OIL LEVEL INDICATOR AND TUBE INSTALLATION Fig. 716: Oil Level Indicator Tube Sealant 1. Apply sealant GM P/N 12346004 (Canadian P/N 10953480) or equivalent, around the oil level indicator tube 13 mm (0.5 in) below the tube bead. 2. Install the oil level indicator tube into the engine block. Rotate the oil level indicator tube into position. NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
|
