Hyundai i10 (2016 year). Manual - part 4
Features of your vehicle
KEYS
4-3
TAILGATE
4-23
• Record your key number
4-3
• Opening the tailgate
4-23
• Key operations
4-3
• Closing the tailgate
4-23
• Immobilizer system
4-4
WINDOWS
4-24
REMOTE KEYLESS ENTRY
4-7
• Power windows
4-26
• Remote keyless entry system operations
4-7
• Manual windows
4-29
• Battery replacement
4-9
HOOD
4-30
SMART KEY
4-11
• Opening the hood
4-30
• Smart key function
4-11
• Closing the hood
4-31
• Door lock/unlock in an emergency situation
4-13
FUEL FILLER LID
4-32
4
THEFT-ALARM SYSTEM
4-14
• Opening the fuel filler lid
4-32
• Armed stage
4-14
• Closing the fuel filler lid
4-33
• Theft-alarm stage
4-15
STEERING WHEEL
4-35
• Disarmed stage
4-15
• Electric power steering
4-35
DOOR LOCKS
4-16
• Horn
4-36
• From outside the vehicle
4-16
MIRRORS
4-37
• From inside the vehicle
4-17
• Inside rearview mirror
4-37
• Impact sensing door unlock system
4-20
• Outside rearview mirror
4-37
• Speed sensing door lock system
4-20
INSTRUMENT CLUSTER
4-41
• Child-protector rear door lock
4-20
• Gauges
4-42
TRUNK
4-21
• Warnings and indicators
4-48
• Opening the trunk
4-21
HAZARD WARNING FLASHER
4-58
• Closing the trunk
4-22
LIGHTING
4-59
WINDSHIELD DEFROSTING AND
• Battery saver function
4-59
DEFOGGING
4-79
• Lighting control
4-59
STORAGE COMPARTMENT
4-81
• High beam operation
4-60
• Center console storage
4-81
• Flashing headlights
4-60
• Glove box
4-81
• Turn signals and lane change signals
4-61
• Cool box
4-82
• Front fog light
4-62
INTERIOR FEATURES
4-83
• Rear fog light
4-63
• Cigarette lighter
4-83
• Headlight leveling device
4-64
• Ashtray
4-83
WIPERS AND WASHERS
4-65
• Cup holder
4-84
4
• Windshield wipers
4-66
• Sunvisor
4-85
• Windshield washers
4-66
• Power outlet
4-85
• Rear window wiper and washer switch
4-67
• Floor mat anchor(s)
4-86
INTERIOR LIGHT
4-68
• Luggage net (holder)
4-87
• Room lamp
4-68
• Cargo area cover
4-87
• Luggage room lamp
4-69
AUDIO SYSTEM
4-88
• Glove box lamp
4-69
• Antenna
4-88
DEFROSTER
4-70
• Audio remote control
4-89
• Rear window defroster
4-70
• Aux, USB and iPod
4-90
MANUAL CLIMATE CONTROL SYSTEM . . . 4-71
• CD Player
4-100
• Heating and air conditioning
4-72
• Audio
4-105
• System operation
4-76
• Climate control air filter
4-78
• Checking the amount of air conditioner refrigerant
and compressor lubricant
4-78
Features of your vehicle
KEYS
■ Type A
Key operations
• Used to start the engine.
• Used to lock and unlock the doors (or
tailgate/trunk).
WARNING - Ignition key
Leaving children unattended in a
vehicle with the ignition key is dan-
OHD046100
gerous even if the key is not in the
■ Type B
ignition switch. Children copy
adults and they could place the key
OUN046100L
in the ignition switch. The ignition
key would enable children to oper-
Record your key number
ate power windows or other con-
The key code number is stamped on the
trols, or even make the vehicle
bar code tag attached to the key set.
move, which could result in serious
Should you lose your keys, we recom-
bodily injury or even death. Never
mend that you contact an authorized
leave the keys in your vehicle with
HYUNDAI dealer. Remove the bar code
OHG040001L
unsupervised children.
tag and store it in a safe place. Also, record
■ Type C
the code number and keep it in a safe and
handy place, but not in the vehicle.
WARNING
Use only HYUNDAI original parts
for the ignition key in your vehicle.
If an aftermarket key is used, the
ignition switch may not return to
ON after START. If this happens, the
starter will continue to operate
causing damage to the starter
OBA043029
motor and possible fire due to
excessive current in the wiring.
4 3
Features of your vehicle
To deactivate the immobilizer system:
✽ NOTICE
Insert the ignition key into the key cylin-
When starting the engine, do not use the
der and turn it to the ON position.
key with other immobilizer keys around.
