Fig. 63: Identifying Intake Manifold Bolt Tightening Sequence 4. Install the intake manifold bolts. Tighten: 1. Tighten the intake manifold bolts a first pass in sequence to 5 N.m (44 lb in). 2. Tighten the intake manifold bolts a final pass in sequence to 10 N.m (89 lb in). NOTE: Refer to Fastener Notice .
2008 Hummer H2 2008 ENGINE Engine Mechanical - 6.2L - H2
|
