Fig. 34: Splash Shield (25/35 Series) 3. Install the O-ring to the steering knuckle. 4. Install the wheel speed sensor to the wheel hub and bearing. Tighten: Tighten the sensor mounting bolt to 18 N.m (13 lb ft). 5. Install the wheel hub and bearing and splash shield to the vehicle. 6. Install the wheel hub and bearing mounting bolts. Tighten: Tighten the wheel hub to knuckle bolts to 180 N.m (133 lb ft). 7. Install the nut and washer retaining the wheel drive shaft assembly to the wheel hub and bearing. Tighten: Tighten the nut to 240 N.m (177 lb ft). NOTE: Refer to Fastener Notice . IMPORTANT: The following service procedure applies to those vehicles equipped with 4WD.
2008 Chevrolet Silverado 1500 2008 SUSPENSION Front Suspension - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