Otherwise the engine may not start or
To activate the immobilizer system:
may stop soon after it starts. Keep each
Turn the ignition key to the OFF position.
key separate in order to avoid a starting
The immobilizer system activates auto-
malfunction.
matically. Without a valid ignition key for
your vehicle, the engine will not start.
CAUTION
Do not put metal accessories near
the ignition switch.
WARNING
OHD046100
Metal accessories may interrupt the
In order to prevent theft of your vehi-
transponder signal and may pre-
Immobilizer system (if equipped)
cle, do not leave spare keys any-
vent the engine from starting.
where in your vehicle. Your immobi-
■ Type A
lizer password is a customer unique
Your vehicle may be equipped with an
password and should be kept confi-
electronic engine immobilizer system to
✽ NOTICE
dential. Do not leave this number
reduce the risk of unauthorized vehicle
If you need additional keys or lose your
anywhere in your vehicle.
use.
keys, we recommend that you consult an
Your immobilizer system is comprised of
authorized HYUNDAI dealer.
a small transponder in the ignition key
and electronic devices inside the vehicle.
With the immobilizer system, whenever
you insert your ignition key into the igni-
tion switch and turn it to ON, it checks
and determines and verifies if the ignition
key is valid or not.
If the key is determined to be valid, the
engine will start.
If the key is determined to be invalid, the
engine will not start.
4 4
Features of your vehicle
■ Type B
CAUTION
Your vehicle is equipped with an electron-
WARNING
The transponder in your ignition
ic engine immobilizer system to reduce
In order to prevent theft of your
key is an important part of the
the risk of unauthorized vehicle use.
vehicle, do not leave spare keys
immobilizer system. It is designed
Your immobilizer system is comprised of
anywhere in your vehicle. Your
to give years of trouble-free service,
a small transponder in the smart key and
Immobilizer password is a cus-
however you should avoid expo-
electronic devices inside the vehicle.
tomer unique password and should
sure to moisture, static electricity
be kept confidential. Do not leave
With the immobilizer system, whenever
and rough handling. Immobilizer
you turn the engine start/stop button to
this number anywhere in your vehi-
system malfunction could occur.
cle.
the ON position by pressing the button
while carrying the smart key, it checks
and determines and verifies if the smart
CAUTION
key is valid or not.
Do not change, alter or adjust the
If the key is determined to be valid, the
immobilizer system because it
engine will start.
could cause the immobilizer sys-
If the key is determined to be invalid, the
tem to malfunction.We recommend
engine will not start.
that the system be serviced by an
authorized HYUNDAI dealer.
To deactivate the immobilizer sys-
Malfunctions caused by improper
tem:
alterations, adjustments or modifi-
Turn the engine start/stop button to the
cations to the immobilizer system
ON position by pressing the button while
are not covered by your vehicle
carrying the smart key.
manufacturer warranty.
To activate the immobilizer system:
Turn the engine start/stop button to the
OFF position. The immobilizer system
activates automatically. Without a valid
smart key for your vehicle, the engine will
not start.
4 5
Features of your vehicle
✽ NOTICE
✽ NOTICE
When starting the engine, do not use the
If you need additional keys or lose your
key with other immobilizer keys around.
keys, we recommend that you consult an
Otherwise the engine may not start or
authorized HYUNDAI dealer.
may stop soon after it starts. Keep each
key separate in order to avoid a starting
malfunction.
CAUTION
The transponder in your smart key
is an important part of the immobi-
CAUTION
lizer system. It is designed to give
Do not put metal accessories near
years of trouble-free service, how-
the smart key.
ever you should avoid exposure to
The engine may not start because
moisture, static electricity and
the metal accessories may interrupt
rough handling. Immobilizer sys-
the transponder signal from trans-
tem malfunction could occur.
mitting normally.
CAUTION
Do not change, alter or adjust the
immobilizer system because it
could cause the immobilizer sys-
tem to malfunction. We recommend
that the system be serviced by an
authorized HYUNDAI dealer.
Malfunctions caused by improper
alterations, adjustments or modifi-
cations to the immobilizer system
are not covered by your vehicle
manufacturer warranty.
4 6
Features of your vehicle
REMOTE KEYLESS ENTRY (IF EQUIPPED)
■ Remote key
■ Remote key
CAUTION
Do not fold the key without press-
ing the release button. This may
damage the key.
Smart key
• To remove the mechanical key, press
and hold the release button (1) and
remove the mechanical key(2).
