2. Rotate the coil hub clockwise until the coil ribbon stops. 3. Rotate the coil hub slowly, counterclockwise until the centering window appears yellow (1) and both arrows (2) line up. This is the CENTER position. 4. While holding the coil hub in the CENTER position, align the SIR coil with the horn tower and slide onto the steering shaft assembly. 3. If a double wire harness strap is installed onto the wire harness assembly and column, you must route the wires up against the steering column. One wire harness strap will surround INFLATABLE RESTRAINT INSTRUMENT PANEL MODULE REPLACEMENT Fig. 19: Inflatable Restraint Instrument Panel Module Replacement Callout Component Name
2008 Chevrolet Silverado 1500 2008 RESTRAINTS Supplemental Inflatable Restraints - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
