1. Pull the plastic cap back from the quick connect fitting and down along the cooler line about 5 cm (2 in). 2. Using a bent-tip screwdriver, pull on one of the open ends of the retaining ring in order to rotate the retaining ring around the quick connect fitting until the retaining ring is out of 3. Remove the retaining ring from the quick connect fitting. 4. Discard the retaining ring. Fig. 54: Cooler Line & Quick Connect Fitting 5. Pull the cooler line straight out from the quick connect fitting. IMPORTANT: Perform the following procedure when removing the retaining rings and cooler lines from the quick connect fittings located
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Automatic Transmission - 6L50/6L80/6L90 - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