OHG040001L
OHG040006L
• To reinstall the mechanical key, put the
■ Smart key
■ Smart key
key into the hole and push it until a
click sound is heard.
OBA043029
OBA043222IN
Remote keyless entry system
Lock (1)
operations
1. Close all doors.
Remote key
2. Press the lock button.
• To unfold the key, press the release
3. The hazard warning light will blink once
button then the key will unfold auto-
to indicate that all doors are locked (the
matically.
engine hood and tailgate/trunk must be
• To fold the key, fold the key manually
closed).
while pressing the release button.
4 7
Features of your vehicle
✽ NOTICE
Transmitter precautions
(Continued)
The doors will not lock if a door is
•
If the transmitter is in close proximity
✽ NOTICE
to your cell phone or smart phone, the
opened.
The transmitter will not work if any of
signal from the transmitter could be
following occurs:
blocked by normal operation of your
Unlock (2)
• The mechanical key is in the ignition
cell phone or smart phone. This is
1. Press the unlock button.
switch.
especially important when the phone
2. The hazard warning lights will blink
• You exceed the operating distance
is active such as making call, receiving
twice to indicate that all doors are
limit (about 10 m [30 feet]).
calls, text messaging, and/or sending/
unlocked.
• The battery in the transmitter is
receiving emails. Avoid placing the
weak.
transmitter and your cell phone or
• Other vehicles or objects may be
Tailgate/trunk unlock (3, if equipped)
smart phone in the same pants or
blocking the signal.
1. Press the tailgate/trunk unlock button
jacket pocket and maintain adequate
• The weather is extremely cold.
for more than 1 second.
distance between the two devices.
• The transmitter is close to a radio
2.The hazard warning light will blink
transmitter such as a radio station or
twice to indicate the tailgate/trunk is
an airport which can interfere with
unlocked.
normal operation of the transmitter.
When the transmitter does not work
✽ NOTICE
correctly, open and close the door with
• After unlocking the tailgate/trunk, the
the ignition key. If you have a problem
with the transmitter, we recommend
tailgate/trunk will lock automatically
unless it is opened within 30 seconds.
that you contact an authorized
• Once the tailgate/trunk is opened and
HYUNDAI dealer.
then closed, the tailgate/trunk will
(Continued)
lock automatically.
• The word "HOLD" is written on the
button to inform you that you must
press and hold the button.
4 8
Features of your vehicle
■ Remote key
2. Replace the battery with a new one.
CAUTION
When replacing the battery, make sure
Keep the transmitter away from
the battery positive “+” symbol faces up
water or any liquid. If the keyless
as indicated in the illustration.
entry system is inoperative due to
3. Install the battery in the reverse order
exposure to water or liquids, it will
of removal.
not be covered by your manufactur-
er’s vehicle warranty.
For transmitter replacement, we recom-
mend that you contact an authorized
HYUNDAI dealer.
CAUTION
OLM042302
Changes or modifications not
■ Smart key
expressly approved by the party
responsible for compliance could
void the user’s authority to operate
the equipment. If the keyless entry
system is inoperative due to
changes or modifications not
expressly approved by the party
responsible for compliance, it will
not be covered by your manufactur-
er’s vehicle warranty.
OLM043439
Battery replacement
The transmitter uses a 3 volt lithium bat-
tery which will normally last for several
years. When replacement is necessary,
use the following procedure.
1. Insert a slim tool into the slot and gen-
tly pry open the transmitter center
cover.
4 9
Features of your vehicle
✽ NOTICE
CAUTION
An inappropriately disposed battery
•
The keyless entry system trans-
can be harmful to the environment and
mitter is designed to give you
human health. Dispose the battery
years of trouble-free use, howev-
according to your local law(s) or regula-
er it can malfunction if exposed to
tion.
moisture or static electricity.
If you are unsure how to use your
transmitter or replace the battery,
we recommend that you contact
an authorized HYUNDAI dealer.
•
Using the wrong battery can
cause the transmitter to malfunc-
tion. Be sure to use the correct
battery.
•
To avoid damaging the transmit-
ter, don't drop it, get it wet, or
expose it to heat or sunlight.
4 10
Features of your vehicle
SMART KEY (IF EQUIPPED)
Locking
1. Carry the smart key.
2. Close all doors.
3. Press the button of the outside door
handle.
4. The hazard warning lights will blink
once (the engine hood and tailgate/trunk
must be closed).
5. Make sure that doors are locked by
pulling the outside door handle.
