The flat on the steering gear stub shaft is parallel with the steering gear side cover. The master spline (3) on the steering gear pitman shaft is in line with the steering gear Fig. 98: Rotating Stub Shaft 45 Degrees From Each Side Of Center Of Stub Shaft 8. Place a torque wrench on the stub shaft with the handle in the vertical position. 9. Rotate the steering gear stub shaft 45 degrees from each side of the center of the steering gear stub shaft. The steering gear stub shaft must rotate smoothly and must not stick or bind. 10. Record the steering gear worm bearing preload measured on or near the center. IMPORTANT: Prevent the steering gear pitman shaft lash adjuster screw from turning while tightening the steering gear pitman shaft
2008 Chevrolet Silverado 1500 2008 STEERING Power Steering - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
