Honda Accord (2019 year). Manual

Honda Sensing®

Road Departure Mitigation (RDM) System

560

Driving

When you turn the RDM on and off, do the
following.
1. Press the safety support switch.
2. Roll the left selector wheel to the

symbol and push it.

The message appears on the driver
information interface when the system
becomes on or off.

The RDM is in the previously selected ON or
OFF setting each time you start the engine.

The system may not properly detect lane markings and the position of your vehicle
under certain conditions. Some examples of these conditions are listed below.

■

Environmental conditions

• Driving in bad weather (rain, fog, snow, etc.).
• Sudden changes between light and dark, such as an entrance or exit of a tunnel.
• There is little contrast between lane lines and the roadway surface.
• Driving into low sunlight (e.g., at dawn or dusk).
• Strong light is reflected onto the roadway.
• Driving in the shadows of trees, buildings, etc.
• Shadows of adjacent objects are parallel to lane markings.
• Roadway objects or structures are misinterpreted as lane markers.
• Reflections on the interior of the windshield.
• Driving at night or in a dark condition such as a tunnel.

■

RDM On and Off

RDM On and Off

When you have selected Warning Only from the
customized options using the audio/information
screen, the system does not operate the steering
wheel and braking.

2 Customized Features P. 370, 381

The Vehicle Stability Assist® (VSA®) system, Vehicle
Stability Assist® (VSA®) OFF, adaptive cruise control
(ACC) with low speed follow (LSF)

, adaptive cruise

control (ACC)

, safety support and low tire pressure/

TPMS indicators may come on in amber along with a
message in the driver information interface when you
set the power mode to ON after re-connecting a
battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

Safety Support Switch

Left Selector Wheel

■

RDM Conditions and Limitations

* Not available on all models

561

Honda Sensing®

Road Departure Mitigation (RDM) System

Driving

■

Roadway conditions

• Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,

reflected lights, road spray, high contrast).

• Driving on a road with temporary lane markings.
• Faint, multiple, or varied lane markings are visible on the roadway due to road

repairs or old lane markings.

• The roadway has merging, split, or crossing lines (e.g., such as at an intersection

or crosswalk).

• The lane markings are extremely narrow, wide, or changing.
• The vehicle in front of you is driving near the lane lines.
• The road is hilly or the vehicle is approaching the crest of a hill.
• Driving on rough or unpaved roads, or over bumpy surfaces.
• When objects on the road (curb, guard rail, pylons, etc.) are recognized as white

lines (or yellow lines).

• Driving on roads with double lines.

■

Vehicle conditions

• Headlight lenses are dirty or the headlights are not properly adjusted.
• The outside of the windshield is streaked or blocked by dirt, mud, leaves, wet

snow, etc.

• The inside of the windshield is fogged.
• The camera temperature gets too high.
• An abnormal tire or wheel condition (wrong sized, varied size or construction,

improperly inflated, compact spare tire, etc.).

• The vehicle is tilted due to a heavy load or suspension modifications.
• When tire chains

are installed.

• The vehicle is towing a trailer

* Not available on all models

562

Honda Sensing®

Traffic Sign Recognition System

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit, your vehicle
has just passed through, showing it on the driver information interface and the
head-up display

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. The sign icon will be displayed until the vehicle reaches a predetermined
time and distance.

The sign icon also may switch to another one or disappear when:

• The other designated limit is detected.
• You make a turn with a turn signal at an intersection.

■

How the System Works

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Driver information interface

Head-up display

* Not available on all models

Continued

563

Honda Sensing®

Traffic Sign Recognition System

Driving

If the system does not detect any traffic signs while you are driving, the image below
may appear.

Traffic Sign Recognition System

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system
to shut off, when parking, find a shady area or face
the front of the vehicle away from the sun. If you use
a reflective sun shade, do not allow it to cover the
camera housing.
Covering the camera can concentrate heat on it.

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears, the traffic sign recognition system does not
work, and

will be displayed.

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the air flow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears, the traffic sign recognition system does not
work, and

will be displayed.

