Honda Accord Sedan (2016 year). Manual

128

Co
ntrols

Opening and Closing the Trunk

Precautions for Opening/Closing the Trunk

■

Opening the trunk

Open the trunk all the way.

If it is not fully opened, the trunk lid may begin to close under its own weight.

■

Closing the trunk

Keep the trunk lid closed while driving to:

Avoid possible damage.

Prevent exhaust gas from leaking into the vehicle.

2 Exhaust Gas Hazard P. 64

Using the Trunk Opener

Pulling the trunk release to the lower left of
the driver's seat unlocks and opens the trunk.

Trunk
Release

129

Opening and Closing the Trunk

Using the Trunk Release Button

Co
ntrols

■

Locking the trunk opener

You can lock the trunk release with the master
key

or the built-in key

Using the Trunk Release Button

Push up the release button on the trunk lid
after the doors are unlocked.

Even if the trunk is locked, you can open the
trunk if you carry the smart entry remote.

The beeper will sound.

Locking the trunk opener

If you need to give the key to someone else, give
them the valet key.

Models without smart entry system

Using the Trunk Release Button

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

A person who is not carrying the smart entry
remote can unlock the trunk if a person who is
carrying it is within range.

•

Do not leave the smart entry remote inside the
trunk and close the lid. The beeper sounds and the
trunk cannot be closed.

•

Do not carry the smart entry remote near the trunk
lid when closing it.

•

Do not place the smart entry remote around the
rear seat when closing the trunk.

Trunk Release Button

* Not available on all models

130

Opening and Closing the Trunk

Using the Remote Transmitter

Co
ntrols

Using the Remote Transmitter

Press the trunk release button for
approximately one second to unlock and open
the trunk.

Trunk Main Switch

The trunk main switch disables the trunk
release button on the remote transmitter and
the trunk release button on the trunk lid to
protect luggage in the trunk.
1. Make sure the rear seat-back is not folded

down.

2. Turn off the trunk main switch in the glove

box.

3. Lock the glove box.
4. Lock the trunk release.

2 Using the Trunk Opener P. 128

Trunk Button

Trunk Main Switch

If you need to give the key to someone else, remove
the built-in key from the smart entry remote by
sliding the release knob, and give the remote as a
valet key.

OFF

Main Switch

* Not available on all models

131

Opening and Closing the Trunk

Emergency Trunk Opener

Co
ntrols

Emergency Trunk Opener

The trunk release lever allows you to open the
trunk from inside for your safety.

Slide the release lever in the direction of the
arrow.

Emergency Trunk Opener

Parents should decide if their children should be
shown how to use this feature.

Lever

132

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when inserting the key into the ignition switch or
pressing the ENGINE START/STOP button:
• Do not allow objects that emit strong radio waves near the ignition switch or the

ENGINE START/STOP button.

• Make sure the key is not covered by or touching a metal object.
• Do not bring a key from another vehicle’s immobilizer system near the ignition

switch or the ENGINE START/STOP button.

• Do not put the key near magnetic items. Electronic devices, such as a television set

and audio system are strongly magnetic, or a key chain can become magnetic, too.

Security System Alarm

The security system alarm activates when the trunk, hood or doors are forcibly
opened. The alarm does not go off if the trunk or doors are opened with the key,
remote transmitter or smart entry system.

However, the alarm goes off when a door is opened with the key, then the shift
lever is moved out of

(

P (automatic transmission/CVT models) or the hood is

opened before the ignition switch is turned to ON

(

■

When the security system alarm activates

The horn sounds intermittently and all the exterior lights flash.

■

To deactivate the security system alarm

Unlock the vehicle using the remote transmitter, or smart entry system. The system,
along with the horn and flashing lights, is deactivated.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Immobilizer System

NOTICE

Leaving the ignition key in the vehicle can result in
theft or accidental movement of the vehicle.
Always take the ignition key with you whenever you
leave the vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Security System Alarm

The security alarm continues for a maximum of two
minutes until the security system deactivates.

Continued

133

Security System

Security System Alarm

Co
ntrols

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The ignition switch is in LOCK

(

, and the key has been removed from the

ignition switch.

• The hood and trunk are closed.
• All doors are locked from outside with the key, the remote transmitter, or smart

entry system.

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system is set.