OBA043222IN
OBA043010L
✽ NOTICE
Smart key function
Carrying the smart key, you may lock and
• The button will only operate when the
unlock the vehicle doors and tailgate/trunk.
smart key is within 0.7 m (28 in.) from
1. Door lock
the outside door handle.
2. Door unlock
Also, you may start the engine. Refer to
• Even though you press the outside
3. Tailgate/trunk unlock
the following, for more details.
door handle button, the doors will not
With a smart key, you can lock or unlock
lock and the chime will sound for 3
a door and tailgate/trunk and even start
seconds if any of following occur:
the engine without inserting the key.
- The smart key is in the vehicle.
The functions of the buttons on a smart
- The engine start/stop button is in
key are similar to the remote keyless
ACC or ON position.
entry. Refer to the
“Remote keyless
- Any door except the tailgate/trunk is
entry” in this section.
opened.
4 11
Features of your vehicle
Unlocking
Tailgate/trunk unlocking
Smart key precautions
1. Carry the smart key.
1. Carry the smart key.
✽ NOTICE
2. Press the button of the front outside
2. Press the tailgate/trunk handle switch.
•
If, for some reason, you happen to lose
door handle.
3. The tailgate/trunk will unlock.
your smart key, you will not be able to
3. All doors will unlock and the hazard
start the engine. Tow the vehicle, if nec-
warning lights will blink twice.
✽ NOTICE
essary, we recommend that you contact
an authorized HYUNDAI dealer.
•
Once the tailgate/trunk is opened and
✽ NOTICE
then closed, the tailgate/trunk will
•
A maximum of 2 smart keys can be
•
The button will only operate when the
lock automatically.
registered to a single vehicle. If you
smart key is within 0.7 m (28 in.) from
•
The button will only operate when the
lose a smart key, we recommend that
you contact an authorized HYUNDAI
the outside door handle.
smart key is within 0.7 m (28 in.) from
dealer.
•
When the smart key is recognized in
the tailgate/trunk handle.
•
The smart key will not work if any of
the area of 0.7 m (28 in.) from the
the following occurs:
front outside door handle, other peo-
- The smart key is close to a radio
ple can also open the doors.
transmitter such as a radio station
or an airport which can interfere
with normal operation of the smart
key.
- The smart key is near a mobile two-
way radio system or a cellular phone.
- Another vehicle’s smart key is being
operated close to your vehicle.
When the smart key does not work
properly, open and close the door with
the mechanical key. If you have a
problem with the smart key, we rec-
ommend that you contact an author-
ized HYUNDAI dealer.
(Continued)
4 12
Features of your vehicle
(Continued)
• If the smart key is in close proximity
to your cell phone or smart phone, the
signal from the smart key could be
blocked by normal operation of your
cell phone or smart phone. This is
especially important when the phone
is active such as making call, receiving
calls, text messaging, and/or send-
ing/receiving emails. Avoid placing the
smart key and your cell phone or
smart phone in the same pants or
jacket pocket and maintain adequate
OBA043029
distance between the two devices.
Door lock/unlock in an emer-
gency situation
CAUTION
If the smart key does not operate nor-
Keep the smart key away from
mally, you can lock or unlock the doors by
water or any liquid. If the keyless
using the mechanical key.
entry system is inoperative due to
1. Press and hold the release button (1)
exposure to water or liquids, it will
and remove the mechanical key (2).
not be covered by your manufactur-
2. Insert the key into the hole of the out-
er’s vehicle warranty.
side door handle. Turn the key toward
the rear of the vehicle to unlock and
toward the front of the vehicle to lock.
3. To reinstall the mechanical key, put the
key into the hole and push it until a
click sound is heard.
4 13
Features of your vehicle
THEFT-ALARM SYSTEM (IF EQUIPPED)
Armed stage
Do not arm the system until all pas-
sengers have left the vehicle. If the
The Theft Alarm System automatically
system is armed while a passenger(s)
sets 30 seconds after you lock the doors
Armed
remains in the vehicle, the alarm may
and the tailgate/trunk. For the system to
stage
be activated when the remaining pas-
activate, you must lock the doors and the
senger(s) leave the vehicle. If any
tailgate/trunk from outside the vehicle
door (or tailgate/trunk) or engine hood
with the remote key or smart key or by
is opened within 30 seconds after the
pressing the button on the outside of the
system enters the armed stage, the
Disarmed
Theft-alarm
door handles with the smart key in your
stage
stage
system is disarmed to prevent unnec-
possession.
essary alarm.