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

Driver information interface

Head-up display

* Not available on all models

Honda Sensing®

Traffic Sign Recognition System

564

Driving

The traffic sign recognition system may not be able to recognize the traffic sign in
the following cases.

■

Vehicle conditions

• Headlight lenses are dirty or the headlights are not properly adjusted.
• The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.
• The inside of the windshield is fogged.
• There are portions remaining to be wiped.
• An abnormal tire or wheel condition (wrong sized, varied size or construction,

improperly inflated, compact spare tire, etc.).

• The vehicle is tilted due to a heavy load or suspension modifications.

■

Environmental conditions

• Driving into low sunlight (e.g., at dawn or dusk).
• Strong light is reflected onto the roadway.
• Sudden changes between light and dark, such as an entrance or exit of a tunnel.
• When you drive in the shadows of trees, buildings, etc.
• Driving at night, in dark areas such as long tunnels.
• Driving in bad weather (rain, fog, snow, etc.).
• A vehicle in front of you is travelling flying up spray or snow.

■

Traffic Sign Recognition System Conditions and Limitations

Traffic Sign Recognition System Conditions and Limitations

When the traffic sign recognition system
malfunctions,

appears on the driver information

interface. If this message does not disappear, have
your vehicle checked by a dealer.

Driver information interface

Head-up display

* Not available on all models

565

Honda Sensing®

Traffic Sign Recognition System

Continued

Driving

■

The position or the condition of the traffic sign

• A sign is hard to be found since it is in a complicated area.
• A sign is located far away from your vehicle.
• A sign is located where the beam of the headlight is hard to reach.
• A sign is on a corner or bend in the road.
• Faded or bent signs.
• Rotated or damaged signs.
• A sign is covered with mud, snow, or frost.
• A part of the sign is hidden by the trees, or the sign itself is hidden by a vehicle

and others.

• Light (a streetlight) or a shadow is reflected on the surface of the sign.
• A sign is too bright or too dark (an electric sign).
• A sign of a small size.

■

Other conditions

• When you are driving at a high speed.

566

Honda Sensing®

Traffic Sign Recognition System

Driving

The traffic sign recognition system may not operate correctly, such as displaying a
sign that does not follow the actual regulation for the roadway or does not exist at
all in the following cases.

Regarding the speed limit sign, it may display higher or lower speed than the
actual speed limit.

• There is a supplementary sign with further information such as weather, time,

vehicle type, school zone, etc.

• Figures on the sign are hard to read (electric sign, numbers on the sign are

blurred).

• A sign is in the vicinity of the lane you are driving even though it is not for the lane

(speed limit sign situated at the junction between the side road and the main
road, etc.).

• There are things that look similar to the color or shape of the recognition object

(similar sign, electric sign, signboard, structure, etc.).

• A lorry and others stuck with the sticker of the speed limit sign on the back are

travelling in front of you.

567

Honda Sensing®

Traffic Sign Recognition System

Driving

The speed limit sign icon is displayed on the right half of the screen.

■

Selecting to display traffic signs when main mode is off

You can continue displaying reduced-size traffic sign icon on the driver information
interface and head-up display

even while the main mode is not selected.

2 Customized Features P. 370, 381

■

Signs Displayed on the Driver information interface and Head-
Up Display

■

When main mode is selected

■

When main mode is not selected

Speed Limit Sign

Driver information interface

Head-up display

Driver information interface

Head-up display

* Not available on all models

568

Honda Sensing®

Front Sensor Camera

Driving

Front Sensor Camera

The camera, used in systems such as LKAS, RDM, ACC

, ACC with LSF

, CMBS

and traffic sign recognition system, is designed to detect an object that triggers any
of the systems to operate its functions.

This camera is located behind the rearview
mirror.

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing
system to shut off, when parking, find a shady
area or face the front of the vehicle away from
the sun. If you use a reflective sun shade, do
not allow it to cover the camera housing.
Covering the camera can concentrate heat on
it.

■

Camera Location and Handling Tips

Front Sensor Camera

Never apply a film or attach any objects to the
windshield, the hood, or the front grille that could
obstruct the camera’s field of vision and cause the
system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making
even minor repairs within the camera’s field of vision
or installing an aftermarket replacement windshield
may also cause the system to operate abnormally.
After replacing the windshield, have a dealer
recalibrate the camera. Proper calibration of the
camera is necessary for the system to operate
properly.

