Features of your vehicle
9. RANDOM Play Button
Turns on/off the randomization of the play
list of files in the currently played DISC.
To cancel the mode, press the button
once again.
10. DISC Selection Button
•
[DISC
] Change Button
Changes disc to the previous disc.
•
[DISC
] Change Button
Changes disc to the next disc.
11. SCAN Play Button
Plays first 10 seconds of each song in
the DISC.
To cancel the mode, press the button
once again.
12. FOLDER Moving Button
• Moves [FLDR
] button child folder of
the current folder and displays the first
song in the folder. Press TUNE/ENTER
button to move to the folder displayed.
It will play the first song in the folder.
• Moves [FLDR
] button parent folder
and displays the first song in the folder.
Press TUNE/ENTER button to move to
the folder displayed. It will play the first
song in the folder.
4 154
Features of your vehicle
USING USB (PA760S) (IF EQUIPPED)
■ Type A
1. CD/AUX Selection Button
2. TRACK Moving Button
3. INFO Button
4. FOLDER Moving Button
5. SEARCH Knob & ENTER Button
■ Type B
6. RANDOM Playback Button
7. REPEAT Selection Button
8. SCAN Selection Button
4 155
Features of your vehicle
In case USB is connected to the multi-
3. INFO Button
6. RANDOM Playback Button
media jack inside the console on the right
Displays the information of the file current-
Press the button for less than 0.8 second
hand side of the driver’s seat. When USB
to start or stop the random playback of
ly played in the order of FILE NAME ➟
is connected, the ‘USB’ icon will be dis-
the songs in the current folder.
TITLE ➟ ARTIST ➟ ALBUM ➟ FOLDER ➟
played on the top right corner of the dis-
TOTAL FILE ➟ FILE NAME ➟… (Displays
Press the button for more than 0.8 sec-
play screen.
no information if the file has no song infor-
ond to randomly play the entire songs in
mation.)
the USB device.
1. USB Selection Button
Press the button again to cancel the mode.
If USB is connected, it switches to the
4. FOLDER Moving Button
USB mode from the other mode to play
• Moves [FLDR
] button child folder of
7. REPEAT Button
the song files stored in the USB. If no CD
the current folder and displays the first
Press the button for less than 0.8 second
and auxiliary device is not connected, it
song in the folder. Press TUNE/ENTER
to repeat the song currently played.
displays "NO Media" for 3 seconds and
knob to move to the folder displayed. It
Press the button for more than 0.8 sec-
returns to the previous mode.
will play the first song in the folder.
ond to repeat the entire songs in the USB
• Moves [FLDR
] button parent folder
device.
2. TRACK Moving Button
and displays the first song in the folder.
• Press the [TRACK
] button for less
Press TUNE/ENTER knob to move to
8. SCAN Button
than 0.8 second to play from the begin-
the folder displayed. It will play the first
Plays 10 seconds of each song in the
ning of the song currently played.
song in the folder.
USB device.
Press the button for less than 0.8 sec-
Press the button once again to cancel
ond and press it again within 1 second
scanning.
5. SEARCH Knob & ENTER
to move to and play the previous track.
Button
Press the button for
0.8 second or
Turn this button clockwise to display the
longer to play the song in reverse direc-
songs next to the currently played song.
tion in fast speed.
Turn the button counterclockwise to dis-
• Press the [TRACK
] button button for
play the songs before the currently
less than 0.8 second to move to the
played song. Press the button to skip to
next track. Press the button for 0.8 sec-
and play the selected song.
ond or longer to play the song in for-
ward direction in fast speed.
4 156
Features of your vehicle
(Continued)
(Continued)
CAUTION IN USING
•
An encrypted MP3 PLAYER is not
•
If you disconnect the external USB
USB DEVICE
recognizable.
device during playback in USB
•
To use an external USB device,
•
Depending on the condition of
mode, the external USB device can
make sure the device is not con-
the external USB device, the con-
be damaged or may malfunction.
nected when starting up the vehi-
nected external USB device can
Therefore, disconnect the external
cle. Connect the device after
be unrecognizable.
