432

uu

When Driving

u

Precautions While Driving

Driving

Precautions While Driving

Utility vehicles have a significantly higher rollover rate than other types of vehicles.
To prevent rollovers or loss of control:
• Take corners at slower speeds than you would with a passenger vehicle.
• Avoid sharp turns and abrupt maneuvers whenever possible.
• Do not modify your vehicle in any way that you would raise the center of gravity.
• Do not carry heavy cargo on the roof.

Never carry more than 165 lbs (75 kg) of cargo on the roof rack (Honda accessory).

Avoid driving in deep water and on flooded roads. This can damage the engine or
driveline, or cause electrical component failure.

■

Driving Guidelines for Your Utility Vehicle

■

In Rain

1

Precautions While Driving

NOTICE

Do not operate the shift lever while pressing the
accelerator pedal. You could damage the
transmission.

NOTICE

If you repeatedly turn the steering wheel at an
extremely low speed, or hold the steering wheel in
the full left or right position for a while, the electric
power steering (EPS) system heats up. The system
goes into a protective mode, and limits its
performance. The steering wheel becomes harder
and harder to operate. Once the system cools down,
the EPS system is restored. Repeated operation under
these conditions can eventually damage the system.

If the ignition switch is turned to ACCESSORY

(

q

*1



while driving, the engine will shut down and all
steering and brake power assist functions will stop,
making it difficult to control the vehicle.

Do not put the shift lever in

(

N, as you will lose

engine braking (and acceleration) performance.

During the first 600 miles (1,000 km) of operation,
avoid sudden acceleration or full throttle operation so
as to not damage the engine or powertrain.

Avoid hard braking for the first 200 miles (300 km).
You should also follow this when the brake pads are
replaced.

*1: Models with the smart entry system have an
ENGINE START/STOP button instead of an ignition
switch.

433

uu

When Driving

u

Continuously Variable Transmission

Driving

If there is a strong impact with something under the vehicle, stop in a safe location.
Check the underside of the vehicle for damage or any fluid leaks.

Continuously Variable Transmission

The engine runs at a higher idle speed and creeping increases.
Keep the brake pedal firmly depressed when stopped.

Quickly depressing the accelerator pedal while driving uphill may cause the
transmission to drop to a lower ratio, unexpectedly increasing vehicle speed.
Depress the accelerator pedal carefully, especially on slippery roads and curves.

■

Other Precautions

■

Creeping

■

Kickdown

1

Driving Guidelines for Your Utility Vehicle

Failure to operate your vehicle correctly might result
in a crash or a rollover.

2 Important Handling Information P. 36
2 Precautions While Driving P. 432

434

uu

When Driving

u

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

Continuously variable transmission models without paddle shifters

1

Shifting

You cannot turn the ignition switch to LOCK

(

0 and

remove the key unless the shift lever is in

(

P.

The vehicle may move forward very slightly even in

(

N while the engine is cold.

Depress the brake pedal firmly and, when necessary,
apply the parking brake.

When shifting positions in extremely low
temperatures (-22°F/-30°C), there may be a short
delay before the shift position is displayed. Always
confirm you are in the correct shift position before
driving.

Park
Used when parking or starting the
engine

Reverse
Used when reversing

Neutral
Transmission is not locked

Drive
Used for normal driving

Drive (S)
Used:

●

For better acceleration

●

To increase engine braking

●

When going up or down hills

Release Button

Low

●

Used to further increase engine
braking

●

Used when going up or down hills

435

uu

When Driving

u

Shifting

Driving

■

Shift Lever Operation

1

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D to

(

R and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the shift lever position indicator to check the
lever position before pulling away.

If the transmission indicator blinks when driving, in
any shift position, there is a problem with the
transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

Shift Lever Position Indicator
(Transmission indicator)

Tachometer’s red zone

Depress the brake pedal and press
the shift lever release button to shift.

Shift without pressing the shift lever
release button.

Press the shift lever release button
and shift.

Models with information display

Models with multi-information display

436

uu

When Driving

u

Shifting

Driving

Shifting

Change the shift position in accordance with your driving needs.

■

Shift lever positions

Continuously variable transmission models with paddle shifters

1

Shifting

You cannot change the power mode from ON to
VEHICLE OFF (LOCK) unless the shift lever is in

(

P.

The vehicle may move forward very slightly even in

(

N while the engine is cold.

Depress the brake pedal firmly and, when necessary,
apply the parking brake.

When shifting positions in extremely low
temperatures (-22°F/-30°C), there may be a short
delay before the shift position is displayed. Always
confirm you are in the correct shift position before
driving.

