4. Hold the top of J 44526-2 bolt (8) with a wrench and tighten nut (5) until J 44526-1 extractor (7) engages the bushing (9). 5. Install J 44526-3 protector (4) onto J 44526-2 bolt (8). 6. Install bearing (3), washer (2), and nut (1) onto J 44526-2 bolt (8). 7. Hold the top of J 44526-2 bolt (8) with a wrench and tighten nut (1) until the bushing is dislodged. 8. Remove J 44526 from the turbine shaft. See Special Tools. Installation Procedure
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - Allison - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
