Fig. 36: Identifying I/P Compartment Door Lock Cylinder 1. Position the instrument panel compartment latch fork bolt in the up position. 2. Grasp the instrument panel compartment lock cylinder. Depress the rear-most, light-colored tumbler that is flush with the instrument panel compartment lock cylinder surface. 3. Insert the key. All the tumblers will now stay depressed. 4. Insert the instrument panel compartment lock cylinder, with the key inserted, into the instrument panel compartment latch housing. Ensure that the front projection pin is at the The instrument panel compartment lock cylinder will drop into place.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Instrument Panel and Console Trim - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