■

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the remote
transmitter, smart entry system, or the ignition switch is turned to ON

(

. The

security system indicator goes off at the same time.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the trunk with the trunk release or the
emergency trunk opener.

•

Opening the hood with the hood release.

•

Moving the shift lever out of

(

If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key or remote transmitter.

Do not attempt to alter this system or add another
device to it.

Automatic transmission/CVT models

134

Security System

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

■

Canceling panic mode

Press any button on the remote transmitter, or turn the ignition switch to ON

(

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Panic Mode

Panic Button

135

Continued

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the ignition switch is in ON

(

, using the switches on the doors. The driver's side switches can be used to

open and close all of the windows.

The power window lock button on the driver's side must be switched off (not
pushed in, indicator off) to open and close the windows from anywhere other than
the driver's seat.

When the power window lock button is pushed in, you can only operate the driver's
window. Turn the power window lock button on when children are in the vehicle.

■

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Opening/Closing Windows with Auto-Open/Close Function

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you turn the ignition switch to LOCK

(

Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it stops closing and reverse direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

WARNING

Closing a power window on someone's
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

On
Off

Power Window
Lock Button

Indicator

Driver’s
Window
Switch

Front Passenger’s
Window Switch

136

Opening and Closing the Windows

Opening/Closing the Power Windows

Co
ntrols

To open: Push the switch down.
To close: Pull the switch up.

Release the switch when the window reaches
the desired position.

To open: Press the unlock button twice
within 10 seconds and hold it down for the
second time.

If the windows stop midway, repeat the
procedure.

■

Opening/Closing Windows without Auto-Open/Close Function

Open

■

Opening Windows and Moonroof with the Remote

Unlock
Button

* Not available on all models

137

Opening and Closing the Windows

Opening/Closing the Power Windows

Co
ntrols

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.
To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows/
moonroof at the desired position. If you want
further adjustment, repeat the same
operation.

■

Opening/Closing the Windows and Moonroof with the Key

Open

* Not available on all models

138

Co
ntrols

Opening and Closing the Moonroof

You can only operate the moonroof when the ignition switch is in ON

(

. Use the

switch in the front of the ceiling to open and close the moonroof.

■

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
touch the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Tilting the moonroof up

To tilt: Push on the center of the moonroof
switch.
To close: Push the switch forward firmly,
then release.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Opening/Closing the Moonroof

Opening/Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you turn the ignition switch off.
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the moonroof to change directions,
then stop. Auto reverse stops sensing when the
moonroof is almost closed to ensure that it fully
closes. Make sure that all objects, including fingers,
are clear of the moonroof.

WARNING

Opening or closing the moonroof on
someone's hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

Open

Tilt

* Not available on all models

139

Co
ntrols

Operating the Switches Around the Steering Wheel

Ignition Switch

Ignition Switch

You cannot take the key out unless the shift lever is
in

(

If you open the driver’s door when the key is in LOCK

(

0 or ACCESSORY

(

q, a warning buzzer will sound

to remind you to take the key out.

When this happens, the following messages appear
on the multi-information display:

•

In LOCK

(

0: Remove Key From Ignition

•

In ACCESSORY

(

q: Turn Ignition Switch To Lock

(0) Position

If the key won’t turn from LOCK

(

0 to ACCESSORY

(

q, turn the key while moving the steering wheel left

and right. The steering wheel will unlock, allowing
the key to turn.

WARNING

Removing the key from the ignition switch
while driving locks the steering. This can
cause you to lose control of the vehicle.

Remove the key from the ignition switch
only when parked.

Manual transmission models

Continuously variable transmission (CVT) models

All models

Models with multi-information display

All models

(

0 LOCK: Insert and remove the key in this

position.

(

q ACCESSORY: Operate the audio system and

other accessories in this position.

(

w ON: This is the position when driving.

(

e START: This position is for starting the engine.

The switch returns to ON

(

w when you let go of

the key.

* Not available on all models

140

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

Co
ntrols

ENGINE START/STOP Button

*1 : Except U.S. automatic transmission/CVT models

■

Changing the Power Mode

ENGINE START/STOP Button

ENGINE START/STOP Button Operating Range

You can start the engine when the smart entry
remote is inside the vehicle.
The engine may also run if the smart entry remote is
close to the door or window, even if it is outside the
vehicle.

ON mode:
Indicator in the button is off, if the engine is running.

