Insert the brake pipe end to be flared into the stripping tool to the depth of the ledge While holding the brake pipe firmly against the stripping tool roller ledges, rotate the Rotate the stripping tool in a clockwise direction, ensuring that the brake pipe end After each successive revolution of the stripping tool, carefully rotate the thumbwheel Loosen the thumbwheel of the tool and remove the brake pipe. Inspect the stripped end of the brake pipe to ensure that the proper amount of coating Specification: 6.35 mm (0.250 in) for 4.76 mm (3/16 in) diameter pipe 9.50 mm (0.374 in) for 6.35 mm (1/4 in) and 7.94 mm (5/16 in) diameter pipe IMPORTANT: Do not gouge the metal surface of the brake pipe. IMPORTANT: Ensure that all loose remnants of the nylon coating have been removed from the brake pipe.
2008 Chevrolet Silverado 1500 2008 BRAKES Hydraulic Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