Park
Used when parking or starting the
engine

Reverse
Used when reversing

Neutral
Transmission is not locked

Drive
Used:

●

For normal driving

●

When temporarily driving in the
7-speed manual shift mode

Release Button

Drive (S)
Used for:

●

For better acceleration

●

To increase engine braking

●

When going up or down hills

●

When driving in the 7-speed manual
shift mode

Continued

437

uu

When Driving

u

Shifting

Driving

■

Shift Lever Operation

1

Shift Lever Operation

NOTICE

When you change the shift lever from

(

D to

(

R and

vice versa, come to a complete stop and keep the
brake pedal depressed.
Operating the shift lever before the vehicle has come
to a complete standstill can damage the transmission.

Use the shift lever position indicator to check the
lever position before pulling away.

If the transmission indicator blinks when driving, in
any shift position, there is a problem with the
transmission.
Avoid sudden acceleration and have the transmission
checked by a dealer as soon as possible.

The fuel supply may be cut off if you drive at engine
speeds in or over the tachometer red zone (engine
speed limit). If this happens, you may experience a
slight jolt.

It may not be possible to operate the shift lever if the
brake pedal is applied while the shift lever release
button is held down.
Depress the brake pedal first.

M (7-Speed Manual Shift Mode)
Indicator/Shift Indicator

Tachometer’s red zone

Depress the brake pedal and press
the shift lever release button to shift.

Shift without pressing the shift lever
release button.

Press the shift lever release button
and shift.

Models with information display

Models with multi-information display

Shift Lever Position Indicator (Transmission indicator)

Shift Lever Position Indicator
(Transmission indicator)

uu

When Driving

u

Shifting

438

Driving

Use the paddle shifters to change between 1st and 7th speeds without removing
your hands from the steering wheel. The transmission switches to the 7-speed
manual shift mode when you pull a paddle shifter while driving. This mode is useful
when engine braking is needed.

■

When the shift lever is in

(

D:

The shift mode goes into the 7-speed manual shift mode temporarily, and the
number is displayed in the shift indicator.
The 7-speed manual shift mode is canceled automatically if you drive at constant
speed or accelerate, and the number in the shift indicator goes off.
You can cancel this mode by pulling the

 paddle shifter for a few seconds.

The 7-speed manual shift mode is especially useful when reducing the vehicle speed
temporarily before making a turn.

■

When the shift lever is in

(

S:

The shift mode goes into the 7-speed manual shift mode. The M indicator and the
speed number are displayed in the shift indicator. As the vehicle speed slows down,
the transmission automatically shifts down accordingly. When the vehicle comes to
a stop, it automatically shifts down into 1st.

If the vehicle speed increases and the engine speed reaches near the tachometer’s
red zone, the transmission automatically shifts up.

You can only pull away in 1st speed.

When canceling the 7-speed manual shift mode, move the shift lever from

(

S to

(

D. When the 7-speed manual shift mode is canceled, the M indicator and shift

indicator go off.

■

7-Speed Manual Shift Mode

1

7-Speed Manual Shift Mode

In the 7-speed manual shift mode, the transmission
shifts up or down by operating either paddle shifter
under the following conditions:
Shift Up: The engine speed reaches the lowest
threshold of the higher speed position.
Shift Down: The engine speed reaches the highest
threshold of the lower speed position.

When the engine speed reaches near the
tachometer’s red zone, the transmission shifts up
automatically.
When the engine speed reaches the lowest threshold
of the selected speed position, the transmission shifts
down automatically.

Operating the paddle shifters on slippery surfaces
may cause the tires to lock up. In this case, the 7-
speed manual shift mode is canceled and goes back
to the normal

(

D driving mode.

439

uu

When Driving

u

Shifting

Driving

■

7-Speed Manual Shift Mode Operation

1

7-Speed Manual Shift Mode Operation

Each paddle shift operation makes a single speed
change.
To change continuously, release the paddle shifter
before pulling it again for the next speed.

The shift indicator blinks when you cannot shift up or
down. It indicates that your vehicle speed is not in its
allowable shifting range.
Slightly accelerate to shift up and decelerate to shift
down while the indicator is blinking.

Upshifting when pulling
the

(

+ paddle shifter

(Changes to higher speed
number)

Downshifting when pulling
the

(

- paddle shifter

(Changes to lower speed
number)

(

- Paddle Shifter

(Shift down)

(

+ Paddle Shifter

(Shift up)

440

uu

When Driving

u

ECON Button

Driving

ECON Button

The ECON button turns the ECON mode on
and off. The ECON mode helps you improve
your fuel economy by adjusting the
performance of the engine, transmission,
heating and cooling system

*

/climate control

system

*

, and cruise control

*

.