USB device when the audio is
starting up.
turned off or in another mode. (e.g,
•
When the formatted byte/sector
•
If you start the engine when the
Radio, XM or CD)
setting of External USB device is
USB device is connected, it may
not either 512BYTE or 2048BYTE,
•
Depending on the type and
damage the USB device. (USB
then the device will not be recog-
capacity of the external USB
flashdrives are very sensitive to
nized.
device or the type of the files
electric shock.)
stored in the device, there is a dif-
•
Use only a USB device formatted
•
If the engine is started up or
ference in the time taken for
to FAT 12/16/32.
turned off while the external USB
recognition of the device.
•
USB devices without USB I/F
device is connected, the external
•
Do not use the USB device for
authentication may not be recog-
USB device may not work.
purposes other than playing
nizable.
•
It may not play inauthentic MP3 or
music files.
•
Make sure the USB connection
WMA files.
•
Use of USB accessories such as
terminal does not come in con-
1) It can only play MP3 files with
rechargers or heaters using USB
tact with the human body or other
the compression rate between
I/F may lower performance or
objects.
8Kbps~320Kbps.
cause trouble.
•
If you repeatedly connect or dis-
2) It can only play WMA music
•
If you use devices such as a USB
connect the USB device in a short
files with the compression rate
hub purchased separately, the
period of time, it may break the
between 8Kbps~320Kbps.
vehicle’s audio system may not
device.
•
Take precautions for static elec-
recognize the USB device. In that
•
You may hear a strange noise
tricity when connecting or dis-
case, connect the USB device
when connecting or disconnect-
connecting the external USB
directly to the multimedia termi-
ing a USB device.
device.
nal of the vehicle.
(Continued)
(Continued)
(Continued)
4 157
Features of your vehicle
(Continued)
(Continued)
•
If the USB device is divided by
•
Please avoid using USB memory
logical drives, only the music files
products which can be used as
on the highest-priority drive are
key chains or cellular phone
recognized by car audio.
accessories as they could cause
•
Devices such as MP3 Player/
damage to the USB jack. Please
Cellular phone/Digital camera can
make certain only to use plug
be unrecognizable by standard
type connector products as
USB I/F can be unrecognizable.
shown below
•
Some non-standard USB devices
(METAL COVER TYPE USB) can
be unrecognizable.
•
Some USB flash memory readers
(such as CF, SD, microSD, etc.) or
external-HDD type devices can be
unrecognizable.
•
Music files protected by DRM
(DIGITAL RIGHTS MANAGE-
MENT) are not recognizable.
•
The data in the USB memory may
be lost while using this audio.
Always back up important data on
a personal storage device.
(Continued)
4 158
Features of your vehicle
RUNNING iPod® (PA760S) (IF EQUIPPED)
■ Type A
1. iPod Selection Button
2. TRACK Moving Button
3. INFO Button
4. CATEGORY Selection Button
5. SEARCH Knob & ENTER Button
6. RANDOM Playback Button
■ Type B
7. REPEAT Selection Button
❈ iPod® is a trademark of Apple Inc.
4 159
Features of your vehicle
In case the iPod exclusive cable is con-
5. SEARCH Knob & ENTER
• Press the [TRACK
] button for less
nected to the multimedia jack inside the
Button
than 0.8 second to move to the next
console on the right hand side of the dri-
track.
When you turn the button clockwise, it
ver’s seat. When the iPod is connected,
Press the button for
0.8 second or
will display the songs (category) next to
the ‘iPod’ icon will be displayed on the top
the song currently played (category in
longer to play the song in forward direc-
right corner of the display screen.
the same level).
tion in fast speed.
Also, when you turn the button counter-
1. iPod Selection Button
clockwise, it will display the songs (cate-
3. INFO Button
If iPod is connected, it switches to the
gory) before the song currently played
iPod mode from the CD mode to play the
Displays the information of the file current-
(category in the same level).
song files stored in the iPod.
ly played in the order of FILE NAME ➟
If you want to listen to the song displayed
TITLE ➟ ARTIST ➟ ALBUM ➟ FILE NAME
If there are no CD and AUX, it displays
in the song category, press the button,
‘NO MEDIA’.