The hazard warning lights will blink and
the chime will sound once to indicate the
system is armed.
This system is designed to provide pro-
Once the security system is set, opening
tection from unauthorized entry into the
any door, the tailgate/trunk, or the hood
car. This system is operated in three
without using the remote key or smart
stages: the first is the "Armed" stage, the
key will cause the alarm to activate.
second is the "Theft-alarm" stage, and the
The theft alarm system will not set if the
third is the "Disarmed" stage. If triggered,
hood, the tailgate/trunk, or any door is
the system provides an audible alarm with
not fully closed. If the system will not set,
the hazard warning light blinking.
check the hood, the tailgate/trunk, or the
doors are fully closed.
4 14
Features of your vehicle
Theft-alarm stage
Disarmed stage
✽ NOTICE - Smart key
The alarm will be activated if any of the
The system will be disarmed when:
• If the system is not disarmed with the
following occurs while the system is
smart key, open the door with the
Remote key
armed.
mechanical key and start the engine.
- The door unlock button is pressed.
• A door is opened without using the
Then the system will be disarmed.
remote key or smart key.
• If you lose your keys, we recommend
Smart key
that you contact an authorized
• The tailgate/trunk is opened without
- The door unlock button is pressed.
HYUNDAI dealer.
using the remote key or smart key.
- The button of the front outside door is
• The engine hood is opened.
pressed while carrying the smart key.
The horn will sound and the hazard
CAUTION
warning lights will blink continuously for
Do not change, alter or adjust the
After the doors are unlocked, the hazard
approximately
27 seconds, unless the
immobilizer system because it
warning lights will blink twice to indicate
system is disarmed. To turn off the sys-
could cause the immobilizer sys-
tem, unlock the doors with the remote
that the system is disarmed.
tem to malfunction and we recom-
key or smart key.
After pressing the unlock button, if any
mend that the system be serviced
door
(or tailgate/trunk) is not opened
by an authorized HYUNDAI dealer.
within
30 seconds, the system will be
Malfunctions caused by improper
rearmed.
alterations, adjustments or modifi-
cations to the immobilizer system
✽ NOTICE - Non-Smart key
are not covered by your vehicle
• If the system is not disarmed with the
manufacturer warranty.
remote key, open the door with the
key and insert the key into the ignition
switch, turn the ignition switch to the
ON position and wait for 30 seconds.
Then the system will be disarmed.
• If you lose your keys, we recommend
that you contact an authorized
HYUNDAI dealer.
4 15
Features of your vehicle
DOOR LOCKS
■ Remote key
Remote key/Smart key
Mechanical key
• Doors can be locked and unlocked with
• Turn the key toward the rear of the
the remote key or smart key.
vehicle to lock and toward the front of
• Doors can be locked and unlocked by
the vehicle to unlock.
pressing the button of the outside door
• If you lock/unlock the driver’s (or pas-
handle with the smart key in your pos-
senger’s) door with a key, all vehicle
session. (if equipped with smart key sys-
doors will lock/unlock automatically. (if
tem)
equipped with central door lock system)
• Once the doors are unlocked, they may
• Once the doors are unlocked, they may
be opened by pulling the door handle.
be opened by pulling the door handle.
OBA043011L
• When closing the door, push the door
• When closing the door, push the door
■ Smart key
by hand. Make sure that doors are
by hand. Make sure that doors are
closed securely.
closed securely.
✽ NOTICE
• In cold and wet climates, door lock
and door mechanisms may not work
properly due to freezing conditions.
• If the door is locked/unlocked multi-
ple times in rapid succession with
either the vehicle key or door lock
OBA043224IN
OBA043010L
switch, the system may stop operating
temporarily in order to protect the
Operating door locks from out-
circuit and prevent damage to system
components.
side the vehicle
4 16
Features of your vehicle
■ Left-hand drive
✽ NOTICE
■ Left-hand drive
The central door lock system will operate
only when all doors and tailgate/trunk
are closed.
Lock
✽ NOTICE
Unlock
Always remove the ignition key, engage
the parking brake, close all windows
and lock all doors when leaving your
vehicle unattended.
OBA043003L
OBA043002L
■ Right-hand drive
■ Right-hand drive
Lock
Unlock
OBA043003
OBA043002
To lock a door without the key, push the
Operating door locks from inside
inside door lock button (1) to the “Lock”
the vehicle
position and close the door (2). (if not
With the door lock button
equipped with central door lock system)
• To unlock a door, push the door lock
button (1) to the “Unlock” position. The
red mark (2) on the button will be visible.
4 17
