Fig. 123: Exploded View Of HVAC Module Assembly 1. Install the lower mode door (9) to the HVAC module assembly (10). 2. Install the air temperature separator plate (5) to the HVAC module assembly (10). 3. Install the HVAC module assembly halves. 4. Install the screws to the HVAC module assembly. NOTE: Refer to Fastener Notice . IMPORTANT: For every heat stake removed ensure that you install a screw.
