Fig. 19: View Of Oil Pump Screen & O-Ring Seal 1. Remove the oil pan. Refer to Oil Pan Replacement (2WD) or Oil Pan Replacement (4WD) . 2. Remove the engine front cover. Refer to Engine Front Cover Replacement (LC9, LH6, LMG, LY2 and LY5) or Engine Front Cover Replacement (LY6, L76 and L92) . 3. Remove the oil pump screen bolt and nuts. 4. Remove the oil pump screen with O-ring seal.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
