Hyundai Azera (2017 year). Manual

Features of your vehicle

SCAN

Press the

SCAN

key to scan all

channels with superior reception for

10 seconds each.

Once scan is complete, the previous-

ly played channel will be restored.

During Scan, pressing the

SCAN

key again will cancel the scan opera-

tion and restore the previously

played channel.

If the

“Category” icon is displayed,

channels are changed within the cur-

rent category.

4 173

Features of your vehicle

MEDIA MODE

✽ NOTICE

• If the

MEDIA

key is pressed with

the system power off, then the

Pressing the

MEDIA

key will change

power will turn on and the most

the operating mode in order of

recently played media mode will

CD➟USB(iPod)➟AUX➟My Music ➟

be played.

BT Audio.

• The media mode pop up screen

can be displayed only when there

are two or more media modes

turned on.

[Mode Pop up] is turned on within

SETUP

[Display], then pressing the

MEDIA

key will display the Media

mode Pop-up screen.

Use the TUNE knob to move the

focus. Press the knob to select.

4 174

Features of your vehicle

AUDIO CD MODE

(1) Mode

(8) Shuffle

Displays currently operating mode.

Turns the Shuffle feature on/off.

Basic Mode Screen

(2) Operation State

(9) List

From Repeat / Shuffle / Scan, dis-

Moves to the list screen.

plays the currently operating func-

tion.

(10) Info

Shows detailed information about

(3) Track Info

the current track.

Displays information about the cur-

rent track.

(4) Play State

Displays the play/pause state.

(5) Play Time

Displays the current play time.

(6) MENU

Displays the Audio CD Menu.

(7) Repeat

Turns the Repeat feature on/off.

4 175

Features of your vehicle

Using Audio CD Mode

Changing Tracks

Selecting from the List

TRACK

Playing/Pausing CD Tracks

Press the

SEEK

key to

Press the

TUNE knob keys to

move to the previous or next track.

search and select for the desired track.

Once an audio CD is inserted, the

mode will automatically start and

begin playing.

✽ NOTICE

TRACK

•

Pressing the

key after the

track has been playing for 2 sec-

onds will start the current track

from the beginning.

•

Pressing the

TRACK

key before

the track has been playing for 1

Once you find the desired track,

seconds will start the previous

press the

TUNE knob to start

track.

playing.

While playing, press the

TUNE

knob to pause and press again to

Rewinding / Fast-forwarding

play.

Tracks

While playing, press and hold the

✽ NOTICE

TRACK

key (over 0.8 sec-

SEEK

• Only genuine audio CDs are sup-

onds) to rewind or fast-forward the

ported. Other discs may result in

current track.

recognition failure (e.g. copy CD-

R, CDs with labels)

Scan

• The artist and title information

Press the

SCAN

key to play the first

are displayed on the screen if

track information is included

10 seconds of each track.

within the audio CD.

4 176

Features of your vehicle

Audio CD Mode Menu

List

Press the

key Select

List

If you press the

key, you will

have access to the Repeat, Shuffle,

List and Info features.

Press the

TUNE knob to search

for the desired track and press the

Repeat

TUNE knob to select.

Press the

key Select

Repeat

Repeat :Repeats the current track.

Info

Press the

key Select

Info

Shuffle

Press the

key Select

Shuffle

Shuffle :Plays tracks in random order

✽ NOTICE

The

keys are shortcut

keys to set the Repeat and Shuffle

features.

Details for the currently playing track

are displayed.

4 177

Features of your vehicle

MP3 CD MODE

(1) Mode

(8) Repeat

Displays currently operating mode.

Turns the Repeat feature on/off.

Basic Mode Screen

(2) Operation State

(9) Shuffle

From Repeat / Shuffle / Scan, dis-

Turns the Shuffle feature on/off.

plays the currently operating func-

tion.

(10) List

Moves to the list screen.

(3) File Index

Displays the current file number.

(11) Info

Shows detailed information about

(4) File Info

the current file.

Displays information about the cur-

rent file.

(12) Copy

Copies the current file into My Music

(5) Play State

Displays the play/pause state.

(6) Play Time

Displays the current play time.

(7) MENU

Displays the CD MP3 Menu.

4 178

Features of your vehicle

Using MP3 CD Mode

Changing Files

Rewinding / Fast-forwarding Files

TRACK

Press the

SEEK

keys to

While playing, press and hold the

select the previous or next file.

TRACK

SEEK

keys (over 0.8 sec-

Playing/Pausing MP3 Files

onds) to rewind or fast-forward the

Once an MP3 disc is inserted the

current file.

mode will automatically start and

✽ NOTICE

being playing.

TRACK

• Pressing the

key after the

file has been playing for 2 seconds

Scan

will start the current file from the

Press the

SCAN

key to play the first

beginning.

