Fig. 131: View Of Valve Lifter Guide And Bolt 3. Install the valve lifters and guide to the engine block. 4. Install the valve lifter guide bolt (1). Tighten: Tighten the valve lifter guide bolt (1) to 12 N.m (106 lb in). 5. Install the cylinder head and gasket. Refer to Cylinder Head Replacement - Left Side or NOTE: Refer to Fastener Notice .
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
