2. Tighten the intake manifold bolts (1-10) a final pass in sequence to 10 N.m (89 lb in). Fig. 73: MAP Sensor 5. Install the fuel rail. Refer to Fuel Rail and Injectors Installation. 6. Lubricate the manifold absolute pressure (MAP) sensor grommet (715) with clean engine oil. 7. Install the grommet onto the MAP sensor (714). 8. Install the MAP sensor and retainer (736).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
