Fig. 81: Identifying Seat Belt Pretensioner Connector, Adapter & Deployment 14. Extend the SIR deployment harness and adapter to full length from the deployment fixture. 15. Connect the seat belt pretensioner connector (1) to the adapter (2) on the deployment harness (3). IMPORTANT: When deploying a seat belt pretensioner, the rapid expansion of gas is very loud. Notify the people in the immediate area
2008 Chevrolet Silverado 1500 2008 RESTRAINTS Supplemental Inflatable Restraints - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
