Continued

415

uu

Bluetooth® HandsFreeLink®

u

Using HFL

Features

 (Pick-up) button: Press to go directly to the phone menu on the driver

information interface, or to answer an incoming call.

 (Hang-up) button: Press to end a call.

 (Back) button: Press to go back to the previous screen, or cancel a command.

 (Talk) button: Press to access Voice Portal.

Left Selector Wheel: Press the

 (home) button, then roll up or down to select

Phone on the driver information interface, and then press the left selector wheel.

 (home) button: Press to go back to the home screen of the driver information

interface.

To go to the phone screen of the driver information interface:
1. Press the

 (home) button on the steering wheel.

2. Select Phone.

u

You can select Favorite Contacts or Recent Calls.

1

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

uu

Bluetooth® HandsFreeLink®

u

Using HFL

416

Features

The audio/information screen notifies you when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored phonebook names or numbers can be called using voice
commands while the vehicle is in motion.

2 Favorite Contacts P. 424

■

HFL Status Display

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

■

Limitations for Manual Operation

*

Bluetooth Indicator
Appears when your phone is
connected to HFL.

Signal Strength

HFL Mode

Battery Level Status

Caller’s Name
(If registered)/
Caller’s Number
(If not registered)

* Not available on all models

417

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use the system.

■

Phone settings screen

1. Press the

 button.

2. Select Phone.
3. Select Settings.

1

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving.

Change Devices

(Existing entry list)

+ Connect New Device

Pair a new phone to the system.

Connect, disconnect, or delete a paired device.

Ringtone

Select the ring tone.

Auto Sync Phone

Set phonebook and call history data to be automatically imported when a phone is paired to HFL.

Auto Phone Call Transfer

Set calls to automatically transfer from your phone to HFL when you enter the vehicle.

HondaLink Assist

*

Turn HondaLink® Assist on and off.

* Not available on all models

418

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

Phone menu screen

1. Press the

 button.

2. Select Phone.

Display the last outgoing, incoming and missed calls.

Recent Calls

Favorite Contacts

All

Dialed

Received

Display the last outgoing calls.

Display the last incoming calls.

Missed

Display the last missed calls.

Keypad

Enter a phone number to dial.

(Existing entry list)

Dial the selected number in the speed dial list.

Contacts

Display the phonebook of the paired phone.

419

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

Bluetooth® setup

You can turn Bluetooth® function on and off.
1. Press the

 button.

2. Select Settings.
3. Select Connections.
4. Select Bluetooth.
5. Select Options.
6. Select Bluetooth, then ON.

■

Phone Setup

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

420

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1. Press the

 button.

2. Select Phone.
3. Select Connect Phone.
4. Make sure your phone is in search or

discoverable mode, then select + Connect
New Device.

u

HFL automatically searches for a
Bluetooth® device.

5. Select your phone when it appears on the

list.

u

If your phone still does not appear,
search for Bluetooth® devices using your
phone.
From your phone, search for
HandsFreeLink.

6. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

7. Select desired functions and then select

Save.

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to the system.

Once you have paired a phone, you can see it
displayed on the screen with one or more icons on
the right side.
These icons indicate the following:

: The phone is compatible with Bluetooth® Audio.
: The phone can be used with HFL.

If there is an active connection to Apple CarPlay
pairing of additional Bluetooth compatible devices is
unavailable.

Continued

421

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To change the currently paired phone

1. Go to the phone settings screen.

2 Phone settings screen P. 417

2. Select Change Devices.
3. Select a phone to connect.

u

HFL disconnects the connected phone
and starts searching for another paired
phone.

4. Select

or .

5. Select Save.

■

To delete a paired phone

1. Go to the phone settings screen.

2 Phone settings screen P. 417

2. Select Change Devices.
3. Select a phone you want to delete.

4. Select Delete.
5. A confirmation message appears on the

screen. Select Yes.

1

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFL will inform you that the
original phone is connected again.

To pair other phones, select + Connect New Device
from the Bluetooth screen.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

422

Features

You can change the ring tone setting.

1. Go to the phone settings screen.

2 Phone settings screen P. 417

2. Select Ringtone.
3. Select Vehicle or Phone.

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1. Go to the phone settings screen.

