Ford Crown Victoria (2010 year). Manual - part 9

AM/FM Premium sound satellite compatible Stereo In-dash Six CD
sound system (if equipped)

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

drivers use extreme caution when using any device that may take their
focus off the road. The driver’s primary responsibility is the safe
operation of their vehicle. Only use cell phones and other devices not
essential to the driving task when it is safe to do so.

1. CD slot: To insert a CD, press
LOAD. Wait to insert a CD until the
system displays LOAD CD #. When
the system is ready, insert a CD, label side up.

2. SEEK: Press to access the
next/previous radio station or CD
track. Press and hold to
advance/reverse in the current CD track.

Entertainment Systems

2010 Crown Victoria (cro)
Owners Guide, 2nd Printing
USA (fus)

3. TUNE/CAT: Press to manually go
up or down the radio frequency.

TEXT is only available when
equipped with Satellite radio. Your system may be equipped with
Satellite ready capability. The kit to enable Satellite reception is available
through your dealer. Detailed Satellite instructions are included with the
dealer installed kit. Check with your authorized dealer for
availability.

4. MUTE: Press to mute the playing
media. Press again to return to the
playing media or turn the volume
control to adjust the volume.

5. Eject: Press to eject CD(s) when
the ignition is on or off. Numbers
will illuminate in the display
indicating which CD slots are loaded with CDs. To eject a specific CD,
press eject and the corresponding preset number. If no preset is
selected, the system will eject the currently selected CD. Press and hold
to eject all loaded discs.

Note: If the CD is not removed within 15 seconds, the system will reload
the disc and begin play if the system is on.

6. BASS: Press BASS; then
press

SEL-TEXT

decrease/increase the level of bass
output.

TREB (Treble): Press TREB; then
press

SEL-TEXT

decrease/increase the level of treble
output.

7. BAL (Balance): Press BAL; then
press

SEL-TEXT

to shift

sound to the left/right speakers.

FADE: Press FADE; then press
SEL-TEXT

to shift sound to the

rear/front speakers.

TREB

BASS

SEL-TEXT

TREB

BASS

SEL-TEXT

FADE

BAL

SEL-TEXT

FADE

BAL

SEL-TEXT

Entertainment Systems

2010 Crown Victoria (cro)
Owners Guide, 2nd Printing
USA (fus)

8. SEL-TEXT: Use with Bass,
Treble, Balance, Fade and other
menu functions.

TEXT: TEXT is only available when equipped with Satellite radio. Your
system may be equipped with Satellite ready capability. The kit to enable
Satellite reception is available through your dealer. Detailed Satellite
instructions are included with the dealer installed kit. Check with your
authorized dealer for availability.

9. MENU: Press MENU repeatedly
to access RDS ON/OFF.
Use

SEL-TEXT

to switch

RDS ON/OFF. Press MENU again to access Program type mode or Show
Type mode. (MENU must be pressed within 10 seconds to proceed to
the next RDS mode.)

The Federal Communications Commission (FCC) and the Canadian Radio
and Telecommunications Commission (CRTC) recommend that FM radio
broadcasters use RDS technology to transmit information. FM radio
stations are independently operated and individually elect to use RDS
technology to transmit station ID and program type as desired.

FIND Program type: Allows you to search RDS-equipped stations for a
certain category of music format: Classic, Country, Info, Jazz, Oldies,
R&B, Religious, Rock, Soft, Top 40.
With RDS ON, press MENU until the program type menu is displayed.
One of the various program types will appear. Press

SEL-TEXT

to scroll through music types. Press SEEK or SCAN to search for a
station playing the requested music category.

Show TYPE: Selects between displaying the station’s call letters or
music format when RDS is enabled. Press MENU until SHOW XX appears
in the display. Press to select NAME or TYPE.

Compression: Brings soft and loud CD passages together for a more
consistent listening level when in CD mode. Press MENU until
compression status is displayed. Press

SEL-TEXT

to enable the

compression feature when COMPRESS OFF is displayed. Press the SEL
control again to disable the feature when COMPRESS ON is displayed.
When activated, the compression icon will illuminate in the display.

Occupancy mode (if equipped): Press MENU until occupancy mode
appears in the display. Press

SEL-TEXT

to select ALL SEATS,

DRIVERS SEAT or REAR SEATS occupancy mode.

Entertainment Systems

2010 Crown Victoria (cro)
Owners Guide, 2nd Printing
USA (fus)

Autoset: Allows you to set the strongest local radio stations without
losing your original manually set preset stations for AM/FM1/FM2. Press

MENU until AUTOSET appears in the display. Press

SEL-TEXT

to turn ON or OFF. When the six strongest stations are filled, the station
stored in preset 1 will begin playing. If there are less than six strong
stations, the system will store the last one in the remaining presets.
When activated, AUTOSET will appear in the display when any of the
preset controls are pressed.

Speed sensitive volume: Radio volume changes automatically and
slightly with vehicle speed to compensate for road and wind noise.
Recommended level is 1–3. Level 0 turns the feature off and level 7 is
the maximum setting.

Press MENU to access and use

SEL-TEXT

to adjust the volume

setting. The level will appear in the display.

Setting the clock: Press MENU until SELECT HOUR or SELECT MINS

is displayed. Press

SEL-TEXT

to increase/decrease the

hours/minutes. Press MENU again to disengage clock mode.

10. Memory presets: To set a
station: Select frequency band, tune
to a station, press and hold a preset
button until sound returns. In CD mode, press to select a specific CD to
play.

11. On/Off/Volume: Press to turn
on/off; turn to adjust the volume
levels.

Note: With the ignition off, you may
press the volume control to
momentarily view the clock.

12. LOAD: Press to load a CD.
Press LOAD and a specific preset to
load in that particular slot. Available
slots are indicated by small flashing indicators in the display. When the
system is ready to accept a disc, LOAD CD X will appear in the display.
Load the CD. Press and hold to autoload up to 6 discs.

Note: Ensure that the system is ready to accept the CD. Do not force
the disc into the CD slot as damage could result.

Entertainment Systems

2010 Crown Victoria (cro)
Owners Guide, 2nd Printing
USA (fus)
