Honda Insight (2019 year). Manual - part 7

95

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Canadian models only: Apply and hold the brake pedal before selecting the ON mode.

Indicator

Name

On/Blinking

Explanation

Message

*1

Immobilizer
System
Indicator

• Blinks if the immobilizer system

cannot recognize the key
information.

• Blinks - You cannot start the power

system. Set the power mode to VEHICLE
OFF

*1

, then select the ON mode again.

• Repeatedly blinks - The system may be

malfunctioning. Have your vehicle
checked by a dealer.

• Do not attempt to alter this system or add

other devices to it. Electrical problems can
occur.

Security System
Alarm Indicator

• Blinks when the security system

alarm has been set.

2 Security System Alarm P. 184

—

Indicator

Indicator

96

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

System
Message
Indicator

• Comes on along with a beep when

a problem is detected. A system
message on the driver information
interface appears at the same time.

• While the indicator is on, press the



(home) button to see the message again.

2 Accessing contents in the main

display P. 131

• Refer to the Indicators information in this

chapter when a system message appears
on the driver information interface. Take
the appropriate action for the message.

• The driver information interface does not

return to the normal screen unless the
warning is canceled, or the left selector
wheel is pressed.

—

ECON Mode
Indicator

• Comes on when the ECON mode is

on.

2 ECON Mode P. 467

SPORT Mode
Indicator

• Comes on when you press the

SPORT button.

• The ambient meter remains lit up in

red as long as SPORT mode is on.

2 SPORT Mode P. 463

97

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive
Cruise Control
(ACC) with Low
Speed Follow
(LSF) Indicator
(Amber)

●

Comes on if there is a problem with
ACC with LSF.

●

Stays on constantly - Have your vehicle
checked by a dealer.

●

Indicator may come on temporarily
when the Maximum Load Limit is
exceeded.

●

ACC with LSF has been
automatically canceled.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 445

●

Stays on constantly - Have your vehicle
checked by a dealer.

●

Comes on if the ACC with LSF is
deactivated temporarily after the
12-volt battery has been
disconnected, then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

98

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive
Cruise Control
(ACC) with Low
Speed Follow
(LSF) Indicator
(Green)

●

Comes on when you press the
MAIN button.

2 Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF) P. 492

—

Lane Keeping
Assist System
(LKAS)
Indicator
(Amber)

●

Comes on if there is a problem with
the LKAS.

●

Stays on constantly - Have your vehicle
checked by a dealer.

Lane Keeping
Assist System
(LKAS)
Indicator
(Green)

●

Comes on when you press the
MAIN button.

2 Lane Keeping Assist System (LKAS)

P. 509

—

99

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Safety Support
Indicator
(Amber)

●

Comes on if there is a problem with
RDM or CMBS

TM

.

●

Stays on constantly - Have your vehicle
checked by a dealer.

●

Indicator may come on temporarily
when the Maximum Load Limit is
exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 445

●

Stays on constantly - Have your vehicle
checked by a dealer.

●

Comes on if the RDM and CMBS

TM



are deactivated temporarily after
the 12-volt battery has been
disconnected and then re-
connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

100

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Safety Support
Indicator
(Amber)

●

Comes on when RDM and/or
CMBS

TM

 shuts itself off.

●

Indicator may come on temporarily when
passing through an enclosed space, such
as tunnel.

●

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you have cleaned the radar sensor.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

) P. 483

●

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

2 Front Sensor Camera P. 528

101

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Safety Support
Indicator
(Amber)

●

Comes on when RDM and/or
CMBS

TM

 shuts itself off.

●

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the debris
off with a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator and message are still
displayed even after you have cleaned the
area around the camera.

2 Front Sensor Camera P. 528

Safety Support
Indicator
(Green/Gray)

●

Lights up in green when RDM and
CMBS

TM

 are on.

●

Lights up in green and gray when
RDM or CMBS

TM

 are off.

●

Lights up in gray when RDM and
CMBS

TM

 are off.

2 RDM On and Off P. 519
2 CMBS

TM

 On and Off P. 486

102

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

The following messages appear only on the driver information interface. Press the

 (home) button, select Warnings to see the message

again with the system message indicator on.

2Switching the Display P. 131

Message

Condition

Explanation

●

Appears when the vehicle is no longer able to run
due to a malfunction.

●

Immediately stop in a safe place.

●

Appears when there is a risk that the vehicle will
move unexpectedly after you have stopped due to a
malfunction with the vehicle.

●

While the vehicle is stopped, apply the parking brake.

●

Have your vehicle checked by a dealer.

●

Appears when you set the power mode to ON again
and the vehicle is able to run.