If the smart entry remote battery is weak, beeper
sounds and the To Start, Hold Remote Near Start
Button message appears on the multi-information
display

2 If the Smart Entry Remote Battery is Weak

P. 566

Do not leave the power mode in ACCESSORY or ON
when you get out.

Operating Range

Automatic Transmission/CVT

Manual Transmission

VEHICLE OFF (LOCK)
Indicator in the button is off.
The steering wheel is locked

The power to all electrical
components is turned off.

Press the button without the shift
lever in

(

Shift to

(

P then press the button.

Press the button.

Without pressing
the clutch pedal

Without pressing
the brake pedal

ACCESSORY
Indicator in the button is on.
Indicator in the button blinks
(from ON to ACCESSORY).
Operate the audio system and
other accessories in this position.

ON
Indicator in the button is on.
All electrical components can be
used.

Indicator

Shift to

(

U.S. models

* Not available on all models

Continued

141

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the shift lever in

(

and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid draining the battery.

When in this mode:

The steering wheel does not lock.

You cannot lock or unlock doors with the remote transmitter or the smart entry
system.

Press the ENGINE START/STOP button to switch the mode to VEHICLE OFF (LOCK).

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
buzzer sounds.

*1: Automatic transmission/CVT models

■

Automatic Power Off

■

Power Mode Reminder

Changing the Power Mode

If the power mode does not change from VEHICLE
OFF to ACCESSORY, press the ENGINE START/STOP
button while moving the steering wheel left and
right. The steering wheel will unlock, allowing the
mode to change.

Except U.S. automatic transmission/CVT models

All models

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

142

Co
ntrols

Warning buzzers may sound from inside and/
or outside the vehicle to remind you that the
smart entry remote is out of the vehicle. If the
buzzer continues even after the remote is put
back inside, place it within the system’s
operational range.

■

When the power mode is in ON

If the smart entry remote is taken out of the
vehicle, and the driver’s door is closed,
warning buzzers sound from both inside and
outside the vehicle. A warning message on
the information display or multi-information
display notifies the driver inside that the
remote is out.

■

When the power mode is in
ACCESSORY

If the smart entry remote is taken out of the
vehicle, and all the doors are closed, a
warning buzzer sounds from outside the
vehicle.

■

Smart Entry Remote Reminder

Smart Entry Remote Reminder

When the smart entry remote is within the system’s
operational range, and the driver’s door is closed, the
warning function cancels.

If the smart entry remote is taken out of the vehicle
after the engine has been started, you can no longer
change the ENGINE START/STOP button mode or
restart the engine. Always make sure if the remote is
in your vehicle when you operate the ENGINE
START/STOP button.

Removing the smart entry remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the smart entry remote on the dashboard
or in the glove box. It may cause the warning buzzer
to go off. Under some other conditions that can
prevent the vehicle from locating the remote, the
warning buzzer may also go off even if the remote is
within the system’s operational range.

Models with information display

Models with multi-information display

143

Operating the Switches Around the Steering Wheel

Ignition Switch and Power Mode Comparison

Co
ntrols

Ignition Switch and Power Mode Comparison

*1:Except U.S. automatic transmission/CVT models

Ignition Switch
Position

LOCK (0)
(with/without
the key)

ACCESSORY (I)

ON (II)

START (III)

Without Smart Entry
System

●

Engine is turned off and
power is shut down.

●

The steering wheel is
locked.

●

No electrical
components can be
used.

●

Engine is turned off.

●

Some electrical
components such as the
audio system and the
accessory power socket
can be operated.

●

Normal key position
while driving.

●

All electrical components
can be used.

●

Use this position to start
the engine.

●

The ignition switch
returns to the ON (II)
position when you
release the key.

Power Mode

VEHICLE OFF
(LOCK)

ACCESSORY

START

With Smart Entry
System and ENGINE
START/STOP
Button

Indicator-Off

●

Engine is turned off and
power is shut down.

●

The steering wheel is
locked

●

No electrical
components can be
used.

Indicator-On or blinking

●

Engine is turned off.

●

Some electrical
components such as the
audio system and the
accessory power socket
can be operated.

Indicator-
On (engine is turned off)
Off (engine is running)

●

All electrical components
can be used.

Indicator-Off

●

The mode automatically
returns to ON after the
engine starts.

Indicator is: On Off

Honda Accord Sedan (2016 year). Manual - part 9