1

ECON Button

While in ECON mode, the climate control system has
greater temperature fluctuations.

Models with climate control system

Models with information display

Models with multi-information display

* Not available on all models

441

uu

When Driving

u

Cruise Control

*

Continued

Driving

Cruise Control

*

Maintains a constant vehicle speed without having to keep your foot on the
accelerator. Use cruise control on freeways or open roads where you can travel at a
constant speed with little acceleration or deceleration.

1

Cruise Control

*

It may not be possible to maintain a constant speed
when driving uphill or downhill.

When not using cruise control:
Turn off cruise control by pressing the CRUISE
button.

While in ECON mode, it may take relatively more time
to accelerate to maintain the set speed.

3

WARNING

Improper use of the cruise control can lead
to a crash.

Use the cruise control only when traveling
on open highways in good weather.

■

Shift positions for cruise control:
In

(

D or

(

S

Always keep sufficient distance
between you and the vehicle in
front of you.

■

Vehicle speed for cruise control:
Desired speed in a range above
roughly 25 mph (40 km/h) ~

When to use

CRUISE MAIN is on in
the instrument panel.
Cruise control is ready to
use.

■

Press the

CRUISE



button on the
steering wheel.

How to use

* Not available on all models

442

uu

When Driving

u

Cruise Control

*

Driving

Take your foot off the pedal and press the –/SET button when you reach the desired
speed.

The moment you release the –/SET button, the set speed is fixed, and cruise control
begins. The CRUISE CONTROL indicator comes on.

■

To Set the Vehicle Speed

–

/SET Button

On when cruise control begins

Press and release

On

On

443

uu

When Driving

u

Cruise Control

*

Driving

Increase or decrease the vehicle speed using the RES/+ or –/SET buttons on the
steering wheel.

• Each time you press the button, the vehicle speed is increased or decreased by

about 1 mph (1.6 km/h).

• If you keep the button pressed, the vehicle speed increases or decreases until you

release it. This speed is then set.

To cancel cruise control, do any of the following:
• Press the CANCEL button.
• Press the CRUISE button.
• Depress the brake pedal.

The CRUISE CONTROL indicator goes off.

■

To Adjust the Vehicle Speed

1

To Adjust the Vehicle Speed

You can set the vehicle speed using the

–

/SET button

on the steering wheel when adjusting the speed with
the accelerator and brake pedals.

■

To Cancel

To decrease speed

To increase speed

1

To Cancel

Resuming the prior set speed:
After cruise control has been canceled, you can still
resume the prior set speed by pressing the RES/+
button while driving at a speed of at least 25 mph (40
km/h) or more.

You cannot set or resume in the following situations:

•

When vehicle speed is less than 25 mph (40 km/h)

•

When the CRUISE button is turned off

At vehicle speeds of 22 mph (35 km/h) or less, cruise
control is canceled automatically.

CRUISE Button

CANCEL
Button

444

uu

When Driving

u

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control (ESC), System

Driving

Vehicle Stability Assist® (VSA®), aka Electronic
Stability Control (ESC), System

VSA® helps to stabilize the vehicle during cornering if the vehicle turns more or less
than what was intended. It also assists in maintaining traction on slippery surfaces.
It does so by regulating engine output and selectively applying the brakes.

When VSA® activates, you may notice that the
engine does not respond to the accelerator.
You may also notice some noise from the
hydraulic system. You will also see the
indicator blink.

■

VSA® Operation

1

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control
(ESC), System

The VSA® may not function properly if tire type and
size are mixed. Make sure to use the same size and
type of tire, and the air pressures as specified.

When the VSA® system indicator comes on and stays
on while driving, there may be a problem with the
system. While this may not interfere with normal
driving, have your vehicle checked by a dealer
immediately.

VSA® cannot enhance stability in all driving situations
and does not control the entire braking system. You
still need to drive and corner at speeds appropriate
for the conditions and always leave a sufficient
margin of safety.

The main function of the VSA® system is generally
known as Electronic Stability Control (ESC). The
system also includes a traction control function.

VSA® System
Indicator

445

uu

When Driving

u

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control (ESC), System

Driving

This button is on the driver side control panel.
To partially disable VSA® functionality/
features, press and hold it until you hear a
beep.

Your vehicle will have normal braking and
cornering ability, but traction control function
will be less effective.

