Tighten: Tighten the J 23523-F plate bolts to 25 N.m (18 lb ft). 2. Install the J 23523-F screw into the end for the crankshaft. 3. Install the J 23523-F bearing, the washer, and the nut onto the J 23523-F screw. 4. Rotate the J 23523-F nut clockwise until the crankshaft balancer hub is completely seated against the crankshaft position sensor reluctor ring. 6. Remove the J 23523-F . Fig. 674: View Of Crankshaft Pulley & Bolts 7. Install the crankshaft pulley and bolts. Finger tighten all bolts until snug. Tighten: Tighten the crankshaft pulley bolts to 58 N.m (43 lb ft).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.3L - Sierra & Silverado
|
