81. Install the input sun gear (3) with the input sun gear flange (2) into the 1-2-3-4, 4-5-6 clutch housing (4). 82. Install the input sun gear external retaining ring (1) into the 1-2-3-4, 4-5-6 clutch housing (4). 83. Make sure the retaining ring is seated all the way around the 1-2-3-4, 4-5-6 clutch housing. 84. Remove tools J 24204-2 and J 43777 . See Special Tools. INPUT SUN GEAR THRUST WASHER INSPECTION Fig. 322: Measuring Thickness Of Input Sun Gear Thrust Washer
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