Do not place an object on the top of the instrument
panel. It may reflect onto the windshield and prevent
the system from detecting lane lines properly.

Front Sensor
Camera

* Not available on all models

569

Honda Sensing®

Front Sensor Camera

Driving

Front Sensor Camera

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed towards the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

570

Honda Sensing®

Radar Sensor

Driving

Radar Sensor

The radar sensor is at the lower part of the
front bumper.

• Do not change the position of the radar

sensor or any of the surrounding parts.

• Do not apply paint, stickers, or attach non-

genuine accessories to the front part of the
radar sensor or the surrounding area. Be
particularly careful that any custom license
plate frame or other accessory does not
block any part of the radar beam path (see
adjacent illustration).

Radar Sensor

Avoid strong impacts to the radar sensor cover.

For the CMBS

to work properly:

•

Always keep the radar sensor cover clean.

•

Never use chemical solvents or polishing powder
for cleaning the sensor cover. Clean it with water
or a mild detergent.

•

Do not put a sticker on the radar sensor cover or
replace the radar sensor cover.

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by using the safety
support switch and take your vehicle to a dealer.

2 CMBS

On and Off P. 513

If the vehicle is involved in any of the following
situations, the radar sensor may not work properly.
Have your vehicle checked by a dealer:

•

Your vehicle is involved in a frontal collision.

•

Your vehicle drives through deep water or is
submerged in deep water.

•

Your vehicle strongly strikes a bump, curb, chock,
or embankment that could jar the radar sensor.

Radar
Sensor

The radar sensor is
at the lower part of
the front bumper.

Do not apply paint, stickers, or
attach accessories to the front
part of the radar sensor or the
surrounding area.

571

Continued

Driving

Braking

Brake System

Use the parking brake to keep the vehicle stationary when parked. When the
parking brake is applied, you can manually or automatically release it.

■

To apply

The electric parking brake can be applied any
time the vehicle has battery, no matter which
position the power mode is in.

Pull the electric parking brake switch up gently
and securely.

The indicator in the switch comes on.

The parking brake indicator (red) comes
on.

■

Parking Brake

Braking

When you depress the brake pedal, you may hear a
whirring sound from the engine compartment. This is
because the brake system is in operation, and it is
normal.

Parking Brake

You may hear the electric parking brake system
motor operating from the rear wheel area when you
apply or release the parking brake. This is normal.

The brake pedal may slightly move due to the electric
parking brake system operation when you apply or
release the parking brake. This is normal.

You cannot apply or release the parking brake if the
battery goes dead.

2 Jump Starting P. 674

If you pull up and hold the electric parking brake
switch while driving, the brakes on all four
wheels are applied by the VSA® system until the
vehicle comes to a stop. The electric parking
brake then applies, and the switch should be
released.

The engine will not start unless the electric parking
brake is engaged. If the vehicle stalls on a slope, the
electric parking brake system may automatically
engage. If it does not, engage it manually, then start
the engine again.

Manual transmission models

Automatic transmission/Continuously
variable transmission models

Electric Parking Brake Switch

Manual transmission models

Electric Parking Brake Switch

Braking

Brake System

572

Driving

■

To release

The power mode must be in ON in order to
release the electric parking brake.
1. Depress the brake pedal.
2. Press the electric parking brake switch.

The indicator in the switch goes off.

The parking brake indicator (red) goes
off.

Manually releasing the parking brake using
the switch helps your vehicle start slowly and
smoothly when facing down hill on steep hills.

Parking Brake

In the following situations, the parking brake
automatically operates.

•

When the vehicle stops with the automatic brake
hold system activated for more than 10 minutes.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped and the automatic brake
hold system is applied.

•

When the engine is turned off while the automatic
brake hold system is applied.

•

When there is a problem with the automatic brake
hold system while brake hold is applied.

•

When the vehicle is stops more than 10 minutes
while ACC with LSF is activated.

•

When the driver’s seat belt is unfastened while
your vehicle is stopped automatically by ACC with
LSF.

