Fig. 2: Locking Flywheel Using J 44643 1. Install the J 44643 to the starter opening in order to hold the flywheel. See Special Tools . Fig. 3: Accessing Flywheel To Crankshaft Bolts 2. Install two bolts into the clutch pressure plate mounting holes 180 degrees apart. 3. Using a long pry bar, turn the secondary ring of the dual mass flywheel clockwise until the flywheel mounting bolts can be accessed. It may require to turn the secondary ring past the IMPORTANT: Do not use the clutch pressure plate bolts. Use a bolt of the correct thread and a length that protrudes enough to use a
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