10 seconds of each file.

TRACK

• Pressing the

key before the

file has been playing for 1 seconds

Searching Folders

will start the previous file.

Select the folder by using the

FOLDER

Selecting from the List

keys and press the

Press the

TUNE knob to search

TUNE knob to select.

While playing, press the

TUNE

and select for the desired files.

knob to pause and press again to

play.

✽ NOTICE

• If there are numerous files and

folders within the disc, reading

time could take more than 10 sec-

onds and the list may not be dis-

played or song searches may not

The first file within the selected fold-

operate. Once loading is complete,

er will begin playing.

Once you find the desired file, press

try again.

the

TUNE knob to start playing.

4 179

Features of your vehicle

MP3 CD Mode Menu

Shuffle

List

Press the

key Select

Shuffle

Press the

key Select

List

If you press the

key, you will

have access to the Repeat, Shuffle,

Each time the button is pressed, the

List, Info and Copy features.

feature changes in order of Shuffle

Folder ➟ Shuffle All➟ Off.

• Folder Shuffle : Plays all files with-

in the current folder in Random

order.

• Shuffle All

: Plays all files in

Random order.

✽ NOTICE

Press the

TUNE knob to search

for the desired file and press the

The

keys are shortcut

TUNE knob to select.

keys to set the Repeat and Shuffle

Repeat

features.

Press the

key Select

Repeat

Each time the button is pressed, the

feature changes in order of Repeat

➟Repeat Folder➟Off.

• Repeat Once : Repeats the current

file.

• Repeat Folder : Repeats all files

within the current Folder.

4 180

Features of your vehicle

Info

Copy Files

Press the

key Select

Info

Press the

key Select

Copy

Details for the currently playing file

The currently playing file is copied

are displayed.

into My Music.

✽ NOTICE

• When the ‘Folder File’ option is

• Selecting another feature during

set as the default display within

copying will display a pop-up ask-

Display setup, the album/artist/file

ing whether you wish to cancel

information are displayed as

copying. To cancel, select 'Yes’.

detailed file information.

• When the ‘Album Artist Song’

option is set as the default display,

the folder name/file name are dis-

played as detailed file information.

• The title, artist and album info are

displayed only when such infor-

mation are recorded within the

MP3 file ID3 tag.

4 181

Features of your vehicle

USB MODE

(1) Mode

(8) Repeat

Displays currently operating mode.

Turns the Repeat feature on/off.

Basic Mode Screen

(2) Operation State

(9) Shuffle

From Repeat / Shuffle / Scan, dis-

Turns the Shuffle feature on/off.

plays the currently operating func-

tion.

(10) List

Moves to the list screen.

(3) File Index

Displays the current file number.

(11) Info

Displays additional information for

(4) File Info

the current file.

Displays information about the cur-

rent file.

(12) Copy

Copies the current file into My Music.

(5) Play State

Changes the play/pause state.

(6) Play Time

Displays the current play time.

(7) MENU

Displays USB Menu.

4 182

Features of your vehicle

Using USB Mode

✽ NOTICE

Selecting from the List

• Loading may require additional

Press the

TUNE knob to search

time if there are many files and

and select desired files.

Playing/Pausing USB Files

folders within the USB and result

Once a USB is connected, the mode

in faulty list display or file search-

will automatically start and begin

ing. Normal operations will

playing a USB file.

resume once loading is complete.

• The device may not support nor-

mal operation when using a USB

memory type besides

(Metal

Cover Type) USB Memory.

Changing Files

TRACK

Press the

SEEK

keys to

Once you find the desired file, press

select the previous or next file.

the

TUNE knob to start playing.

While playing, press the

TUNE

✽ NOTICE

Rewinding / Fast-forwarding Files

knob to pause and press again to

TRACK

• Pressing the

key after the

While playing, press and hold the

play.

TRACK

keys (over 0.8 sec-

file has been playing for 2 seconds

SEEK

will start the current file from the

onds) to rewind or fast-forward the

beginning.

current file.

TRACK

• Pressing the

key before the

file has been playing for 1 seconds

Scan

will start the previous file.

Press the

SCAN

key to play the first

10 seconds of each file.

4 183

Features of your vehicle

Searching Folders

USB Mode Menu

Shuffle

Select the folder by using the

Press the

key Select

Shuffle

If you press the

key, you will

FOLDER

keys and press the

have access to the Repeat, Shuffle,

Each time the button is pressed, the

TUNE knob to select.

List, Info and Copy features.

feature changes in order of Shuffle

Folder➟Shuffle All➟Off.

• Folder Shuffle : Plays the files in the

current folder in random order.

• Shuffle All : Plays all files in random

order.