•

When the engine is turned off while ACC with LSF
is activated.

•

When there is a problem with the electric parking
brake switch, after you set the power mode to
VEHICLE OFF.

Models with ACC with LSF

Manual transmission models

Automatic transmission/Continuously
variable transmission models

Electric Parking Brake Switch

Manual transmission models

Electric Parking Brake Switch

Continued

573

Braking

Brake System

Driving

■

Automatic parking brake feature operation

If the automatic parking brake feature has been activated:
• The parking brake is applied automatically when you set the power mode to

VEHICLE OFF.

• To confirm that the parking brake is applied, check if the parking brake indicator

(red) is on.

2 P. 575

■

To release automatically

Depressing the accelerator pedal releases the parking brake.

Depress the accelerator pedal while releasing the clutch pedal releases the parking
brake.

Use the accelerator pedal to release the parking brake when you are starting the
vehicle facing uphill, or in a traffic jam.

Gently depress the accelerator pedal.
When on a hill, it may require more
accelerator input to release.

The indicator in the switch goes off.

The parking brake indicator (red) goes
off.

Parking Brake

If the parking brake cannot be released
automatically, release it manually.

When the vehicle is travelling uphill, the accelerator
pedal may need to be pressed farther to
automatically release the electric parking brake.

The parking brake cannot be released automatically
while the following indicators are on:

•

Malfunction indicator lamp

•

Transmission indicator

The parking brake may not be released automatically
while the following indicators are on:

•

Brake system indicator

•

VSA® system indicator

•

ABS indicator

•

Supplemental restraint system indicator

The clutch pedal is fully depressed before gently
depress the accelerator pedal and release the clutch
pedal.

Manual transmission models

Automatic transmission/Continuously variable transmission models

Manual transmission models

All models

Accelerator Pedal

Automatic transmission/Continuously
variable transmission models

574

Braking

Brake System

Driving

Gently depress the accelerator pedal and
release the clutch pedal.

The indicator in the switch goes off.

The parking brake indicator (red) goes
off.

The parking brake automatically releases as you depress the accelerator pedal when:
• You are wearing the driver’s seat belt.
• The engine is running.

• The transmission is not in

(

P or

(

• The transmission is not in neutral.

Accelerator Pedal

Clutch Pedal

Manual transmission models

Automatic transmission/Continuously variable transmission models

Manual transmission models

Continued

575

Braking

Brake System

Driving

■

Activating and deactivating the automatic parking brake feature

With the power mode is in ON, carry out the following steps to either activate or
deactivate the automatic parking brake feature.
1. Put the transmission into

(

2. Without depressing the brake pedal, pull up and release the parking brake switch.

Check that the parking brake indicator (red) has come on.

3. Pull up and hold the parking brake switch. When you hear a beeping sound,

release the switch and within 3 seconds pull up and hold the switch again.

4. When you hear a sound indicating that the procedure is completed, release the

switch.

Two beeps indicates that the feature has been activated.

One beep indicates that the feature has been deactivated.

When you have completed activating the feature, the parking brake will
remain applied after you turn off the engine.

To confirm that the parking brake is applied, check if the parking brake
indicator (red) is on.

If you need to temporarily deactivate the feature for when putting your vehicle
through a conveyor type car wash, you can follow the procedure explained below.
1. Depress the brake pedal and bring the vehicle to a stop.
2. Set the power mode to VEHICLE OFF and then within 2 seconds push down the

parking brake switch.

Activation and deactivation settings for the feature will not be affected.

Before temporarily deactivating the feature, make sure to first turn off both
ACC with LSF and the automatic brake hold system.

To confirm that the parking brake is applied, check if the parking brake
indicator (red) is on.

Automatic transmission/Continuously variable transmission models

Parking Brake

In cold climates, the parking brake may freeze in
place if applied.

When parking the vehicle, chock the wheels and
make sure the automatic parking brake feature is
deactivated.

Also, when putting your vehicle through a conveyor-
type car wash or when having your vehicle towed,
deactivate the automatic parking brake feature and
leave the parking brake released.

Automatic transmission models

Honda Accord (2019 year). Manual - part 36
