4. Install the pitman arm nut (4). Tighten: Tighten the nut to 62 N.m (46 lb ft). 5. Install the idler arm nut (6). Tighten: Tighten the nut to 62 N.m (46 lb ft). 6. Install the steering linkage inner tie rods (3). Refer to Steering Linkage Inner Tie Rod Replacement. 7. Install the steering linkage shock absorber to the relay rod, if equipped. Refer to Steering Linkage Shock Absorber Replacement. 8. Install the engine shield, if equipped. Refer to Engine Shield Replacement . 9. Adjust the front toe. Refer to Front Toe Adjustment . STEERING LINKAGE SHOCK ABSORBER REPLACEMENT Tools Required J 24319-B Steering Linkage and Tie Rod Puller Removal Procedure 1. Remove the engine shield, if equipped. Refer to Engine Shield Replacement . NOTE: Refer to Fastener Notice . IMPORTANT: Use a new pitman arm nut. IMPORTANT: Use a new idler arm nut.
2008 Chevrolet Silverado 1500 2008 STEERING Steering Linkage - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