➟… (Displays no information if the file
then it will skip to the selected song and
has no song information.)
play.
2. TRACK Moving Button
4. CATEGORY Selection Button
6. RANDOM Playback Button
• Press the [TRACK
] button for less
Moves to the upper category from cur-
than 0.8 second to play from the begin-
Press the button for less than 0.8 second
rently played category of the iPod.
ning of the song currently played.
to activate or deactivate the random play-
You will be able to search through the
back of the songs within the current cat-
Press the button for less than 0.8 sec-
lower category of the selected category.
egory.
ond and press it again within 1 second
The order of iPod’s category is SONG,
Press the button for longer than 0.8 sec-
to move to and play the previous track.
ALBUMES, ARTISTS, GENRES, and
ond to randomly play all songs in the
Press the button for
0.8 second or
iPod. (Refer to the iPod user’s manual for
entire album of the iPod.
longer to play the song in reverse
more information)
Press the button once again to cancel the
direction in fast speed.
mode.
7. REPEAT Button
Repeats the song currently played.
4 160
Features of your vehicle
✽ NOTICE FOR USING THE
(Continued)
CAUTION IN USING THE
iPod® DEVICE
•
Deactivate (turn off) the equalizer
iPod® DEVICE
•
Some iPod models might not sup-
function of an iPod when adjust-
•
The Hyundai iPod Power Cable is
port the communication protocol
ing the audio system’s volume,
needed in order to operate iPod
and the files will not be played.
and turn off the equalizer of the
with the audio buttons on the
audio system when using the
Supported iPod models:
audio system. The USB cable pro-
equalizer of an iPod.
- iPod Mini
- iPod 4th(Photo) ~ 6th(Classic)
vided by Apple may cause mal-
•
When the iPod cable is connect-
generation
function and should not be used
ed, the system can be switched to
- iPod Nano 1st~4th generation
for Hyundai vehicles.
AUX mode even without iPod
- iPod Touch 1st~2nd generation
❋ The Hyundai iPod Power Cable
device and may cause noise.
•
The order of search or playback of
Disconnect the iPod cable when
may be purchased through your
songs in the iPod can be different
you are not using the iPod device.
Hyundai Dealership.
from the order searched in the
•
When not using iPod with car
•
When connecting iPod with the
audio system.
audio, detach the iPod cable from
•
If the iPod disabled due to its own
iPod Power Cable, insert the con-
iPod. Otherwise, iPod may remain
malfunction, reset the iPod. (Reset:
nector to the multimedia socket
in accessory mode, and may not
Refer to iPod manual)
completely. If not inserted com-
work properly.
•
An iPod may not operate normally
pletely, communications between
on low battery.
iPod and audio may be interrupted.
•
Some iPod devices, such as the
•
When adjusting the sound effects
iPhone, can be connected through
of the iPod and the audio system,
the Bluetooth® wireless technology
the sound effects of both devices
interface. The device must have
will overlap and might reduce or
audio Bluetooth® wireless technolo-
gy capability
(such as for stereo
distort the quality of the sound.
headphone
Bluetooth® wireless
(Continued)
technology). The device can play,
but it will not be controlled by the
audio system.
4 161
Features of your vehicle
XM SATELLITE RADIO (PA760S) (IF EQUIPPED)
■ Type A
1. XM Selection Button
2. INFO Button
3. Automatic Channel Selection Button
4. SCAN Button
5. CATEGORY Search Button
■ Type B
6. Manual Channel Selection Button
7. Preset Button
4 162
Features of your vehicle
1. XM Selection Button
4. SCAN Button
7. Preset Button
Turns to XM Satellite Radio Mode. XM
Press to hear a brief sampling of all
Push [1]~[6] buttons less than 0.8 sec-
mode toggles in order to XM1 ➟ XM2 ➟
channel. To cancel the scan mode, press
ond to play the channel saved in each
XM3 ➟ XM1... when the button is pressed
the button once again.
button. Push [PRESET] button for 0.8
each time.
second or longer to save current channel
to the respective button with a beep.
