Fig. 46: View Of Front Brake Rotor Components Callout Component Name Preliminary Procedures 1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . 2. Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . CAUTION: Refer to Brake Dust Caution . NOTE: Support the brake caliper with heavy mechanic wire, or equivalent, whenever it is separated from its NOTE: Any new rotor must have the protective coating removed from the friction surfaces before being 1 Brake Caliper Bracket Bolt (Qty: 2) Procedure 1. Remove all traces of the adhesive patch on the brake caliper bracket bolts and threaded holes of the brake caliper bracket. 2. Clean the brake caliper bracket bolt threads and the threaded holes of the brake caliper bracket with denatured alcohol or equivalent and allow to 3. Apply threadlocker G/M P/N 12345493 (Canadian P/N 10953488) to 2/3 of the threaded portion of the brake caliper bolts. Tighten: 175 N.m (129 lb ft) NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 BRAKES Disc Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
