9. Lubricate the 1-2-3-4 clutch piston housing seal (1) with J 36850 . See Special Tools. Fig. 307: View Of 1-2-3-4 Clutch Piston Housing & 1-2-3-4, 4-5 Clutch Housing 10. Align the 4-5-6 clutch piston return spring assembly (2) so that the notches of the spring assemblies are facing and aligned with the tangs of the 4-5-6 clutch piston (4). 11. Install the 4-5-6 clutch piston return spring assembly (2) into the 4-5-6 clutch piston (4).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
