5. Remove the tire and wheel assemblies. Refer to Tire and Wheel Removal and Installation . 6. Compress the brake caliper pistons. Install 2 large C-clamps over the top of the caliper housing and against the back Slowly and evenly tighten the C-clamps until the caliper pistons are completely Remove the C-clamps. 1 Brake Caliper Guide Pin Bolt Tighten: 108 N.m (80 lb ft) NOTE: Refer to Fastener Notice . 2 Brake Caliper 1. Without disconnecting the brake hose, pivot the brake caliper upward. 2. Support the brake caliper with heavy mechanics wire or equivalent. 3 Disc Brake Pad (Qty: 2) 4 Brake Pad Shim (Qty: 2) 1. If installing new brake pads, DO NOT reuse the shims. Discard the brake pad shims. 2. Thoroughly clean the brake pad hardware mating surfaces of the caliper bracket of any debris and corrosion. 3. After the installation is complete and with the engine OFF, gradually apply the brake pedal to approximately 2/3 of its travel distance. 4. Slowly release the brake pedal. 5. Wait 15 seconds, then repeat steps 3-4 until a firm brake pedal is obtained. This will properly seat the brake caliper pistons and brake pads. 6. Fill the master cylinder to the proper level. Refer to Master Cylinder
2008 Chevrolet Silverado 1500 2008 BRAKES Disc Brakes - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