2 Phone settings screen P. 417

2. Select Auto Phone Call Transfer.
3. Select ON or OFF.

■

Ring Tone

1

Ring Tone

Vehicle: The fixed ring tone sounds from the
speakers.
Phone: Depending on the make and model of the
cell phone, the ring tone stored in the phone will
sound if the phone is connected.

■

Automatic Transferring

Continued

423

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

When Auto Sync Phone is set to On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

■

Changing the Auto Sync Phone setting

1. Go to the phone settings screen.

2 Phone settings screen P. 417

2. Select Auto Sync Phone.
3. Select ON or OFF.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

On some phones, it is necessary to set up it enabled
to be imported the cellular phonebook.

When you select a name from the list in the cellular
phonebook, you can see a category icon. The icons
indicate what types of numbers are stored for that
name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Home

Mobile

Work

Other

Pager

Car

Pref

Fax

Voice

424

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

To store a speed dial number:
1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select the Recent Calls, Contacts, or

Keypad screen.

3. Select the star icon.

u

A notification appears on the screen if
the Favorite Contact is successfully
stored.

u

To remove the Favorite Contact, select
the star icon again.

■

Favorite Contacts

Recent Calls Screen

Contacts Screen

Keypad Screen

Star Icon

Star Icon

Star Icon

425

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To edit a Favorite Contact

1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select Favorite Contacts.
3. Select Edit on the speed dial entry you

want to edit.

4. Select a setting you want.
5. Select Save.

■

To delete a speed dial

1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select Favorite Contacts.
3. Select Edit on the speed dial entry you

want to delete.

4. Select Remove.
5. A confirmation message appears on the

screen. Select Yes.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

426

Features

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, or Favorite Contact
entries.

■

Making a Call

1

Making a Call

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with
HandsFreeLink® and are only made from Apple
CarPlay.

427

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To make a call using the imported
phonebook

1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select Contacts.
3. Select a name.

u

You can sort by First Name or Last
Name. Select the icon on the upper right
of the screen.

4. Select a number.

u

Dialing starts automatically.

■

To make a call using a phone number

1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select Keypad.
3. Select a number.

u

Use the keyboard on the touch screen for
entering numbers.

4. Select Call.

u

Dialing starts automatically.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

428

Features

■

To make a call using the call history

Call history is stored by All, Dialed, Missed,
and Received.
1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select Recent Calls.

u

You can sort by All, Dialed, Missed, or
Received. Select the icon on the upper
right of the screen.

3. Select a number.

u

Dialing starts automatically.

■

To make a call using a Favorite Contact
entry

1. Go to the phone menu screen.

2 Phone menu screen P. 418

2. Select Favorite Contacts.

u

You can change the order of Favorite
Contact entries by selecting Reorder.

3. Select a number.

u

Dialing starts automatically.

1

To make a call using the call history

The call history appears only when a phone is
connected to the system.

Continued

429

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming Call... screen appears.

Press the

 button to answer the call.

Press the

 button to decline or end the

call.

The following options are available during a call.
Mute: Mute your voice.
Use Handheld: Transfer a call from the system to your phone.
Keypad: Send numbers during a call. This is useful when you call a menu-driven
phone system.

The available options are shown on the lower
half of the screen.

Select the option.

u

The mute icon appears when Mute is
selected. Select Mute again to turn it off.

■

Receiving a Call

1

Receiving a Call

Call Waiting
Press the

 button to put the current call on hold to

answer the incoming call.
Press the

 button again to return to the current

call.

Select Ignore to ignore the incoming call if you do
not want to answer it.
Press the

 button if you want to hang up the

current call.

You can select the icons on the audio/information
screen instead of the

 and

 buttons.

■

Options During a Call

1

Options During a Call

You can select the icons on the audio/information
screen.

Mute Icon

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

430

Features

■

To turn on or off the text message
notice

1. Press the

 button.

2. Select Messages.
3. Select Settings.
4. Select Pop-up Notification.
5. Select ON or OFF.

■

To Set Up Text Message Options

1

To Set Up Text Message Options

To use the text message function, it may be necessary
to set up on your phone.

1

To turn on or off the text message notice

ON: A pop-up notification comes on every time you
receive a new message.
OFF: The message you receive is stored in the system
without notification.