2 Turning on the Power P. 448

103

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if any door or the trunk is not completely

closed.

• Appears if any door or the trunk is opened while

driving. The beeper sounds.

• Disappears when all doors and the trunk are closed.

• Appears when the engine oil pressure is low.

• Appears while driving - Immediately stop in a safe

place.

2 If the Low Oil Pressure Warning Appears P. 633

●

Appears when the engine coolant temperature is
near its upper limit.

●

Drive slowly to prevent overheating.

●

Appears when the engine coolant temperature gets
abnormally high.

2 Overheating P. 631

104

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the washer fluid is low.

●

Refill the washer fluid.

2 Refilling Window Washer Fluid P. 574

●

Appears when the scheduled maintenance is due
soon.

●

Consequently, Maintenance Due Now and
Maintenance Past Due follow.

2 Maintenance Minder Messages on the Driver

Information Interface P. 557

●

Appears when there is a problem with the sensor on
the 12-volt battery.

●

Have your vehicle checked by a dealer.

2 Checking the 12-Volt Battery P. 591

●

Appears along with the 12-volt battery charging
system indicator when the 12-volt battery is not
charging.

●

Turn off the climate control system and rear defogger to
reduce electricity consumption.

2 If the 12-Volt Battery Charging System Indicator

Comes On P. 634

Canadian models

105

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if there is a problem with the cooling
system.

●

Drive slowly to prevent overheating and have your
vehicle checked by a dealer as soon as possible.

●

Appears when the fuel fill cap is loose or is not
installed.

2 Tighten Fuel Cap Message P. 635

●

Appears if the vehicle’s speed reaches about 10 mph
(15 km/h) with the fuel fill door opened.

●

Stop the vehicle and close the fuel fill door.

●

Appears when the fuel fill door has been open for 30
minutes.

●

Turn off the power system, reinstall the fuel cap, and
close the fuel fill door.
- If you still want to refuel, press the fuel fill door release

button to reopen the door.

106

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if the vehicle is being driven in a manner

consistent with drowsy or inattentive driving.

2 Driver Attention Monitor P. 144

• Appears if there is a problem with the automatic

lighting control system.

• Appears while driving - Manually turn the lights on,

and have your vehicle checked by a dealer.

• Appears if there is a problem with the headlights.

• Appears while driving - The headlights may not be

on. When conditions allow you to drive safety, have
your vehicle checked by a dealer as soon as possible.

107

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the automatic brake hold system is
turned off.

2 Automatic Brake Hold P. 536

●

Appears when the automatic brake hold button is
pressed without wearing the driver’s seat belt.

●

Fasten the driver’s seat belt.

2 Automatic Brake Hold P. 536

●

Appears when the automatic brake hold button is
pressed without depressing the brake pedal while
the automatic brake hold is in operation.

●

Press the automatic brake hold button with the brake
pedal depressed.

2 Automatic Brake Hold P. 536

●

Appears when the parking brake is applied
automatically while it is in operation.

2 Automatic Brake Hold P. 536
2 Parking Brake P. 531

108

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if the automatic brake hold is automatically
canceled while it is in operation.

●

Immediately depress the brake pedal.

●

Appears when the electric parking brake switch is
pressed without depressing the brake pedal while
the electric parking brake is in operation.

●

Press the electric parking brake switch with the brake
pedal depressed.

2 Parking Brake P. 531

109

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears when the power mode is in ACCESSORY.

—

●

Appears after the driver’s door is opened when the
power mode is in ACCESSORY.

●

Change the power mode to VEHICLE OFF.

2 POWER Button P. 190

●

Appears when you close the door with the power
mode in ON without the remote inside the vehicle.

●

Disappears when you bring the remote back inside the
vehicle and close the door.

2 Remote Reminder P. 192

●

Appears when the remote battery becomes weak.

2 Replacing the Button Battery P. 593

110

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

●

Appears if the remote battery is too weak to turn on
the power system or the key is not within operating
range to turn on the power system.
A beeper sounds six times.

●

Bring the back of the remote into contact with the
POWER button.

2 If the Remote Battery is Weak P. 626

●

Appears as soon as a problem is detected in the
smart entry system

*

 or push button starting system.

●

Appears constantly - Have your vehicle checked by a
dealer.

●

Appears after you set the power mode to
ACCESSORY or ON.

●

Appears after you unlock and open the driver’s door.

2 Turning on the Power P. 448

• Appears if you press the POWER button while the

vehicle is moving.

• The message will disappear after six seconds or when

the power mode is set to VEHICLE OFF.

Canadian models

* Not available on all models
