Fig. 190: View Of Sealant Applied To Rear Oil Pan-To-Engine Block Junction 2. Apply a 5 mm (0.20 in) bead of sealant 20 mm (0.8 in) long to the engine block. Refer to Sealers, Adhesives, and Lubricants for the correct part number. Apply the sealant directly onto the tabs of the rear cover gasket that protrudes into the oil
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
