Fig. 238: Removing Seat Back
Courtesy of FORD MOTOR CO.

4. To assemble, reverse the disassembly procedure.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 239: Identifying Bolt
Courtesy of FORD MOTOR CO.

SEAT - 60 PERCENT FRONT BENCH

Disassembly

1. Remove the seat track. Refer to SEAT TRACK-MANUAL .

2. Remove the front seat recliner dump handle (62762).



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 240: Removing Front Seat Recliner Dump Handle
Courtesy of FORD MOTOR CO.

3. Remove the front seat back recliner handle.

1. Remove the screw.

2. Remove the front seat back recliner handle.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 241: Removing Front Seat Back Recliner Handle
Courtesy of FORD MOTOR CO.

4. Remove the front seat track side shield (62187).

1. Remove the screws.

2. Remove the pin-type retainer.

3. Disconnect the electrical connectors (if equipped) and remove the front seat track side shield.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
