1. If necessary, install a NEW pressure relief valve O-ring. 2. Lubricate the O-ring with engine oil. Tighten: Tighten the valve to 39 N.m (29 lb ft). Fig. 231: Determining Sealant Bead Dimensions 3. Apply a 2-3 mm (1/8 in) wide by 0.5-1.5 mm (1/16 in) high, bead of sealant to the engine front cover sealing surface to the engine block. Refer to Sealers, Adhesives, and 4. Apply a 2-3 mm (1/8 in) wide by 0.5-1.5 mm (1/16 in) high, bead of sealant to the engine front cover sealing surface to the upper oil pan. Refer to Sealers, Adhesives, and
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
