REAR SIDE DOOR WINDOW REGULATOR REPLACEMENT (EXTENDED CAB, POWER) 2. Remove the rear door trim panel. Refer to Rear Side Door Trim Panel Replacement (YE9) or Rear Side Door Trim Panel Replacement (SLT) . 3. Remove the rear door water deflector. Refer to Rear Side Door Water Deflector Replacement . 1 Rear Side Door Window Bolt (Qty: 2) Procedure 1. Tape the window to the door frame to prevent it from moving. 2. Loosen the 2 bolts that attach the window to the window regulator. Tighten: 9 N.m (80 lb in) NOTE: Refer to Fastener Notice . 2 Rear Side Door Window Regulator Bolt (Qty: 5) Tighten: 9 N.m (80 lb in) 3 Rear Side Door Window Regulator
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
