Fig. 75: View Of Main Coil Harness & Fuel Injector Electrical Connectors (Left 1. Remove the engine sight shield. Refer to Upper Intake Manifold Sight Shield Replacement (6.0L (LQ4)). 2. Remove the connector position assurance (CPA) lock. 3. Disconnect the main electrical connector (2) feeding the ignition coils. 4. Remove the harness clips (1). 5. Reposition the engine harness. 6. Remove the spark plug wires from the ignition coils. Twist each plug wire 1/2 turn. Pull only on the boot in order to remove the wire from the ignition coil.
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
