Preliminary Procedures 1. Turn the ignition switch to the OFF position. 2. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . 3. Remove any dirt and debris from the area of the brake pressure modulator valve (BPMV) assembly. 4. Disconnect the electronic brake control module (EBCM) electrical connector. 1 Master Cylinder Inlet Brake Pipe Fitting (Qty: 2) Tighten: 18 N.m (13 lb ft) NOTE: Refer to Fastener Notice . 2 Front Wheel Outlet Brake Pipe Fitting (Qty: 2) Tighten: 18 N.m (13 lb ft) 3 Rear Wheel Outlet Brake Pipe Fitting Tighten: 18 N.m (13 lb ft) 4 Brake Pressure Modulator Valve (BPMV) Bracket Bolt (Qty: 3) Tighten: 22 N.m (16 lb ft) 5 BPMV Mounting Bolt Tighten: 11 N.m (97 lb in) 6 BPMV Mounting Bracket 7 BPMV Insulator (Qty: 2) BPMV Assembly
2008 Chevrolet Silverado 1500 2008 BRAKES Antilock Brake System - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
