Fig. 420: Piston Pin, Piston & Connecting Rod 5. Remove the pin from the piston and connecting rod. 6. The piston and pin are a matched set and are not to be serviced separately. Mark, sort, or organize the piston and the matching piston pin. PISTON, CONNECTING ROD, AND BEARING CLEANING AND INSPECTION Piston, Pin, and Piston Rings
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