✽ NOTICE

• The

keys are short-

cut keys to set the Repeat and

The first file within the selected fold-

Shuffle features.

er will begin playing.

Repeat

Press the

key Select

Repeat

Each time the button is pressed, the

feature changes in order of Repeat➟

Repeat Folder➟ Off.

• Repeat : Repeats the current file.

• Folder Repeat : Repeats all files

within the current folder.

4 184

Features of your vehicle

List

✽ NOTICE

Copy Files

Press the

key Select

List

• When the ‘Folder File’ option is

Press the

key Select

Copy

set as the default display within

The currently playing file is copied

Display setup, the album/artist/file

into My Music.

information are displayed as

detailed file information.

✽ NOTICE

• When the ‘Album Artist Song’

option is set as the default display,

Selecting another feature during

the folder name/file name are dis-

copying will display a pop-up asking

played as detailed file information.

whether you wish to cancel copying.

• The title, artist and album info are

To cancel, select 'Yes’.

displayed only when such infor-

mation are recorded within the

Press the

TUNE knob to search

MP3 file ID3 tag.

for the desired file and press the

TUNE knob to select.

Info

Press the

key Select

Info

Details for the currently playing file are

displayed.

4 185

Features of your vehicle

iPod MODE

(1) Mode

(8) Repeat

Displays currently operating mode.

Turns the Repeat feature on/off.

Basic Mode Screen

(2) Operation State

(9) Shuffle

From Repeat / Shuffle, displays the

Turns the Shuffle feature on/off.

currently operating function.

(10) List

(3) Song Index

Moves to the list screen.

Displays the current song/total num-

ber of songs.

(4) Song Info

Displays information about the cur-

rent song.

(5) Play State

Changes the play/pause state.

(6) Play Time

Displays the current play time.

(7) MENU

Displays the iPod Menu.

4 186

Features of your vehicle

Using iPod Mode

Changing Songs

Searching Categories

TRACK

Press the

SEEK

keys to

Use the

TUNE knob to search

select the previous or next file.

categories and press the knob to

Playing/Pausing iPod Songs

select.

Once an iPod is connected, the

mode will automatically start and

✽ NOTICE

begin playing an iPod song.

TRACK

• Pressing the

key after the

song has been playing for 2 sec-

onds will start the current song

from the beginning.

• Pressing the

TRACK

key before

the song has been playing for 1

seconds will start the previous

song.

If you press the

key within the

• Slight time differences may exist

Category Menu, This button is used

depending your iPod product.

to move to the previous category.

While playing, press the

TUNE

knob to pause and press again to

Rewinding / Fast-forwarding Songs

✽ NOTICE

play.

While playing, press and hold the

• There are eight categories that can

TRACK

keys (over 0.8 sec-

SEEK

be searched, including Playlists,

✽ NOTICE

onds) to rewind or fast-forward the

Artists, Albums, Genres, Songs,

current song.

Composers, Audiobooks and

• iPods with unsupported communi-

cation protocols may not properly

Podcasts.

• If the search mode is accessed while

operate in the audio system.

playing a song, the most recently

searched category is displayed.

• Search steps upon initial connec-

tion may differ depending on the

type of iPod device.

4 187

Features of your vehicle

iPod Mode Menu

List

AUX MODE

Press the

key Select

List

If you press the

key, you will

have access to the Repeat, Shuffle

Using AUX Mode

and List features.

Press the

MEDIA

key Select [AUX]

Press the

TUNE knob to search

for the desired file and press the

TUNE knob to select.

Repeat

Press the

key Select

Repeat

An external device can be connected

• Repeat Once : Repeats the current

to play music.

song.

Shuffle

Press the

key Select

Shuffle

• Shuffle Album : Plays songs within

the current category in random

order.

• Shuffle All

: Plays all songs in

Random order.

4 188

Features of your vehicle

✽ NOTICE

Connecting an External Device

CAUTION

•

If an external device connector is

•

Connecting a connector jack

connected with the AUX terminal,

to the AUX terminal without an

then AUX mode will automatically

external device will convert

operate. Once the connector is dis-

the system to AUX mode, but

connected, the previous mode will

only output noise. When an

be restored.

external device is not being

•

AUX mode can be used only when

used, also remove the connec-

an external audio player

(cam-

tor jack.

corder, car VCR, etc.) has been

connected.

•

When the external device

•

The AUX volume can be con-

power is connected to the

External audio players (Camcorders,

trolled separately from other

power jack, playing the exter-

car VCR, etc.) can be played through

audio modes.

nal device may output noise.

a dedicated cable.

In such cases, disconnect the

power connection before use.

•

Fully insert the AUX cable to

the AUX jack uponuse.

4 189

Hyundai Azera (2017 year). Manual - part 15
