious injury.

•

If any slipping or changes in the oper-

ation of your transaxle occurs, check

the transaxle fluid level.

•

Check automatic transaxle P

(Park)

function.

•

Check the parking brake.

•

Check for fluid leaks under your vehicle

(water dripping from the air condition-

ing system during or after use is nor-

mal).

7 6

Maintenance

At least monthly:

At least twice a year

At least once a year:

• Check the coolant level in the engine

(i.e., every Spring and Fall):

• Clean the body and door drain holes.

coolant reservoir.

• Check the radiator, heater and air con-

• Lubricate the door hinges and checks,

• Check the operation of all exterior

ditioning hoses for leaks or damage.

and hood hinges.

lights, including the stoplights, turn sig-

• Check the windshield washer spray

• Lubricate the door and hood locks and

nals and hazard warning flashers.

and wiper operation. Clean the wiper

latches.

• Check the inflation pressures of all

blades with clean cloth dampened with

• Lubricate the door rubber weather-

tires including the spare.

washer fluid.

strips.

• Check the headlight alignment.

• Check the air conditioning system.

• Check the muffler, exhaust pipes,

• Inspect and lubricate the automatic

shields and clamps.

transaxle linkage and controls.

• Check the lap/shoulder belts for wear

• Clean the battery and terminals.

and function.

• Check the brake

(and clutch) fluid

• Check for worn tires and loose wheel

level.

lug nuts.

7 7

Maintenance

SCHEDULED MAINTENANCE SERVICE

Follow the Normal Maintenance

If your vehicle is operated under the

Schedule if the vehicle is usually operat-

above conditions, you should inspect,

ed where none of the following conditions

replace or refill more frequently than the

apply. If any of the following conditions

following Normal Maintenance Schedule.

apply, follow Maintenance Under Severe

After the periods or distance shown in

Usage Conditions.

the chart, continue to follow the pre-

•

Repeated short distance driving.

scribed maintenance intervals.

•

Driving in dusty conditions or sandy

areas.

•

Extensive use of brakes.

•

Driving in areas where salt or other

corrosive materials are being used.

•

Driving on rough or muddy roads.

•

Driving in mountainous areas.

•

Extended periods of idling or low

speed operation.

•

Driving for a prolonged period in cold

temperatures and/or extremely humid

climates.

•

More than 50% driving in heavy city

traffic during hot weather above 32°C

(90°F).

7 8

Maintenance

NORMAL MAINTENANCE SCHEDULE (FOR MEXICO)

MAINTENANCE

Number of months or driving distance, whichever comes first

INTERVALS

Months

Miles×1,000

6.5

19.5

32.5

45.5

MAINTENANCE

ITEM

Km×1,000

Drive belts *1

Engine oil and engine oil filter *2

Air cleaner filter

Spark plugs

Replace every 160,000 km (100,000 miles) *3

: Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

: Adjust alternator and power steering (and water pump drive belt) and air conditioner drive belt (if equipped).

Inspect and if necessary correct or replace.

: Check the engine oil level and leak every 500 km (350 miles) or before starting a long trip.

: For your convenience, it can be replaced prior to it's interval when you do maintenance of other items.

7 9

Maintenance

NORMAL MAINTENANCE SCHEDULE (FOR MEXICO) (CONT.)

MAINTENANCE

Number of months or driving distance, whichever comes first

INTERVALS

Months

Miles×1,000

6.5

19.5

32.5

45.5

MAINTENANCE

ITEM

Km×1,000

Valve clearance *4 (if equipped)

Inspect every 95,000 km (60,000 miles) or 48 months *3

Vapor hose and fuel filler cap

Vacuum hose

Fuel filter *5

Fuel lines, hoses and connections

Inspect “Coolant level and leak” every day

Cooling system

Inspect “Water pump” when replacing the drive belt or timing belt

: Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

: For your convenience, it can be replaced prior to it's interval when you do maintenance of other items.

: Inspect for excessive valve noise and/or engine vibration and adjust if necessary. We recommend that the system be serviced

by an authorized HYUNDAI dealer.

: The fuel filter is considered to be maintenance free but periodic inspection is recommended for this maintenance schedule

depends on fuel quality. If there are some important safety matters like fuel flow restriction, surging, loss of power, hard start-

ing problem etc, replace the fuel filter immediately regardless of maintenance schedule and consult an authorized HYUNDAI

dealer for details.

7 10

Maintenance

NORMAL MAINTENANCE SCHEDULE (FOR MEXICO) (CONT.)

MAINTENANCE

Number of months or driving distance, whichever comes first

INTERVALS

Months

Miles×1,000

6.5

19.5

32.5

45.5

MAINTENANCE

ITEM

Km×1,000

At first, replace at 210,000 km (120,000 miles) or 120 months:

Engine coolant *6

after that, replace every 30,000 km (20,000 miles) or 24 months *7

Battery condition

All electrical systems

Brake lines, hoses and connections

Brake pedal, clutch pedal (if equipped)

Parking brake

Brake/clutch(if equipped) fluid

Disc brakes and pads

Drum brakes and linings (if equipped)

: Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

: When adding coolant, use only a qualified coolant additive for your vehicle and never mix hard water in the coolant filled at

the factory. An improper coolant mixture can result in serious malfunction or engine damage.

: For your convenience, it can be replaced prior to it’s interval when you do maintenance of other items.

7 11

Maintenance

NORMAL MAINTENANCE SCHEDULE (FOR MEXICO) (CONT.)

MAINTENANCE

Number of months or driving distance, whichever comes first

INTERVALS

Months

Miles×1,000

6.5

19.5

32.5

45.5

MAINTENANCE

ITEM

Km×1,000

Steering gear rack, linkage and boots

Driveshaft and boots

Tire (pressure & tread wear)

Front suspension ball joints

Bolt and nuts on chassis and body

Air conditioner refrigerant (if equipped)

Air conditioner compressor (if equipped)

Climate control air filter

Manual transaxle fluid *8 (if equipped)

Inspect every 60,000 km (40,000 miles) or 48 months

Automatic transaxle fluid (if equipped)

Inspect every 60,000 km (40,000 miles) or 48 months

: Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

: Manual transaxle fluid should be changed anytime they have been submerged in water.

7 12

Maintenance

NORMAL MAINTENANCE SCHEDULE (EXCEPT MEXICO)

MAINTENANCE

Number of months or driving distance, whichever comes first

INTERVALS

Months

Miles×1,000

MAINTENANCE

ITEM

Km×1,000

105

120

Drive belts *1

Except

Replace every 15,000 km (10,000 miles) or 12 months

Engine oil and engine oil filter *2

Middle East

Replace every 10,000 km (6,000 miles) or 12 months

Except

Middle East

Air cleaner filter

Middle East

Spark plugs

Replace every 160,000 km (100,000 miles) *3

: Inspect and if necessary, adjust, correct, clean or replace.

R : Replace or change.

: Adjust alternator and power steering (and water pump drive belt) and air conditioner drive belt (if equipped).

Inspect and if necessary correct or replace.

: Check the engine oil level and leak every 500 km (350 miles) or before starting a long trip.

: For your convenience, it can be replaced prior to it's interval when you do maintenance of other items.

7 13

Hyundai i10 (2016 year). Manual - part 15
