6. Remove the pressure relief valve spring (415). 7. Remove the pressure relief valve (414). 8. Inspect the oil pump components. Refer to Oil Pump Cleaning and Inspection. OIL PUMP CLEANING AND INSPECTION Fig. 491: Exploded View Of Oil Pump IMPORTANT: The internal parts of the oil pump assembly are not The oil pump pipe and screen are to be serviced as an
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