5. CATEGORY Search Button
2. INFO Button
• Push [CAT
] button to search previ-
Displays the information of the current
ous category.
channel in the order of Artist/Song title ➟
• Push [CAT
] button to search next
Category/Channel name ➟ Current Play
category. To listen to the displayed cate-
Channel ➟ Artist/Song title ➟ Category/
gory, press the TUNE/ENTER knob. To
Channel name... when the button is
scan channel in displayed category,
pressed each time. If can not display the
press the
[SCAN] button. To search
whole text information, rotate the tune
channel in displayed category, press
button to see the next page.
[SEEK] buttons or turn the [TUNE] knob
clockwise/counterclockwise.(CATEGO-
3. Automatic Channel Selection
RY icon is will be turned on in Category
Button
mode)
• Push [SEEK
] button for less than
0.8 second to select previous channel.
6. Manual Channel Selection
• Push [SEEK
] button for 0.8 second
Button
or longer to continuously move to pre-
While listening to XM broadcast, rotate
vious channel.
this control to the right or left to search
• Push [SEEK
] button for less than
other channels while listening to current
0.8 second to select next channel.
channel. (Turn to the right to searchhigh-
• Push [SEEK
] button for 0.8 second
er channels and left, lower channels)
or longer to contiuously move to next
channel.
• Radio ID : Seek or Tune to XM channel
0 to display the Radio ID.
4
163
Before driving / 5-3
Key positions / 5-5
Starting the engine / 5-6
Manual transaxle / 5-7
Automatic transaxle / 5-10
Brake system / 5-16
Cruise control system / 5-26
Economical operation / 5-30
Special driving conditions / 5-32
Winter driving / 5-36
Trailer towing / 5-40
Driving your vehicle
5
Vehicle load limit / 5-48
Vehicle weight / 5-52
Driving your vehicle
E010000AFD
WARNING - ENGINE EXHAUST CAN BE DANGEROUS!
Engine exhaust fumes can be extremely dangerous. If, at any time, you smell exhaust fumes inside the vehicle, open the win-
dows immediately.
• Do not inhale exhaust fumes.
Exhaust fumes contain carbon monoxide, a colorless, odorless gas that can cause unconsciousness and death by asphyxia-
tion.
• Be sure the exhaust system does not leak.
The exhaust system should be checked whenever the vehicle is raised to change the oil or for any other purpose. If you hear
a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the car, have the
exhaust system checked as soon as possible by an authorized HYUNDAI dealer.
• Do not run the engine in an enclosed area.
Letting the engine idle in your garage, even with the garage door open, is a hazardous practice. Never run the engine in your
garage any longer than it takes to start the engine and back the car out.
• Avoid idling the engine for prolonged periods with people inside the car.
If it is necessary to idle the engine for a prolonged period with people inside the car, be sure to do so only in an open area
with the air intake set at "Fresh" and fan operating at one of the higher speeds so fresh air is drawn into the interior.
If you must drive with the tailgate open because you are carrying objects that make this necessary:
1. Close all windows.
2. Open side vents.
3. Set the air intake control at "Fresh", the air flow control at "Floor" or "Face" and the fan at one of the higher speeds.
To assure proper operation of the ventilation system, be sure the ventilation air intakes located just in front of the windshield are
kept clear of snow, ice, leaves or other obstructions.
5 2
Driving your vehicle
BEFORE DRIVING
E020100AUN
E020200AUN
CALIFORNIA PROPOSI-
Before entering vehicle
Necessary inspections
TION 65 WARNING
•
Be sure that all windows, outside mir-
Fluid levels, such as engine oil, engine
Engine exhaust and a wide variety
ror(s), and outside lights are clean.
coolant, brake fluid, and washer fluid
of automobile components and
•
Check the condition of the tires.
should be checked on a regular basis,
parts, including components found
with the exact interval depending on the
•
Check under the vehicle for any sign of
in the interior furnishings in a vehi-
fluid. Further details are provided in
leaks.
cle, contain or emit chemicals
Section 7, “Maintenance”.