To restore VSA® functionality/features, press
the

(VSA® OFF) button until you hear a

beep.

VSA® is turned on every time you start the
engine, even if you turned it off the last time
you drove the vehicle.

■

VSA® On and Off

1

Vehicle Stability Assist® (VSA®), aka Electronic Stability Control
(ESC), System

In certain unusual conditions when your vehicle gets
stuck in shallow mud or fresh snow, it may be easier
to free it with the VSA® temporarily switched off.

When the   button is pressed, the traction control
function becomes less effective. This allows for the
wheels to spin more freely at low speed. You should
only attempt to free your vehicle with the VSA® off if
you are not able to free it when the VSA® is on.

Immediately after freeing your vehicle, be sure to
switch VSA® on again. We do not recommend driving
your vehicle with the VSA® system switched off.

You may hear a motor sound coming from the
engine compartment while system checks are being
performed immediately after starting the engine or
while driving. This is normal.

VSA® OFF Indicator

446

uu

When Driving

u

LaneWatch

TM

*

Driving

LaneWatch

TM

*

LaneWatch is an assistance system that allows you to check the passenger side rear
areas displayed on the audio/information screen when the turn signal is activated to
the passenger’s side. A camera in the passenger side door mirror monitors these
areas and allows you to check for vehicles, in addition to your visual check and use
of the passenger door mirror. You can also keep the system on for your convenience
while driving.

1

LaneWatch

TM

*

Important Safety Reminder
Like all assistance systems, LaneWatch has
limitations. Over reliance on LaneWatch may result in
a collision.

The LaneWatch function can be affected by weather,
lighting (including headlights and low sun angle),
ambient darkness, camera condition, and loading.

The LaneWatch may not provide the intended display
of traffic to the side and rear under the following
conditions:

•

Your vehicle’s suspension has been altered,
changing the height of the vehicle.

•

Your tires are over or under inflated.

•

Your tires or wheels are of varied size or
construction.

3

WARNING

Failure to visually confirm that it is safe to
change lanes before doing so may result in
a crash and serious injury or death.

Do not rely only on LaneWatch while
driving.

Always look in your mirrors, to either side
of your vehicle, and behind you for other
vehicles before changing lanes.

The system activates when you:

The passenger side view
display appears on the
audio/information
screen.

Move the turn
signal lever to the
passenger side.

Press the
LaneWatch
button.

The system deactivates when you:

Pull the turn signal
lever back.

Press the LaneWatch
button again.

Camera

Audio/Information Screen

* Not available on all models

447

uu

When Driving

u

LaneWatch

TM

*

Driving

■

Customizing the LaneWatch settings

You can customize the following items using the audio/information screen.
• Show with Turn Signal: Selects whether LaneWatch monitor comes on when

you operate the turn signal light lever.

• Display Time after Turn Signal Off: Changes the remaining LaneWatch

display time after you pull the turn signal lever back.

• Reference Line: Selects whether the reference lines appear on the LaneWatch

monitor.

• Next Maneuver Pop up

*

: Selects whether a turn direction screen of the

navigation system interrupts the LaneWatch display.

• Display: Adjusts display settings.

2 Customized Features P. 341

■

Reference Lines

Three lines that appear on the screen can give
an idea of how far the vehicles or objects on
the screen are from your vehicle, respectively.
If an object is near line 1 (in red), it indicates
that it is close to your vehicle whereas an
object near line 3 is farther away.

1

LaneWatch

TM

*

The LaneWatch camera view is restricted. Its unique
lens makes objects on the screen slightly look
different from what they are.

LaneWatch display does not come on when the shift
lever is in

(

R.

For proper LaneWatch operation:

•

The camera is located in the passenger side door
mirror. Always keep this area clean. If the camera lens
is covered with dirt or moisture, use a soft, moist cloth
to keep the lens clean and free of debris.

•

Do not cover the camera lens with labels or stickers
of any kind.

•

Do not touch the camera lens.

1

Reference Lines

The area around the reference line 1 (red) is very close to
your vehicle. As always, make sure to visually confirm
the safety of a lane change before changing lanes.

The distance between your vehicle and lines 1, 2 and
3 on the screen vary depending on road conditions
and vehicle loading. For example, the reference lines
on the screen may seem to appear closer than the
actual distances when the rear of your vehicle is more
heavily loaded.

Consult a dealer if:

•

The passenger side door mirror, or area around it is
severely impacted, resulting in changing the
camera angle.

•

The LaneWatch display does not come on at all.

* Not available on all models
