Fig. 10: Identifying U-Bolts 5. Remove the U-bolt nuts. 6. Remove the U-bolts and discard. 7. Remove the spring spacer. 8. Remove the anchor plate. 9. Remove the front and rear leaf spring shackle bolts and nuts. Refer to Spring Shackle Replacement. 10. Remove the front bolt and nuts.
2008 Chevrolet Silverado 1500 2008 SUSPENSION Rear Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
