Chevrolet Silverado / GMC Sierra. Service manual - part 2986

2. Use a new dauber in order to apply glass prep, clear #1, to the channel area approximately

13 mm (1/2 in) to the upper edge of the window.

3. Wipe the glass primed area immediately with a clean lint-free cloth.

4. Shake the glass primer, black #2, for at least 1 minute.

5. Use a new dauber in order to apply glass primer, black #2, to the top edge of the window.

IMPORTANT: Use care when applying the prep, clear #1, to the window.

This primer dries almost instantly, and may stain the viewing
area of the window if not applied evenly.

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado

Fig. 68: Applying Urethane Adhesive Between Window & Pinch-Weld
Courtesy of GENERAL MOTORS CORP.

6. Apply a small bead of urethane adhesive (2) between the window (1) and the pinch-weld.

Fig. 69: Identifying Reveal Molding
Courtesy of GENERAL MOTORS CORP.

7. Reinstall the window reveal molding.

1. Start from the loose area and hand-press the reveal molding into place over the edge of

the window.

2. Run warm water over the reveal molding in order to speed the setup time of the

urethane adhesive.

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado

3. Tape should be applied in order to retain the reveal molding to the window. This will

maintain a flush fit with the body.

4. The tape is to be removed after 6 hours.

FRONT SIDE DOOR WINDOW AND REAR SIDE DOOR WINDOW SWITCH REPLACEMENT
(WITH DL8 AND WITHOUT SLT)

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado

2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Fixed and Moveable Windows - Cab & Chassis Sierra, Cab & Chassis Silverado,

Sierra & Silverado