•
Be sure there are no obstacles behind
known to the State of California to
you if you intend to back up.
cause cancer and birth defects and
WARNING
reproductive harm. In addition, cer-
tain fluids contained in vehicles
Driving while distracted can result
and certain products of component
in a loss of vehicle control, that
wear contain or emit chemicals
may lead to an accident, severe
known to the State of California to
personal injury, and death. The dri-
cause cancer and birth defects or
ver’s primary responsibility is in
other reproductive harm.
the safe and legal operation of a
vehicle, and use of any handheld
devices, other equipment, or vehi-
cle systems which take the driver’s
eyes, attention and focus away
from the safe operation of a vehicle
or which are not permissible by law
should never be used during oper-
ation of the vehicle.
5 3
Driving your vehicle
E020300AUN
Before starting
WARNING - Driving under
WARNING
• Close and lock all doors.
the influence of alcohol or
•
When you intend to park or stop
• Position the seat so that all controls are
drugs
the vehicle with the engine on, be
easily reached.
Drinking and driving is dangerous.
careful not to depress the accel-
Drunk driving is the number one
erator pedal for a long period of
• Adjust the inside and outside rearview
contributor to the highway death
time. It may overheat the engine
mirrors.
toll each year. Even a small amount
or exhaust system and cause fire.
• Be sure that all lights work.
of alcohol will affect your reflexes,
•
When you make a sudden stop or
• Check all gauges.
perceptions and judgement.
turn the steering wheel rapidly,
• Check the operation of warning lights
Driving while under the influence of
loose objects may drop on the
when the ignition switch is turned to
drugs is as dangerous or more dan-
floor and it could interfere with
the ON position.
gerous than driving drunk.
the operation of the foot pedals,
• Release the parking brake and make
You are much more likely to have a
possibly causing an accident.
sure the brake warning light goes out.
serious accident if you drink or
Keep all things in the vehicle
For safe operation, be sure you are famil-
take drugs and drive.
safely stored.
iar with your vehicle and its equipment.
If you are drinking or taking drugs,
•
If you do not focus on driving, it
don’t drive. Do not ride with a driv-
may cause an accident. Be care-
er who has been drinking or taking
ful when operating what may dis-
WARNING
drugs. Choose a designated driver
turb driving such as audio or
All passengers must be properly
or call a cab.
heater. It is the responsibility of
belted whenever the vehicle is mov-
the driver to always drive safely.
ing. Refer to “Seat belts” in section
3 for more information on their
proper use.
WARNING
Always check the surrounding
areas near your vehicle for people,
especially children, before putting a
car into D (Drive) or R (Reverse).
5 4
Driving your vehicle
KEY POSITIONS
E030202AUN
ACC (Accessory)
The steering wheel is unlocked and elec-
trical accessories are operative.
✽ NOTICE
If difficulty is experienced turning the
ignition switch to the ACC position, turn
the key while turning the steering wheel
right and left to release the tension.
E030203AUN
OFD057001
OFD057002
ON
E030100AFD
Ignition switch position
The warning lights can be checked
Illuminated ignition switch
E030201AUN
before the engine is started. This is the
(if equipped)
LOCK
normal running position after the engine
Whenever a front door is opened, the
The steering wheel locks to protect
is started.
ignition switch will be illuminated for your
against theft. The ignition key can be
Do not leave the ignition switch ON if the
convenience, provided the ignition switch
removed only in the LOCK position.
engine is not running to prevent battery
is not in the ON position. The light will go
When turning the ignition switch to the
discharge.
off immediately when the ignition switch
LOCK position, push the key inward at
is turned on or go off after about 30 sec-
the ACC position and turn the key toward
E030204AUN
onds when the door is closed.
the LOCK position.
START
Turn the ignition switch to the START
position to start the engine. The engine
will crank until you release the key; then
it returns to the ON position. The brake
warning lamp can be checked in this
position.
5 5
Driving your vehicle
STARTING THE ENGINE
E040000AUN
4. In extremely cold weather
(below
WARNING - Ignition switch
0°F / -18°C) or after the vehicle has
not been operated for several days, let
•
Never turn the ignition switch to
WARNING
the engine warm up without depress-
LOCK or ACC while the vehicle is
Always wear appropriate shoes
ing the accelerator.
moving. This would result in loss
when operating your vehicle.
Whether the engine is cold or warm, it
of directional control and braking
Unsuitable shoes (high heels, ski
function, which could cause an
should be started without depressing
boots,etc.) may interfere with your
accident.
the accelerator.
ability to use the brake and acceler-
•
The anti-theft steering column lock
ator pedal, and the clutch
(if
is not a substitute for the parking
equipped).
CAUTION
brake. Before leaving the driver’s
If the engine stalls while you are in
seat, always make sure the shift
E040100AUN
motion, do not attempt to move the
lever is engaged in P (Park) for the
Starting the engine
shift lever to the P (Park) position. If
automatic transaxle and set the
traffic and road conditions permit,
parking brake fully and shut the
1. Make sure the parking brake is applied.
you may put the shift lever in the N
engine off. Unexpected and sud-
2. Manual Transaxle
- Depress the
(Neutral) position while the vehicle
den vehicle movement may occur
clutch pedal fully and shift the
is still moving and turn the ignition
if these precautions are not taken.
transaxle into Neutral. Keep the clutch
switch to the START position in an
•
Never reach for the ignition switch,
pedal and brake pedal depressed
attempt to restart the engine.
or any other controls through the
while turning the ignition switch to the
steering wheel while the vehicle is in
start position.
motion. The presence of your hand
Automatic Transaxle
- Place the
or arm in this area could cause a
CAUTION
transaxle shift lever in P
(Park).
loss of vehicle control, an accident
Do not engage the starter for more
Depress the brake pedal fully.
and serious bodily injury or death.
than 10 seconds. If the engine stalls
You can also start the engine when the
•
Do not place any movable objects
or fails to start, wait 5 to 10 seconds
shift lever is in the N (Neutral) position.
around the driver’s seat as they may
before re-engaging the starter.
3. Turn the ignition switch to START and
move while driving, interfere with
Improper use of the starter may
hold it there until the engine starts (a
the driver and lead to an accident.
damage it.
maximum of
10 seconds), then
release the key.
5 6
Driving your vehicle
MANUAL TRANSAXLE (IF EQUIPPED)
E050100AFD-EU
Manual transaxle operation
CAUTION
•
When downshifting from fifth
The manual transaxle has
5 forward
gear to fourth gear, caution
gears.
should be taken not to inadver-
This shift pattern is imprinted on the shift
tently press the gear shift lever
knob. The transaxle is fully synchronized
sideways in such a manner that
in all forward gears so shifting to either a
second gear is engaged. Such a
higher or a lower gear is easily accom-
drastic downshift may cause the
plished.
engine speed to increase to the
Press the clutch pedal down fully while
point that the tachometer will
shifting, then release it slowly.
enter the red-zone. Such over-
If your vehicle is equipped with an igni-
revving of the engine may possi-
tion lock switch, the engine will not start
bly cause engine damage.
The shift lever can be moved without
when starting the engine without
pulling the ring (1).
•
Do not downshift more than 2
depressing the clutch pedal. (if equipped)
gears or downshift the gear when
The ring (1) must be pulled up while
The gearshift lever must be returned to
the engine is running at high
moving the shift lever.
the neutral position before shifting into R
speed
(5,000 RPM or higher).
OFD057003K
(Reverse). The ring located immediately
Such a downshifting may damage
E050000AUN
below the shift knob must be pulled
the engine.
upward while moving the shift lever to the
R position.
Make sure the vehicle is completely
stopped before shifting into R (Reverse).
Never operate the engine with the
tachometer (rpm) in the red zone.
5 7
